- WhichTractor size: Utility
- No lab test on file
- 1978–1982
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
VALMET 602 specs: hp, weight, years
VALMET 311 C three-cylinder diesel or VALMET 311 CS diesel. The manufacturer claimed 57.3 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
57.3 hp
42.7 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Valmet 602”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 6,129 lb
- 3-point lift
- 3,748 lb
- Hyd. flow
- 8.2 gpm
- Top speed
- 18.6 mph
VALMET 602 specs: key facts
The VALMET 602 was built from 1978 to 1982.
The VALMET 602 has a claimed engine power (gross or net not stated) of 42.7 kW (57.3 hp); it has no measured PTO figure.
The VALMET 602 is two-wheel drive (2WD).Source 2
The VALMET 602 has a VALMET 311 C engine, a 3-cylinder 3.30 L diesel unit.
The VALMET 602 weighs 2,780 kg (6,129 lb) unladen.
The VALMET 602 has a rear PTO running at 540 rpm.
The three-point hitch of the VALMET 602 lifts 1,700 kg (3,748 lb) at the lower-link ends.
The hydraulic pump of the VALMET 602 delivers 30.9 L/min (8.2 gpm).
Source · Traktorenlexikon, “Valmet 602”
How does the 602 compare with its class?
- Limitation:
Six forward gears is low for its class — 40% below the median of 10 across the 309 machines within 10% of its power that hold this figure.
Derived by WhichTractor from 312 comparable records. How we work this out
How much horsepower does a 602 have?
The only figure for the 602 is 57.3 hp (42.7 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Valmet 602”
What engine is in a 602?
A 602 has a VALMET 311 C, a 3-cylinder 3.30 L diesel engine. Diesel tractors have a VALMET 311 CS.
| Make & model | VALMET 311 C |
|---|---|
| Cylinders | 3, liquid-cooled |
| Displacement | 201.3 ci · 3.30 L |
| Max torque | 155 lb·ft · 210 N·m @ 1,300 rpm |
| Injection | Direct injection |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Valmet 602”
How much will a 602 lift, and what is its hydraulic flow?
A 602 lifts 3,748 lb (1,700 kg) at the lower-link ends of its Category 2 three-point hitch.
| Pump flow | 8.2 gpm · 30.9 L/min |
|---|---|
| Hitch category | Category 2 |
| Lift at ends | 3,748 lb · 1,700 kg |
| Rear PTO | 540 rpm @ 1,721 engine rpm |
| PTO shaft | 1 3/8"- 6 splines form A |
Source · Traktorenlexikon, “Valmet 602”
What transmission does a 602 have?
Transmission specifications for the 602 are below.
| Clutch | Dry BORG & BECK double clutch |
|---|---|
| Steering | Hydrostatic DANFOSS steering type ORBITROL |
| Top speed | 18.6 mph · 30 km/h |
Source · Traktorenlexikon, “Valmet 602”
How much does a 602 weigh?
A 602 weighs 6,129 lb (2,780 kg) unladen.
| Unladen weight | 6,129 lb · 2,780 kg |
|---|---|
| Wheelbase | 83.1 in · 2,112 mm |
| Length | 137.3 in · 3,487 mm |
| Width | 69.6 in · 1,769 mm |
| Height | 99.2 in · 2,520 mm |
| Ground clearance | 18.9 in · 480 mm |
| Front track | 55.1–66.9 in · 1,400–1,700 mm |
| Rear track | 56.1–76.3 in · 1,424–1,938 mm |
| Turning radius, braked | 9.8 ft · 3.00 m |
Source · Traktorenlexikon, “Valmet 602”
What oil does a 602 take, and how much?
A 602 engine takes 7.7 qt (7.3 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 7.7 qt · 7.3 LSource: Traktorenlexikon, “Valmet 602” · single source, not independently verified |
| Transmission | 13.2 qt · 12.5 LSource: Traktorenlexikon, “Valmet 602” · single source, not independently verified |
| Hydraulic | 21.1 qt · 20.0 LSource: Traktorenlexikon, “Valmet 602” · single source, not independently verified |
| Cooling system | 10.6 qt · 10.0 LSource: Traktorenlexikon, “Valmet 602” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a 602?
Within 10% of its 54.1 hp at the PTO as the maker claimed it, with no laboratory test on file, the same type, and first built within 15 years of it.
- Leyland 38454.0 hp PTO, claimed · 1969–1972Side by side with the 602 →
- Nuffield 4/65 (465)54.0 hp PTO, claimed · 1967–1969Side by side with the 602 →
- Massey Ferguson 575 (A)54.2 hp PTO, claimed · 1976–1983Side by side with the 602 →
- Eicher Mammut 335454 hp PTO, claimed · 1974–1978Side by side with the 602 →
- Fendt Farmer 260S53.6 hp PTO, claimed · from 1988Side by side with the 602 →
- Deutz-Fahr DX 3.5054.6 hp PTO, claimed · 1984–1996Side by side with the 602 →
Common questions about the VALMET 602
Is a 602 two-wheel drive or four-wheel drive?
The VALMET 602 is two-wheel drive (2WD).
What PTO does a 602 have?
A 602 has a 540 rpm rear PTO on a 1 3/8"- 6 splines form A shaft.
Sources and how this page was built
Compiled from Traktorenlexikon, “Valmet 602”; and Traktorenlexikon, “Valmet 602 Turbo”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- Traktorenlexikon: Valmet 602 — CC BY-SA 4.0, WIKIBOOKS-TL-116325 · revision 997111. Wikibooks contributors (Traktorenlexikon). Original document
- Traktorenlexikon: Valmet 602 Turbo — CC BY-SA 4.0, WIKIBOOKS-TL-116326 · revision 997116. Wikibooks contributors (Traktorenlexikon). Original document
