- Vehicle type: unspecified
- Rigid chassis
- WhichTractor size: Utility
- No lab test on file
- 1982–1989
- Record: Fendt
- 1,120 built
It was ranked on an engine power figure whose source does not say gross or net. WhichTractor size, not the maker’s category
We looked and the record does not say what this machine is. How we decide what a machine is
Fendt Farmer 304 LSA specs: hp, weight, years
MWM D 226.3.2 three-cylinder diesel. The manufacturer claimed 57.1 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
57.1 hp
42.6 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Fendt Farmer 304 LSA”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 7,275 lb
- Hyd. flow
- 10.7 gpm
- Top speed
- 18.6–24.9 mph
Fendt Farmer 304 LSA specs: key facts
The Fendt Farmer 304 LSA was built from 1982 to 1989.
The Fendt Farmer 304 LSA has a claimed engine power (gross or net not stated) of 42.6 kW (57.1 hp); it has no measured PTO figure.
The Fendt Farmer 304 LSA is four-wheel drive (4WD).
The Fendt Farmer 304 LSA has a MWM D 226.3.2 engine, a 3-cylinder 3.12 L diesel unit.Source 1
The Fendt Farmer 304 LSA weighs 3,300 kg (7,275 lb) unladen.
The Fendt Farmer 304 LSA has an independent rear PTO running at 540/750/1000 rpm.
The hydraulic pump of the Fendt Farmer 304 LSA delivers 40.6 L/min (10.7 gpm).
Source · Traktorenlexikon, “Fendt Farmer 304 LSA”
How does the Farmer 304 LSA compare with its class?
- Worth knowing:
An unladen mass of 3,300 kg is high for its class — 29% above the median of 2,566 kg across the 311 machines within 10% of its power that hold this figure.
Derived by WhichTractor from 311 comparable records. How we work this out
How much horsepower does a Farmer 304 LSA have?
The only figure for the Farmer 304 LSA is 57.1 hp (42.6 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Fendt Farmer 304 LSA”
What engine is in a Farmer 304 LSA?
A Farmer 304 LSA has an MWM D 226.3.2, a 3-cylinder 3.12 L diesel engine.
| Make & model | MWM D 226.3.2 |
|---|---|
| Cylinders | 3, liquid-cooledSource 2 |
| Displacement | 190.2 ci · 3.12 L |
| Max torque | 150 lb·ft · 204 N·m @ 1,590 rpmSource 2 |
| Electrical system | 12 VSource 2 |
Source · Traktorenlexikon, “Fendt Farmer 102 LS/LSA”
How much will a Farmer 304 LSA lift, and what is its hydraulic flow?
Hydraulic and PTO specifications for the Farmer 304 LSA are below.
| System | Open centre |
|---|---|
| Pump flow | 10.7 gpm · 40.6 L/min |
| Rear PTO | Independent, engine-driven, 540/750/1000 rpm @ 2,232 engine rpmEngages under load |
Source · Traktorenlexikon, “Fendt Farmer 304 LSA”
What transmission does a Farmer 304 LSA have?
Transmission specifications for the Farmer 304 LSA are below.
| Top speed | 18.6–24.9 mph · 30–40 km/hthe article lists alternatives |
|---|
Source · Traktorenlexikon, “Fendt Farmer 304 LSA”
How much does a Farmer 304 LSA weigh?
A Farmer 304 LSA weighs 7,275 lb (3,300 kg) unladen.
| Unladen weight | 7,275 lb · 3,300 kg |
|---|---|
| Maximum permissible mass | 11,023 lb · 5,000 kg |
| Wheelbase | 86.3 in · 2,192 mm |
| Length | 148.8 in · 3,780 mm |
| Width | 77.8 in · 1,975 mm |
| Height | 100.5 in · 2,552 mm |
| Ground clearance | 13.3 in · 338 mm |
| Front track | 59.7 in · 1,517 mm |
| Rear track | 59.5 in · 1,512 mm |
| Turning radius, braked | 14.3 ft · 4.37 m |
Source · Traktorenlexikon, “Fendt Farmer 304 LSA”
What oil does a Farmer 304 LSA take, and how much?
A Farmer 304 LSA engine takes 7.7 qt (7.25 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 7.7 qt · 7.25 LSource: Traktorenlexikon, “Fendt Farmer 304 LSA” · single source, not independently verified |
| Transmission | 34.3 qt · 32.5 LSource: Traktorenlexikon, “Fendt Farmer 304 LSA” · single source, not independently verified |
| Hydraulic | 19.0 qt · 18 LSource: Traktorenlexikon, “Fendt Farmer 304 LSA” · single source, not independently verified |
| Cooling system | 10.1 qt · 9.6 LSource: Traktorenlexikon, “Fendt Farmer 304 LSA” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a Farmer 304 LSA?
Within 10% of its 57.1 hp of claimed engine power, the same type, and first built within 15 years of it.
- Fendt Farmer 304 LS57.1 hp engine, claimed · 1982–1989Side by side with the Farmer 304 LSA →
- Fendt Farmer 10557.1 hp engine, claimed · 1972–1973Side by side with the Farmer 304 LSA →
- Hürlimann D-150 Synchromatic57.1 hp engine, claimed · 1969–1971Side by side with the Farmer 304 LSA →
- Fiat 566 (DT)57.3 hp engine, claimed · 1982–1986Side by side with the Farmer 304 LSA →
- AGRIFULL 80-56 (DT)57.3 hp engine, claimed · 1980–1986Side by side with the Farmer 304 LSA →
- ZETOR 6011/604557.3 hp engine, claimed · 1980–1984Side by side with the Farmer 304 LSA →
Common questions about the Fendt Farmer 304 LSA
Is a Farmer 304 LSA two-wheel drive or four-wheel drive?
The Fendt Farmer 304 LSA is four-wheel drive (4WD).
What PTO does a Farmer 304 LSA have?
A Farmer 304 LSA has a independent 540/750/1000 rpm rear PTO.
Sources and how this page was built
Compiled from Traktorenlexikon, “Fendt Farmer 102 LS/LSA”; and Traktorenlexikon, “Fendt Farmer 304 LSA”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- Traktorenlexikon: Fendt Farmer 102 LS/LSA — CC BY-SA 4.0, WIKIBOOKS-TL-98278 · revision 993752. Wikibooks contributors (Traktorenlexikon). Original document
- Traktorenlexikon: Fendt Farmer 304 LSA — CC BY-SA 4.0, WIKIBOOKS-TL-98614 · revision 995584. Wikibooks contributors (Traktorenlexikon). Original document
