- Vehicle type: unspecified
- Rigid chassis
- WhichTractor size: Utility
- No lab test on file
- 1968–1973
- 5,800 built
It was ranked on an engine power figure whose source does not say gross or net. WhichTractor size, not the maker’s category
We looked and the record does not say what this machine is. How we decide what a machine is
International Harvester Farmall 544 specs: hp, weight, years
INTERNATIONAL HARVESTER C-200 four-cylinder. The manufacturer claimed 51.2 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
51.2 hp
38.2 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Farmall Farmall 544”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 6,098 lb
- Hyd. flow
- 12.0 gpm
- Top speed
- 18.6 mph
International Harvester Farmall 544 specs: key facts
The International Harvester Farmall 544 was built from 1968 to 1973.
The International Harvester Farmall 544 has a claimed engine power (gross or net not stated) of 38.2 kW (51.2 hp); it has no measured PTO figure.
The International Harvester Farmall 544 is two-wheel drive (2WD).
The International Harvester Farmall 544 has a INTERNATIONAL HARVESTER C-200 engine, a 4-cylinder unit.Source 2
The International Harvester Farmall 544 weighs 2,766 kg (6,098 lb) unladen.
The International Harvester Farmall 544 has a dependent rear PTO running at 540/1000 rpm.
The hydraulic pump of the International Harvester Farmall 544 delivers 45.4 L/min (12.0 gpm).
Source · Traktorenlexikon, “Farmall Farmall 544”
How does the Farmall 544 compare with its class?
- Strength:
A maximum engine torque of 232 N·m is high for its class — 31% above the median of 177 N·m across the 241 machines within 10% of its power that hold this figure.
- Limitation:
Five forward gears is low for its class — 38% below the median of 8 across the 312 machines within 10% of its power that hold this figure.
- Strength:
A 125 L fuel tank is high for its class — 95% above the median of 64 L across the 294 machines within 10% of its power that hold this figure.
Derived by WhichTractor from 317 comparable records. How we work this out
How much horsepower does a Farmall 544 have?
The only figure for the Farmall 544 is 51.2 hp (38.2 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Farmall Farmall 544”
What engine is in a Farmall 544?
A Farmall 544 has an INTERNATIONAL HARVESTER C-200, a 4-cylinder engine.
| Make & model | INTERNATIONAL HARVESTER C-200Source 2 |
|---|---|
| Cylinders | 4, liquid-cooledSource 2 |
| Max torque | 171 lb·ft · 232 N·m @ 1,600 rpm |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Farmall Farmall 544”
How much will a Farmall 544 lift, and what is its hydraulic flow?
Hydraulic and PTO specifications for the Farmall 544 are below.
| Pump flow | 12.0 gpm · 45.4 L/min |
|---|---|
| Rear PTO | Dependent, transmission-driven, 540/1000 rpm @ 1,988 engine rpm |
| PTO shaft | 1 3/8"- 6 splines or 1 3/4"-20teilig |
Source · Traktorenlexikon, “Farmall Farmall 544”
What transmission does a Farmall 544 have?
Transmission specifications for the Farmall 544 are below.
| Clutch | Pedal-operated dry single-plate clutch |
|---|---|
| Steering | Hydraulic steering |
| Top speed | 18.6 mph · 30 km/h |
Source · Traktorenlexikon, “Farmall Farmall 544”
How much does a Farmall 544 weigh?
A Farmall 544 weighs 6,098 lb (2,766 kg) unladen.
| Unladen weight | 6,098 lb · 2,766 kg |
|---|---|
| Wheelbase | 90.5 in · 2,299 mm |
| Length | 138.0 in · 3,505 mm |
| Width | 71.0 in · 1,803 mm |
| Height | 62.0 in · 1,575 mm |
| Ground clearance | 13.0 in · 330 mm |
| Front track | 8.0–16.0 in · 203–406 mm |
| Rear track | 54.0–96.0 in · 1,372–2,438 mm |
| Turning radius, braked | 8.7 ft · 2.64 m |
Source · Traktorenlexikon, “Farmall Farmall 544”
What oil does a Farmall 544 take, and how much?
A Farmall 544 engine takes 7.0 qt (6.6 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 7.0 qt · 6.6 LSource: Traktorenlexikon, “Farmall Farmall 544” · single source, not independently verified |
| Transmission | 80.0 qt · 75.7 LSource: Traktorenlexikon, “Farmall Farmall 544” · single source, not independently verified |
| Cooling system | 13.9 qt · 13.2 LSource: Traktorenlexikon, “Farmall Farmall 544” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a Farmall 544?
Within 10% of its 51.2 hp of claimed engine power, the same type, and first built within 15 years of it.
- Fiat 550 (DT)51.2 hp engine, claimed · 1968–1978Side by side with the Farmall 544 →
- Landini R-5000 Special (TL 14 N/A)51.2 hp engine, claimed · 1968–1974Side by side with the Farmall 544 →
- SOMECA 550 (DT)51.2 hp engine, claimed · 1968–1971Side by side with the Farmall 544 →
- SOMECA 615 (DT)51.2 hp engine, claimed · 1965–1968Side by side with the Farmall 544 →
- Ford 4000 (A) 6X/6Y51.2 hp engine, claimed · 1964–1975Side by side with the Farmall 544 →
- Fordson County Super IV51.2 hp engine, claimed · 1960–1964Side by side with the Farmall 544 →
Common questions about the International Harvester Farmall 544
Is a Farmall 544 two-wheel drive or four-wheel drive?
The International Harvester Farmall 544 is two-wheel drive (2WD).
What PTO does a Farmall 544 have?
A Farmall 544 has a dependent 540/1000 rpm rear PTO on a 1 3/8"- 6 splines or 1 3/4"-20teilig shaft.
Sources and how this page was built
Compiled from Traktorenlexikon, “IHC 544”; and Traktorenlexikon, “Farmall Farmall 544”.
