- WhichTractor size: Standard-size
- Not independently tested
- 1993–2001
- 2,165 built
It was ranked on an engine power figure whose source does not say gross or net. WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Fendt Farmer 312 Full specifications
MWM D 226. B-6 six-cylinder diesel or MWM D 226-6.2 (ab 1990 = D 226.B.6) diesel. The manufacturer claimed 123 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
123 hp
92 kW as stated by the source
Not independently tested
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Fendt Farmer 312”, claimed
- Weight
- 11,795 lb
- Top speed
- 24.9 mph
Fendt Farmer 312 specs: key facts
The Fendt Farmer 312 was built from 1993 to 2001.
The Fendt Farmer 312 has a claimed engine power (gross or net not stated) of 92 kW (123 hp); it has no measured PTO figure.
The Fendt Farmer 312 is four-wheel drive (4WD).Source 2
The Fendt Farmer 312 has a MWM D 226. B-6 engine, a 6-cylinder 6.23 L diesel unit.
The Fendt Farmer 312 weighs 5,350 kg (11,795 lb) unladen.
The Fendt Farmer 312 has a rear PTO running at 540/750/1000 rpm.Source 2
The hydraulic pump of the Fendt Farmer 312 delivers 74.0 L/min (19.5 gpm).Source 2
Source · Traktorenlexikon, “Fendt Farmer 312”
-tractor_Fendt_Farmer_312_and_Kyburz-Winch-01ASD.jpg){kind=link}
How much horsepower does a Farmer 312 have?
The only figure for the Farmer 312 is 123 hp (92 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Fendt Farmer 312”
What engine is in a Farmer 312?
A Farmer 312 has an MWM D 226. B-6, a 6-cylinder 6.23 L diesel engine. Diesel tractors have a MWM D 226-6.2 (ab 1990 = D 226.B.6).
| Make & model | MWM D 226. B-6 |
|---|---|
| Cylinders | 6, liquid-cooled |
| Displacement | 380.4 ci · 6.23 L |
| Max torque | 339 lb·ft · 459 N·m @ 1,601 rpm |
Source · Traktorenlexikon, “Fendt Farmer 312”
How much will a Farmer 312 lift?
Hydraulic and PTO specifications for the Farmer 312 are below.
| Pump flow | 19.5 gpm · 74.0 L/minSource 2On record for 1 of 2 configurations |
|---|---|
| Hitch category | Category 3 |
| Rear PTO | engine-driven, 540/750/1000 rpm @ 2,233 engine rpmSource 2 |
Source · Traktorenlexikon, “Fendt Farmer 312”
What transmission does a Farmer 312 have?
Transmission specifications for the Farmer 312 are below.
| Clutch | Hydraulically operated self-adjusting dry clutch by Fichtel & SachsOn record for 1 of 2 configurations |
|---|---|
| Brakes | Hydraulically operated disc brake acting on the differential side shaftsOn record for 1 of 2 configurations |
| Top speed | 24.9 mph · 40 km/hSource 1 |
Source · Traktorenlexikon, “Fendt Farmer 312 LSA”
How much does a Farmer 312 weigh?
A Farmer 312 weighs 11,795 lb (5,350 kg) unladen.
| Unladen weight | 11,795 lb · 5,350 kg |
|---|---|
| Maximum permissible mass | 17,637 lb · 8,000 kgSource 2On record for 1 of 2 configurations |
| Wheelbase | 101.9 in · 2,589 mm |
| Length | 176.4 in · 4,480 mm |
| Width | 91.3 in · 2,320 mm |
| Height | 111.0 in · 2,820 mm |
| Ground clearance | 21.7 in · 550 mm |
| Front track | 70.9–71.7 in · 1,800–1,820 mmthe article lists alternatives |
| Rear track | 73.2 in · 1,860 mm |
Source · Traktorenlexikon, “Fendt Farmer 312”
Which tractors compare with a Farmer 312?
Within 10% of its 123 hp of claimed engine power, the same type, and first built within 15 years of it.
- John Deere 6620123 hp engine, claimed · 2002–2007Side by side with the Farmer 312 →
- Landini 130 DT123.2 hp engine, claimed · 1993–1997Side by side with the Farmer 312 →
- WHITE 6125123.2 hp engine, claimed · 1993–1997Side by side with the Farmer 312 →
- WHITE 6125123.2 hp engine, claimed · 1993–1997Side by side with the Farmer 312 →
- VALMET 8150123.2 hp engine, claimed · 1995–2004Side by side with the Farmer 312 →
- Case-IH CS 130123.2 hp engine, claimed · 1997–2003Side by side with the Farmer 312 →
Everything else people ask
Is a Farmer 312 two-wheel drive or four-wheel drive?
The Fendt Farmer 312 is four-wheel drive (4WD).
What PTO does a Farmer 312 have?
A Farmer 312 has a 540/750/1000 rpm rear PTO.
Where this page comes from
Compiled from Traktorenlexikon, “Fendt Farmer 312 LSA”; and Traktorenlexikon, “Fendt Farmer 312”.
