- Rigid chassis
- WhichTractor size: Standard-size
- Lab tested ×1
- 2002–2005
- Record: Traktorenlexikon
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
New Holland TG 210 Full specifications
CUMMINS 6 TAA-830 six-cylinder diesel or Consolidated Diesel 6TAA-830. The manufacturer claimed 207.2 horsepower. The only laboratory test on record is of one version: OECD Test 2183 measured 195.3 hp at the PTO of the TG 210 (4 WD).
Engine power, claimed · gross or net not stated
207.2 hp
154.5 kW as stated by the source
Not independently tested
Claimed · standard not stated by the source
Source · Traktorenlexikon, “New Holland TG 210”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 20,466 lb
- 3-point lift
- 9,458 lb
- Hyd. flow
- 38.6 gpm
- Top speed
- 24.9 mph
New Holland TG 210 specs: key facts
The New Holland TG 210 was built from 2002 to 2005.
Only one version of the New Holland TG 210 has a laboratory test on record: the TG 210 (4 WD) produced 145.6 kW (195.3 hp) at the PTO, measured on OECD Test 2183.Source 1
The New Holland TG 210 has a claimed engine power (gross or net not stated) of 154.5 kW (207.2 hp); it has no measured PTO figure.
The New Holland TG 210 is four-wheel drive (4WD).Source 1
The New Holland TG 210 has a CUMMINS 6 TAA-830 engine, a 6-cylinder 8.27 L diesel unit.Source 2
The New Holland TG 210 weighs 9,283 kg (20,466 lb) unladen.
The New Holland TG 210 has an independent rear PTO running at 540 rpm / 1000 rpm.
The three-point hitch of the New Holland TG 210 lifts 4,290 kg (9,458 lb) at the lower-link ends.
The hydraulic pump of the New Holland TG 210 delivers 146.1 L/min (38.6 gpm).
Source · Traktorenlexikon, “New Holland TG 210”
How does the TG 210 compare with its class?
- Strength:
Hydraulic pump flow is high for its class. 146 L/min — 33% above the median of 110 L/min across the 86 machines within 10% of its power.
Derived by WhichTractor from 117 comparable records. How we work this out
How much horsepower does a TG 210 have?
The only laboratory test on record is of one version. OECD Test 2183 measured 195.3 hp at the PTO of the TG 210 (4 WD). For the TG 210 as a whole the figure is the 207.2 hp claimed for the engine, which is not power at the shaft.
Sources · Traktorenlexikon, “New Holland TG 210”; OECD test report 2183, 2004
What engine is in a TG 210?
A TG 210 has a CUMMINS 6 TAA-830, a 6-cylinder 8.27 L diesel engine. TG 210 (4 WD) tractors have a Consolidated Diesel 6TAA-830.
| Make & model | CUMMINS 6 TAA-830 |
|---|---|
| Cylinders | 6, liquid-cooledSource 3 |
| Displacement | 504.5 ci · 8.27 L |
| Max torque | 679 lb·ft · 921 N·m @ 1,250 rpmSource 3 |
| Electrical system | 12 VSource 3 |
Source · Traktorenlexikon, “Case-IH MX210”
How much will a TG 210 lift, and what is its hydraulic flow?
A TG 210 lifts 9,458 lb (4,290 kg) at the lower-link ends.
| Pump flow | 38.6 gpm · 146.1 L/min |
|---|---|
| Pressure | 3,031 psi · 209 bar |
| Lift at ends | 9,458 lb · 4,290 kg |
| Rear PTO | Independent, engine-driven, 540 rpm / 1000 rpm @ 1,984 engine rpmEngages under load |
Source · Traktorenlexikon, “New Holland TG 210”
What transmission does a TG 210 have?
Transmission specifications for the TG 210 are below.
| Clutch | Electro-hydraulically operated wet Case-IH multi-plate clutch |
|---|---|
| Steering | Hydrostatic Eaton steering |
| Top speed | 24.9 mph · 40 km/h |
Source · Traktorenlexikon, “New Holland TG 210”
How much does a TG 210 weigh?
A TG 210 weighs 20,466 lb (9,283 kg) unladen.
| Unladen weight | 20,466 lb · 9,283 kgSteer: 9,358 |
|---|---|
| Maximum permissible mass | 30,865 lb · 14,000 kg |
| Wheelbase | 121.2 in · 3,078 mmSteer: 3,284 |
| Length | 227.4 in · 5,775 mm |
| Width | 120.0–150.0 in · 3,048–3,810 mm |
| Height | 125.0 in · 3,175 mm |
| Ground clearance | 13.8 in · 350 mm |
| Front track | 60.0–88.0 in · 1,524–2,235 mm |
| Rear track | 64.0–129.0 in · 1,626–3,277 mm |
Source · Traktorenlexikon, “New Holland TG 210”
What oil does a TG 210 take, and how much?
A TG 210 engine takes 20.1 qt (19.0 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity | Grade | Interval |
|---|---|---|---|
| Engine oil | 20.1 qt · 19.0 LSource: Traktorenlexikon, “New Holland TG 210” · single source, not independently verified | — | — |
| Transmission & hydraulic | 181.8 qt · 172.0 LSource: Traktorenlexikon, “New Holland TG 210” · single source, not independently verified | — | — |
| Cooling system | 26.4 qt · 25.0 LSource: Traktorenlexikon, “New Holland TG 210” · single source, not independently verified | — | — |
Always confirm against the operator’s manual for your machine before service.
How much fuel does a TG 210 burn per hour?
Measured on OECD Test 2183 (tested as the TG 210 (4 WD)), at each condition the laboratory recorded.
Cost per hour = fuel used per hour × your fuel price (per litre, or per US gallon for the gal/h figure).
| Test condition | Fuel per hour |
|---|---|
| Maximum PTO powerPTO 145.6 kW (195.3 hp) at 984 rpm | 44.07 L/h 11.64 gal/h |
| Rated engine speedPTO 129.1 kW (173.1 hp) at 1,110 rpm | 44.15 L/h 11.66 gal/h |
| Standard PTO speedPTO 144.2 kW (193.4 hp) at 1,000 rpm | 44.28 L/h 11.70 gal/h |
| 75% load, 50% load | Not on record for this test |
Source · OECD Test 2183
Which tractors compare with a TG 210?
Within 10% of its 207.2 hp of claimed engine power, the same type, and first built within 15 years of it.
- Ford 8870207.2 hp engine, claimed · 1993–1999Side by side with the TG 210 →
- New Holland 8870 A207.2 hp engine, claimed · 1993–2002Side by side with the TG 210 →
- Massey Ferguson MF 8260 A207.3 hp engine, claimed · 1999–2002Side by side with the TG 210 →
- John Deere 8200 T207.3 hp engine, claimed · 1997–1998Side by side with the TG 210 →
- New Holland-Fiat G 210207.3 hp engine, claimed · 1993–2003Side by side with the TG 210 →
- Fendt 924 Vario207 hp engine, claimed · 2006–2014Side by side with the TG 210 →
Everything else people ask
Is a TG 210 two-wheel drive or four-wheel drive?
The New Holland TG 210 is four-wheel drive (4WD).
What PTO does a TG 210 have?
A TG 210 has a independent 540 rpm / 1000 rpm rear PTO.
Where this page comes from
Compiled from OECD tractor test report 2183; Traktorenlexikon, “New Holland TG 210”; and Traktorenlexikon, “Case-IH MX210”.
