- Vehicle type: unspecified
- Rigid chassis
- WhichTractor size: Compact
- Not independently tested
- 1982–1985
- 290 built
It sits on the compact/utility boundary, so either size is a fair description. It was ranked on an engine power figure whose source does not say gross or net. WhichTractor size, not the maker’s category
We looked and the record does not say what this machine is. How we decide what a machine is
Fendt Farmer 303 LSA Full specifications
MWM D 226.3.2 three-cylinder diesel. The manufacturer claimed 51.1 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
51.1 hp
38.1 kW as stated by the source
Not independently tested
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Fendt Farmer 303 LSA”, claimed
- Weight
- 7,088 lb
- Hyd. flow
- 10.8 gpm
- Top speed
- 24.9 mph
Fendt Farmer 303 LSA specs: key facts
The Fendt Farmer 303 LSA was built from 1982 to 1985.
The Fendt Farmer 303 LSA has a claimed engine power (gross or net not stated) of 38.1 kW (51.1 hp); it has no measured PTO figure.
The Fendt Farmer 303 LSA is four-wheel drive (4WD).
The Fendt Farmer 303 LSA has a MWM D 226.3.2 engine, a 3-cylinder 3.12 L diesel unit.Source 1
The Fendt Farmer 303 LSA weighs 3,215 kg (7,088 lb) unladen.
The Fendt Farmer 303 LSA has an independent rear PTO running at 540/650/750/1000 rpm.
The hydraulic pump of the Fendt Farmer 303 LSA delivers 40.7 L/min (10.8 gpm).
Source · Traktorenlexikon, “Fendt Farmer 303 LSA”
How much horsepower does a Farmer 303 LSA have?
The only figure for the Farmer 303 LSA is 51.1 hp (38.1 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Fendt Farmer 303 LSA”
What engine is in a Farmer 303 LSA?
A Farmer 303 LSA has an MWM D 226.3.2, a 3-cylinder 3.12 L diesel engine.
| Make & model | MWM D 226.3.2 |
|---|---|
| Cylinders | 3, liquid-cooledSource 2 |
| Displacement | 190.2 ci · 3.12 L |
| Max torque | 148 lb·ft · 201 N·m @ 1,499 rpmSource 2 |
| Electrical system | 12 VSource 2 |
Source · Traktorenlexikon, “Fendt Farmer 102 LS/LSA”
How much will a Farmer 303 LSA lift, and what is its hydraulic flow?
Hydraulic and PTO specifications for the Farmer 303 LSA are below.
| System | Open centre |
|---|---|
| Pump flow | 10.8 gpm · 40.7 L/min |
| Rear PTO | Independent, engine-driven, 540/650/750/1000 rpm @ 2,230 engine rpmEngages under load |
| PTO shaft | 1 3/8'-6 splines (Form-A) |
Source · Traktorenlexikon, “Fendt Farmer 303 LSA”
What transmission does a Farmer 303 LSA have?
Transmission specifications for the Farmer 303 LSA are below.
| Clutch | Single-plate dry clutch from Fichtel & Sachs with upstream Voith fluid coupling |
|---|---|
| Top speed | 24.9 mph · 40 km/h |
Source · Traktorenlexikon, “Fendt Farmer 303 LSA”
How much does a Farmer 303 LSA weigh?
A Farmer 303 LSA weighs 7,088 lb (3,215 kg) unladen.
| Unladen weight | 7,088 lb · 3,215 kg |
|---|---|
| Maximum permissible mass | 11,023 lb · 5,000 kg |
| Wheelbase | 86.3 in · 2,192 mm |
| Length | 148.8 in · 3,780 mm |
| Width | 77.6 in · 1,971 mm |
| Height | 100.5 in · 2,552 mm |
| Ground clearance | 13.3 in · 338 mm |
| Front track | 59.7 in · 1,517 mm |
| Rear track | 59.3 in · 1,506 mm |
| Turning radius, braked | 13.3 ft · 4.06 m |
Source · Traktorenlexikon, “Fendt Farmer 303 LSA”
Which tractors compare with a Farmer 303 LSA?
Within 10% of its 51.1 hp of claimed engine power, the same type, and first built within 15 years of it.
- Hürlimann H-350 (A)51.2 hp engine, claimed · 1982–1986Side by side with the Farmer 303 LSA →
- International Harvester 48551.2 hp engine, claimed · 1981–1990Side by side with the Farmer 303 LSA →
- SAME Condor (DT)51.2 hp engine, claimed · 1978–1982Side by side with the Farmer 303 LSA →
- Hürlimann T-5100 (A)51.2 hp engine, claimed · 1977–1978Side by side with the Farmer 303 LSA →
- Hürlimann T-5200 (A)51.2 hp engine, claimed · 1977–1979Side by side with the Farmer 303 LSA →
- Fiat 550 (DT)51.2 hp engine, claimed · 1968–1978Side by side with the Farmer 303 LSA →
Everything else people ask
Is a Farmer 303 LSA two-wheel drive or four-wheel drive?
The Fendt Farmer 303 LSA is four-wheel drive (4WD).
What PTO does a Farmer 303 LSA have?
A Farmer 303 LSA has a independent 540/650/750/1000 rpm rear PTO on a 1 3/8'-6 splines (Form-A) shaft.
