- Rigid chassis
- WhichTractor size: Utility
- Not independently tested
- 1987–1996
It was ranked on an engine power figure whose source does not say gross or net. WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Deutz-Fahr DX 3.65 Full specifications
KHD F4L 912 four-cylinder diesel. The manufacturer claimed 69.1 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
69.1 hp
51.5 kW as stated by the source
Not independently tested
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Deutz-Fahr DX 3.65”, claimed
- Weight
- 7,496 lb
- 3-point lift
- 7,275 lb
- Hyd. flow
- 11.3 gpm
- Top speed
- 24.9 mph
Deutz-Fahr DX 3.65 specs: key facts
The Deutz-Fahr DX 3.65 was built from 1987 to 1996.
The Deutz-Fahr DX 3.65 has a claimed engine power (gross or net not stated) of 51.5 kW (69.1 hp); it has no measured PTO figure.
The Deutz-Fahr DX 3.65 is four-wheel drive (4WD).
The Deutz-Fahr DX 3.65 has a KHD F4L 912 engine, a 4-cylinder 3.77 L diesel unit.Source 1
The Deutz-Fahr DX 3.65 weighs 3,400 kg (7,496 lb) unladen.
The Deutz-Fahr DX 3.65 has a rear PTO running at 540/1000 rpm.
The three-point hitch of the Deutz-Fahr DX 3.65 lifts 3,300 kg (7,275 lb) at the lower-link ends.
The hydraulic pump of the Deutz-Fahr DX 3.65 delivers 42.6 L/min (11.3 gpm).
Source · Traktorenlexikon, “Deutz-Fahr DX 3.65”
How much horsepower does a DX 3.65 have?
The only figure for the DX 3.65 is 69.1 hp (51.5 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Deutz-Fahr DX 3.65”
What engine is in a DX 3.65?
A DX 3.65 has a KHD F4L 912, a 4-cylinder 3.77 L diesel engine.
| Make & model | KHD F4L 912Source 1 |
|---|---|
| Cylinders | 4, air-cooledSource 1 |
| Displacement | 229.9 ci · 3.77 LSource 1 |
| Max torque | 180 lb·ft · 244 N·m @ 1,543 rpm |
| Injection | direct injection |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Deutz-Fahr DX 3.65”
How much will a DX 3.65 lift, and what is its hydraulic flow?
A DX 3.65 lifts 7,275 lb (3,300 kg) at the lower-link ends.
| System | Constant flow |
|---|---|
| Pump flow | 11.3 gpm · 42.6 L/min |
| Pressure | 3,481 psi · 240 bar |
| Lift at ends | 7,275 lb · 3,300 kg |
| Rear PTO | 540/1000 rpm @ 2,202 engine rpm |
| PTO shaft | 1 3/8"-6 splines (Form 1) |
Source · Traktorenlexikon, “Deutz-Fahr DX 3.65”
What transmission does a DX 3.65 have?
Transmission specifications for the DX 3.65 are below.
| Clutch | independent dry double clutch |
|---|---|
| Steering | hydrostatic ZF steering |
| Top speed | 24.9 mph · 40 km/h |
Source · Traktorenlexikon, “Deutz-Fahr DX 3.65”
How much does a DX 3.65 weigh?
A DX 3.65 weighs 7,496 lb (3,400 kg) unladen.
| Unladen weight | 7,496 lb · 3,400 kg |
|---|---|
| Maximum permissible mass | 11,023 lb · 5,000 kg |
| Maximum front axle load | 4,630 lb · 2,100 kg |
| Maximum rear axle load | 7,716 lb · 3,500 kg |
| Wheelbase | 88.6 in · 2,250 mm |
| Length | 150.4 in · 3,820 mm |
| Width | 85.9 in · 2,183 mm |
| Height | 101.6 in · 2,580 mm |
| Ground clearance | 16.1 in · 408 mm |
| Front track | 59.1–65.0 in · 1,500–1,650 mm |
| Rear track | 59.1–63.0 in · 1,500–1,600 mm |
| Turning radius, braked | 15.1 ft · 4.60 m |
Source · Traktorenlexikon, “Deutz-Fahr DX 3.65”
Which tractors compare with a DX 3.65?
Within 10% of its 69.1 hp of claimed engine power, the same type, and first built within 15 years of it.
- Fiat 70-56 LM (DT69.1 hp engine, claimed · from 1988Side by side with the DX 3.65 →
- UTB U-703 DT69.1 hp engine, claimed · 1988–2004Side by side with the DX 3.65 →
- AGCO-ALLIS 567069.1 hp engine, claimed · 1991–1999Side by side with the DX 3.65 →
- AGCO-ALLIS 667069.1 hp engine, claimed · 1991–1999Side by side with the DX 3.65 →
- Fiat 70-86 (DT)69.1 hp engine, claimed · 1992–2000Side by side with the DX 3.65 →
- Fiat 72-86 (DT)69.1 hp engine, claimed · 1992–2000Side by side with the DX 3.65 →
Everything else people ask
Is a DX 3.65 two-wheel drive or four-wheel drive?
The Deutz-Fahr DX 3.65 is four-wheel drive (4WD).
What PTO does a DX 3.65 have?
A DX 3.65 has a 540/1000 rpm rear PTO on a 1 3/8"-6 splines (Form 1) shaft.
