- Vehicle type: unspecified
- Rigid chassis
- WhichTractor size: Standard-size
- Lab tested ×1
- 2001–2006
WhichTractor size, not the maker’s category
We looked and the record does not say what this machine is. How we decide what a machine is
Fendt Farmer 412 Vario Full specifications
Deutz BF4M 2013 C four-cylinder diesel. The manufacturer claimed 118 horsepower. The only laboratory test on record is of one version: OECD Test 2067 measured 123.4 hp at the PTO of the Farmer 412 Vario (4 WD).
Engine power, claimed · gross or net not stated
118 hp
88 kW as stated by the source
Not independently tested
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Fendt Farmer 412 Vario”, claimed
- Weight
- 11,552 lb
- Hyd. flow
- 30.3 gpm
- Top speed
- 31.1 mph
Fendt Farmer 412 Vario specs: key facts
The Fendt Farmer 412 Vario was built from 2001 to 2006.
Only one version of the Fendt Farmer 412 Vario has a laboratory test on record: the Farmer 412 Vario (4 WD) produced 92.0 kW (123.4 hp) at the PTO, measured on OECD Test 2067.Source 1
The Fendt Farmer 412 Vario has a claimed engine power (gross or net not stated) of 88 kW (118 hp); it has no measured PTO figure.
The Fendt Farmer 412 Vario is four-wheel drive (4WD).Source 1
The Fendt Farmer 412 Vario has a Deutz BF4M 2013 C engine, a 4-cylinder 3.80 L diesel unit.Source 2
The Fendt Farmer 412 Vario weighs 5,240 kg (11,552 lb) unladen.
The Fendt Farmer 412 Vario has a rear PTO running at 540/540E/1000 rpm.
The hydraulic pump of the Fendt Farmer 412 Vario delivers 114.8 L/min (30.3 gpm).
Source · Traktorenlexikon, “Fendt Farmer 412 Vario”
How much horsepower does a Farmer 412 Vario have?
The only laboratory test on record is of one version. OECD Test 2067 measured 123.4 hp at the PTO of the Farmer 412 Vario (4 WD). For the Farmer 412 Vario as a whole the figure is the 118 hp claimed for the engine, which is not power at the shaft.
Sources · Traktorenlexikon, “Fendt Farmer 412 Vario”; OECD test report 2067, 2003
What engine is in a Farmer 412 Vario?
A Farmer 412 Vario has a Deutz BF4M 2013 C, a 4-cylinder 3.80 L diesel engine.
| Make & model | Deutz BF4M 2013 C |
|---|---|
| Cylinders | 4, liquid-cooledSource 3 |
| Displacement | 232.0 ci · 3.80 L |
| Aspiration | supercharged |
| Max torque | 398 lb·ft · 540 N·m @ 1,450 rpmSource 3 |
| Electrical system | 12 VSource 3 |
Source · Traktorenlexikon, “Fendt Farmer 411 Vario”
How much will a Farmer 412 Vario lift, and what is its hydraulic flow?
Hydraulic and PTO specifications for the Farmer 412 Vario are below.
| System | Closed centreSource 1 |
|---|---|
| Pump flow | 30.3 gpm · 114.8 L/min |
| Pressure | 2,611 psi · 180 bar |
| Rear PTO | 540/540E/1000 rpm @ 1,933 engine rpm |
| PTO shaft | 35 mm, 6 splinesSource 1 |
Source · Traktorenlexikon, “Fendt Farmer 412 Vario”
What transmission does a Farmer 412 Vario have?
Transmission specifications for the Farmer 412 Vario are below.
| Steering | Hydrostatic steering, type: OSPC 125 LSR with integrated synchronizing cylinder |
|---|---|
| Top speed | 31.1 mph · 50 km/h |
Source · Traktorenlexikon, “Fendt Farmer 412 Vario”
How much does a Farmer 412 Vario weigh?
A Farmer 412 Vario weighs 11,552 lb (5,240 kg) unladen.
| Unladen weight | 11,552 lb · 5,240 kg |
|---|---|
| Maximum permissible mass | 19,842 lb · 9,000 kg |
| Wheelbase | 95.2 in · 2,417 mm |
| Length | 165.0 in · 4,190 mm |
| Width | 96.7 in · 2,455 mm |
| Height | 113.2 in · 2,875 mm |
| Ground clearance | 20.9 in · 530 mm |
| Front track | 71.7 in · 1,820 mm |
| Rear track | 70.9 in · 1,800 mm |
| Turning radius, braked | 14.4 ft · 4.40 m |
Source · Traktorenlexikon, “Fendt Farmer 412 Vario”
How much fuel does a Farmer 412 Vario burn per hour?
Measured on OECD Test 2067 (tested as the Farmer 412 Vario (4 WD)), at each condition the laboratory recorded.
Cost per hour = fuel used per hour × your fuel price (per litre, or per US gallon for the gal/h figure).
| Test condition | Fuel per hour |
|---|---|
| Maximum PTO powerPTO 92.0 kW (123.4 hp) at 982 rpm | 26.33 L/h 6.96 gal/h |
| Rated engine speedPTO 82.9 kW (111.2 hp) at 1,084 rpm | 24.87 L/h 6.57 gal/h |
| Standard PTO speedPTO 91.7 kW (123.0 hp) at 1,000 rpm | 26.47 L/h 6.99 gal/h |
| 75% load, 50% load | Not on record for this test |
Source · OECD Test 2067
Which tractors compare with a Farmer 412 Vario?
Within 10% of its 118 hp of claimed engine power, the same type, and first built within 15 years of it.
- Fendt 413 Vario118 hp engine, claimed · 2006–2013Side by side with the Farmer 412 Vario →
- Fendt Xylon 320118 hp engine, claimed · 1990Side by side with the Farmer 412 Vario →
- Fendt Vario 513118 hp engine, claimed · from 2013Side by side with the Farmer 412 Vario →
- WHITE 120118 hp engine, claimed · 1987–1990Side by side with the Farmer 412 Vario →
- Renault Ares 626 RX/RZ118.4 hp engine, claimed · 2002–2003Side by side with the Farmer 412 Vario →
- Agco RT-120118.4 hp engine, claimed · 2004–2005Side by side with the Farmer 412 Vario →
Everything else people ask
Is a Farmer 412 Vario two-wheel drive or four-wheel drive?
The Fendt Farmer 412 Vario is four-wheel drive (4WD).
What PTO does a Farmer 412 Vario have?
A Farmer 412 Vario has a 540/540E/1000 rpm rear PTO on a 35 mm, 6 splines shaft.
Where this page comes from
Compiled from OECD tractor test report 2067; Traktorenlexikon, “Fendt Farmer 411 Vario”; and Traktorenlexikon, “Fendt Farmer 412 Vario”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- OECD Code 2 test report 2/2 067: Fendt Farmer 412 Vario — Licence not stated by the publisher; facts cited, OECD-2067 · published 2003-05-28 · retrieved 2026-09-14. OECD; testing station DLG, Gross-Umstadt, Germany. Original document
- Traktorenlexikon: Fendt Farmer 411 Vario — CC BY-SA 4.0, WIKIBOOKS-TL-73703 · revision 990749. Wikibooks contributors (Traktorenlexikon). Original document
- Traktorenlexikon: Fendt Farmer 412 Vario — CC BY-SA 4.0, WIKIBOOKS-TL-82890 · revision 1023883. Wikibooks contributors (Traktorenlexikon). Original document
