- Rigid chassis
- WhichTractor size: Utility
- Not independently tested
- 1987–1991
- 10,000 built
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Deutz-Fahr DX 6.05 Full specifications
KHD F6L 912 six-cylinder diesel. The manufacturer claimed 97 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
97 hp
72 kW as stated by the source
Not independently tested
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Deutz-Fahr DX 6.05”, claimed
- Weight
- 9,987 lb
- 3-point lift
- 11,464 lb
- Hyd. flow
- 12.9 gpm
- Top speed
- 18.6–24.9 mph
Deutz-Fahr DX 6.05 specs: key facts
The Deutz-Fahr DX 6.05 was built from 1987 to 1991.
The Deutz-Fahr DX 6.05 has a claimed engine power (gross or net not stated) of 72 kW (97 hp); it has no measured PTO figure.
The Deutz-Fahr DX 6.05 was offered in two-wheel-drive and four-wheel-drive versions.
The Deutz-Fahr DX 6.05 has a KHD F6L 912 engine, a 6-cylinder 5.65 L diesel unit.Source 1
The Deutz-Fahr DX 6.05 weighs 4,530 kg (9,987 lb) unladen.
The Deutz-Fahr DX 6.05 has an independent rear PTO running at 540/1000 rpm.
The three-point hitch of the Deutz-Fahr DX 6.05 lifts 5,200 kg (11,464 lb) at the lower-link ends.
The hydraulic pump of the Deutz-Fahr DX 6.05 delivers 48.8 L/min (12.9 gpm).
Source · Traktorenlexikon, “Deutz-Fahr DX 6.05”
How much horsepower does a DX 6.05 have?
The only figure for the DX 6.05 is 97 hp (72 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Deutz-Fahr DX 6.05”
What engine is in a DX 6.05?
A DX 6.05 has a KHD F6L 912, a 6-cylinder 5.65 L diesel engine.
| Make & model | KHD F6L 912Source 1 |
|---|---|
| Cylinders | 6, air-cooledSource 1 |
| Displacement | 344.9 ci · 5.65 LSource 1 |
| Max torque | 266 lb·ft · 360 N·m @ 1,602 rpm |
| Injection | Bosch inline injection pump and multi-hole nozzle |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Deutz-Fahr DX 6.05”
How much will a DX 6.05 lift, and what is its hydraulic flow?
A DX 6.05 lifts 11,464 lb (5,200 kg) at the lower-link ends.
| System | Open centre |
|---|---|
| Pump flow | 12.9 gpm · 48.8 L/min |
| Pressure | 3,481 psi · 240 bar |
| Lift at ends | 11,464 lb · 5,200 kg |
| Rear PTO | Independent, 540/1000 rpm @ 2,025 engine rpmEngages under load |
Source · Traktorenlexikon, “Deutz-Fahr DX 6.05”
What transmission does a DX 6.05 have?
Transmission specifications for the DX 6.05 are below.
| Clutch | Independent dry double clutch |
|---|---|
| Brakes | Hydraulically operated dry disc brake acting via intermediate shaft on rear wheels |
| Steering | Hydrostatic DANFOSS steering |
| Top speed | 18.6–24.9 mph · 30–40 km/hthe article lists alternatives |
Source · Traktorenlexikon, “Deutz-Fahr DX 6.05”
How much does a DX 6.05 weigh?
A DX 6.05 weighs 9,987 lb (4,530 kg) unladen.
| Unladen weight | 9,987 lb · 4,530 kg |
|---|---|
| Maximum permissible mass | 14,991 lb · 6,800 kg |
| Maximum front axle load | 5,512 lb · 2,500 kg |
| Maximum rear axle load | 10,362 lb · 4,700 kg |
| Wheelbase | 105.0 in · 2,667 mm |
| Length | 175.7 in · 4,464 mm |
| Width | 87.0 in · 2,210 mm |
| Height | 106.7 in · 2,710 mm |
| Ground clearance | 17.9 in · 455 mm |
| Front track | 63.0–70.9 in · 1,600–1,800 mm |
| Rear track | 63.0–78.7 in · 1,600–2,000 mm |
| Turning radius, braked | 16.0 ft · 4.87 m |
Source · Traktorenlexikon, “Deutz-Fahr DX 6.05”
Which tractors compare with a DX 6.05?
Within 10% of its 81.1 hp at the PTO (claimed), the same type, and first built within 15 years of it.
- Case-IH CX 9081.1 hp PTO, claimed · 1998–2000Side by side with the DX 6.05 →
- Lamborghini 874-90 Turbo DT81.3 hp PTO, claimed · 1986–1990Side by side with the DX 6.05 →
- Lamborghini R 874-90 (DT)81.3 hp PTO, claimed · 1989–1998Side by side with the DX 6.05 →
- Fiat TL 90 (DT)81.3 hp PTO, claimed · 1998–2004Side by side with the DX 6.05 →
- Case-IH JX 95 (A)81.3 hp PTO, claimed · 2002–2004Side by side with the DX 6.05 →
- Fiat 880-5 (DT)81.0 hp PTO, claimed · 1980–1984Side by side with the DX 6.05 →
Everything else people ask
Is a DX 6.05 two-wheel drive or four-wheel drive?
The Deutz-Fahr DX 6.05 was offered in two-wheel-drive and four-wheel-drive versions.
What PTO does a DX 6.05 have?
A DX 6.05 has a independent 540/1000 rpm rear PTO.
