- Rigid chassis
- WhichTractor size: Utility
- No lab test on file
- 1969–1972
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Leyland 384 specs: hp, weight, years
LEYLAND-MOTORS 38 TD four-cylinder diesel. The manufacturer claimed 70.0 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
70.0 hp
52.2 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Leyland 384”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 4,718 lb
- 3-point lift
- 3,351 lb
- Hyd. flow
- 7.9 gpm
- Top speed
- 18.6 mph
Leyland 384 specs: key facts
The Leyland 384 was built from 1969 to 1972.
The Leyland 384 has a claimed engine power (gross or net not stated) of 52.2 kW (70.0 hp); it has no measured PTO figure.
The Leyland 384 is two-wheel drive (2WD).
The Leyland 384 has a LEYLAND-MOTORS 38 TD engine, a 4-cylinder 3.77 L diesel unit.
The Leyland 384 weighs 2,140 kg (4,718 lb) unladen.
The Leyland 384 has an independent rear PTO running at 540 rpm.
The three-point hitch of the Leyland 384 lifts 1,520 kg (3,351 lb) at the lower-link ends.
The hydraulic pump of the Leyland 384 delivers 30.0 L/min (7.9 gpm).
Source · Traktorenlexikon, “Leyland 384”
How does the 384 compare with its class?
- Limitation:
A three-point lift at the lower links of 1,520 kg is low for its class — 43% below the median of 2,670 kg across the 318 machines within 10% of its power that hold this figure.
- Worth knowing:
An unladen mass of 2,140 kg is low for its class — 28% below the median of 2,960 kg across the 415 machines within 10% of its power that hold this figure.
Derived by WhichTractor from 415 comparable records. How we work this out
How much horsepower does a 384 have?
The only figure for the 384 is 70.0 hp (52.2 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Leyland 384”
What engine is in a 384?
A 384 has a LEYLAND-MOTORS 38 TD, a 4-cylinder 3.77 L diesel engine.
| Make & model | LEYLAND-MOTORS 38 TD |
|---|---|
| Cylinders | 4, liquid-cooled |
| Displacement | 230.1 ci · 3.77 L |
| Max torque | 174 lb·ft · 236 N·m @ 1,400 rpm |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Leyland 384”
How much will a 384 lift, and what is its hydraulic flow?
A 384 lifts 3,351 lb (1,520 kg) at the lower-link ends.
| Pump flow | 7.9 gpm · 30.0 L/min |
|---|---|
| Lift at ends | 3,351 lb · 1,520 kg |
| Rear PTO | Independent, engine-driven, 540 rpm @ 1,813 engine rpmEngages under load |
| PTO shaft | 1 3/8" - 6 splines |
Source · Traktorenlexikon, “Leyland 384”
What transmission does a 384 have?
Transmission specifications for the 384 are below.
| Clutch | Dry BORG & BECK double clutch |
|---|---|
| Top speed | 18.6 mph · 30 km/h |
Source · Traktorenlexikon, “Leyland 384”
How much does a 384 weigh?
A 384 weighs 4,718 lb (2,140 kg) unladen.
| Unladen weight | 4,718 lb · 2,140 kg |
|---|---|
| Wheelbase | 80.0 in · 2,032 mm |
| Length | 134.0 in · 3,404 mm |
| Width | 68.6 in · 1,742 mm |
| Height | 87.8 in · 2,230 mm |
| Ground clearance | 18.2 in · 462 mm |
| Front track | 52.0–76.0 in · 1,321–1,930 mm |
| Rear track | 52.0–80.0 in · 1,321–2,032 mm |
| Turning radius, braked | 11.3 ft · 3.43 m |
Source · Traktorenlexikon, “Leyland 384”
What oil does a 384 take, and how much?
A 384 engine takes 8.0 qt (7.6 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 8.0 qt · 7.6 LSource: Traktorenlexikon, “Leyland 384” · single source, not independently verified |
| Transmission | 57.7 qt · 54.6 LSource: Traktorenlexikon, “Leyland 384” · single source, not independently verified |
| Cooling system | 14.4 qt · 13.6 LSource: Traktorenlexikon, “Leyland 384” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a 384?
Within 10% of its 54.0 hp at the PTO as the maker claimed it, with no laboratory test on file, the same type, and first built within 15 years of it.
- Nuffield 4/65 (465)54.0 hp PTO, claimed · 1967–1969Side by side with the 384 →
- VALMET 60254.1 hp PTO, claimed · 1978–1982Side by side with the 384 →
- Eicher Mammut 335454 hp PTO, claimed · 1974–1978Side by side with the 384 →
- Massey Ferguson 575 (A)54.2 hp PTO, claimed · 1976–1983Side by side with the 384 →
- International Harvester 60653.6 hp PTO, claimed · 1961–1967Side by side with the 384 →
- Deutz-Fahr DX 3.5054.6 hp PTO, claimed · 1984–1996Side by side with the 384 →
Common questions about the Leyland 384
Is a 384 two-wheel drive or four-wheel drive?
The Leyland 384 is two-wheel drive (2WD).
What PTO does a 384 have?
A 384 has a independent 540 rpm rear PTO on a 1 3/8" - 6 splines shaft.
Sources and how this page was built
Compiled from Traktorenlexikon, “Leyland 384”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- Traktorenlexikon: Leyland 384 — CC BY-SA 4.0, WIKIBOOKS-TL-116099 · revision 993605. Wikibooks contributors (Traktorenlexikon). Original document
