- Rigid chassis
- WhichTractor size: Standard-size
- No lab test on file
- 1988–1991
It was ranked on an engine power figure whose source does not say gross or net. WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Ford 7810 specs: hp, weight, years
The manufacturer claimed 96.7 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
96.7 hp
72.1 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Ford 7810”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 7,749 lb
- 3-point lift
- 9,381 lb
- Hyd. flow
- 18.2 gpm
- Top speed
- 18.6 mph
Ford 7810 specs: key facts
The Ford 7810 was built from 1988 to 1991.
The Ford 7810 has a claimed engine power (gross or net not stated) of 72.1 kW (96.7 hp); it has no measured PTO figure.
The Ford 7810 was offered in two-wheel-drive and four-wheel-drive versions.
The Ford 7810 weighs 3,515 kg (7,749 lb) unladen.
The Ford 7810 has an independent rear PTO running at 540/1000 rpm.
The three-point hitch of the Ford 7810 lifts 4,255 kg (9,381 lb) at the lower-link ends.
The hydraulic pump of the Ford 7810 delivers 68.9 L/min (18.2 gpm).
Source · Traktorenlexikon, “Ford 7810”
How much horsepower does a 7810 have?
The only figure for the 7810 is 96.7 hp (72.1 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Ford 7810”
How much will a 7810 lift, and what is its hydraulic flow?
A 7810 lifts 9,381 lb (4,255 kg) at the lower-link ends of its Category 2 three-point hitch.
| Pump flow | 18.2 gpm · 68.9 L/min |
|---|---|
| Hitch category | Category 2 |
| Lift at ends | 9,381 lb · 4,255 kg |
| Rear PTO | Independent, engine-driven, 540/1000 rpm @ 1,901 engine rpm |
Source · Traktorenlexikon, “Ford 7810”
What transmission does a 7810 have?
Transmission specifications for the 7810 are below.
| Steering | Hydrostatic BURMANN steering |
|---|---|
| Top speed | 18.6 mph · 30 km/h |
Source · Traktorenlexikon, “Ford 7810”
How much does a 7810 weigh?
A 7810 weighs 7,749 lb (3,515 kg) unladen.
| Unladen weight | 7,749 lb · 3,515 kgtwo-wheel-drive version |
|---|---|
| Wheelbase | 99.1 in · 2,516 mmtwo-wheel-drive version |
| Length | 165.5 in · 4,204 mm |
| Width | 76.9 in · 1,953 mm |
| Height | 107.8 in · 2,739 mm |
| Ground clearance | 24.0 in · 610 mmtwo-wheel-drive version |
| Front track | 55.9–80.0 in · 1,420–2,032 mmtwo-wheel-drive version |
| Rear track | 59.8–89.8 in · 1,520–2,280 mm |
Source · Traktorenlexikon, “Ford 7810”
What oil does a 7810 take, and how much?
A 7810 engine takes 18.9 qt (17.9 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 18.9 qt · 17.9 LSource: Traktorenlexikon, “Ford 7810” · single source, not independently verified |
| Transmission & hydraulic | 80.9 qt · 76.6 LSource: Traktorenlexikon, “Ford 7810” · single source, not independently verified |
| Front axle | 6.3 qt · 6.0 LSource: Traktorenlexikon, “Ford 7810” · single source, not independently verified |
| Cooling system | 19.9 qt · 18.8 LSource: Traktorenlexikon, “Ford 7810” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a 7810?
Within 10% of its 96.7 hp of claimed engine power, the same type, and first built within 15 years of it.
- Fiat F-100 DT96.7 hp engine, claimed · 1990–1996Side by side with the 7810 →
- SAME Laser 100 (DT)96.7 hp engine, claimed · 1986–1991Side by side with the 7810 →
- VALMET 800096.7 hp engine, claimed · 1991–1996Side by side with the 7810 →
- SAME Jaguar 100 (DT)96.7 hp engine, claimed · 1982–1984Side by side with the 7810 →
- Ford 771096.7 hp engine, claimed · 1981–1991Side by side with the 7810 →
- Fiat 980 (DT)96.7 hp engine, claimed · 1979–1984Side by side with the 7810 →
Common questions about the Ford 7810
Is a 7810 two-wheel drive or four-wheel drive?
The Ford 7810 was offered in two-wheel-drive and four-wheel-drive versions.
What PTO does a 7810 have?
A 7810 has a independent 540/1000 rpm rear PTO.
Sources and how this page was built
Compiled from Traktorenlexikon, “Ford 7810”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- Traktorenlexikon: Ford 7810 — CC BY-SA 4.0, WIKIBOOKS-TL-91156 · revision 917324. Wikibooks contributors (Traktorenlexikon). Original document
