- Rigid chassis
- WhichTractor size: Utility
- No lab test on file
- 1973–1975
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Leyland 245 specs: hp, weight, years
Perkins D 3152 three-cylinder diesel. The manufacturer claimed 46.8 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
46.8 hp
34.9 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Leyland 245”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 5,236 lb
- 3-point lift
- 3,748 lb
- Hyd. flow
- 8.0 gpm
- Top speed
- 16.2 mph
Leyland 245 specs: key facts
The Leyland 245 was built from 1973 to 1975.
The Leyland 245 has a claimed engine power (gross or net not stated) of 34.9 kW (46.8 hp); it has no measured PTO figure.
The Leyland 245 is two-wheel drive (2WD).
The Leyland 245 has a Perkins D 3152 engine, a 3-cylinder 2.50 L diesel unit.Source 2
The Leyland 245 weighs 2,375 kg (5,236 lb) unladen.
The Leyland 245 has an independent rear PTO running at 540 rpm.
The three-point hitch of the Leyland 245 lifts 1,700 kg (3,748 lb) at the lower-link ends.
The hydraulic pump of the Leyland 245 delivers 30.2 L/min (8.0 gpm).
Source · Traktorenlexikon, “Leyland 245”
How much horsepower does a 245 have?
The only figure for the 245 is 46.8 hp (34.9 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Leyland 245”
What engine is in a 245?
A 245 has a Perkins D 3152, a 3-cylinder 2.50 L diesel engine.
| Make & model | Perkins D 3152Source 2 |
|---|---|
| Cylinders | 3, liquid-cooledSource 2 |
| Displacement | 152.7 ci · 2.50 LSource 2 |
| Max torque | 128 lb·ft · 173 N·m @ 1,300 rpm |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Leyland 245”
How much will a 245 lift, and what is its hydraulic flow?
A 245 lifts 3,748 lb (1,700 kg) at the lower-link ends.
| Pump flow | 8.0 gpm · 30.2 L/min |
|---|---|
| Lift at ends | 3,748 lb · 1,700 kg |
| Rear PTO | Independent, engine-driven, 540 rpm @ 1,813 engine rpmEngages under load |
Source · Traktorenlexikon, “Leyland 245”
What transmission does a 245 have?
Transmission specifications for the 245 are below.
| Clutch | Dry Borg & Beck double clutch |
|---|---|
| Brakes | Pedal-operated dry Girling disc brake acting on differential side shafts |
| Steering | Mechanical recirculating ball steering |
| Top speed | 16.2 mph · 26 km/h |
Source · Traktorenlexikon, “Leyland 245”
How much does a 245 weigh?
A 245 weighs 5,236 lb (2,375 kg) unladen.
| Unladen weight | 5,236 lb · 2,375 kg |
|---|---|
| Wheelbase | 74.4 in · 1,890 mm |
| Length | 126.0 in · 3,200 mm |
| Width | 63.8 in · 1,621 mm |
| Height | 90.6 in · 2,301 mm |
| Ground clearance | 15.7 in · 399 mm |
| Front track | 52.0–76.0 in · 1,321–1,930 mm |
| Rear track | 56.0–80.0 in · 1,422–2,032 mm |
| Turning radius, braked | 10.1 ft · 3.07 m |
Source · Traktorenlexikon, “Leyland 245”
What oil does a 245 take, and how much?
A 245 engine takes 7.4 qt (7.0 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 7.4 qt · 7.0 LSource: Traktorenlexikon, “Leyland 245” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a 245?
Within 10% of its 35.4 hp at the PTO as the maker claimed it, with no laboratory test on file, the same type, and first built within 15 years of it.
- David Brown 3800 Selectmatic35.1 hp PTO, claimed · 1968–1971Side by side with the 245 →
- Massey Ferguson 24535.7 hp PTO, claimed · 1976–1983Side by side with the 245 →
- UZINA TRACTORUL 420 (DT)34.9 hp PTO, claimed · 1974–1981Side by side with the 245 →
- International Harvester International 42436.0 hp PTO, claimed · 1964–1967Side by side with the 245 →
- Ford 291036.1 hp PTO, claimed · 1983–1991Side by side with the 245 →
- Steyr 40, 40h, 40a34.6 hp PTO, claimed · 1967–1977Side by side with the 245 →
Common questions about the Leyland 245
Is a 245 two-wheel drive or four-wheel drive?
The Leyland 245 is two-wheel drive (2WD).
What PTO does a 245 have?
A 245 has a independent 540 rpm rear PTO.
Sources and how this page was built
Compiled from Traktorenlexikon, “Leyland 245”; and Traktorenlexikon, “Lindner BF 420 SN/SA”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- Traktorenlexikon: Leyland 245 — CC BY-SA 4.0, WIKIBOOKS-TL-115928 · revision 1056330. Wikibooks contributors (Traktorenlexikon). Original document
- Traktorenlexikon: Lindner BF 420 SN/SA — CC BY-SA 4.0, WIKIBOOKS-TL-83737 · revision 991738. Wikibooks contributors (Traktorenlexikon). Original document
