- Rigid chassis
- WhichTractor size: Utility
- No lab test on file
- 1954–1957
- 2,871 built
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Fahr D 130 specs: hp, weight, years
Güldner 2 LD two-cylinder diesel. The manufacturer claimed 16.8 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
16.8 hp
12.5 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Fahr D 130”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 2,624 lb
- Top speed
- 11.7 mph
Fahr D 130 specs: key facts
The Fahr D 130 was built from 1954 to 1957.
The Fahr D 130 has a claimed engine power (gross or net not stated) of 12.5 kW (16.8 hp); it has no measured PTO figure.
The Fahr D 130 is two-wheel drive (2WD).
The Fahr D 130 has a Güldner 2 LD engine, a 2-cylinder 1.31 L diesel unit.Source 2
The Fahr D 130 weighs 1,190 kg (2,624 lb) unladen.
The Fahr D 130 has a rear PTO running at 588 rpm.
Source · Traktorenlexikon, “Fahr D 130”
How much horsepower does a D 130 have?
The only figure for the D 130 is 16.8 hp (12.5 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Fahr D 130”
What engine is in a D 130?
A D 130 has a Güldner 2 LD, a 2-cylinder 1.31 L diesel engine.
| Make & model | Güldner 2 LDSource 2 |
|---|---|
| Cylinders | 2, air-cooledSource 2 |
| Displacement | 79.6 ci · 1.31 LSource 2 |
| Max torque | 48 lb·ft · 65 N·m @ 1,700 rpm |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Fahr D 130”
How much will a D 130 lift?
Hydraulic and PTO specifications for the D 130 are below.
| Pressure | 3,129 psi · 216 bar |
|---|---|
| Rear PTO | 588 rpm |
| PTO shaft | 29 x 34,9 x 8,7 mm |
Source · Traktorenlexikon, “Fahr D 130”
What transmission does a D 130 have?
Transmission specifications for the D 130 are below.
| Steering | ZF steering type EL-10 604 |
|---|---|
| Top speed | 11.7 mph · 18.8 km/h |
Source · Traktorenlexikon, “Fahr D 130”
How much does a D 130 weigh?
A D 130 weighs 2,624 lb (1,190 kg) unladen.
| Unladen weight | 2,624 lb · 1,190 kg |
|---|---|
| Maximum permissible mass | 3,748 lb · 1,700 kg |
| Maximum front axle load | 1,543 lb · 700 kg |
| Maximum rear axle load | 2,205 lb · 1,000 kg |
| Wheelbase | 65.6 in · 1,665 mm |
| Length | 104.7 in · 2,660 mm |
| Width | 64.4 in · 1,636 mm |
| Height | 59.7 in · 1,516 mm |
| Ground clearance | 14.2 in · 361 mm |
| Front track | 48.2–75.7 in · 1,224–1,924 mmWikibooks gives one track for both axles |
| Rear track | 48.2–75.7 in · 1,224–1,924 mmWikibooks gives one track for both axles |
| Turning radius, braked | 8.1 ft · 2.48 m |
Source · Traktorenlexikon, “Fahr D 130”
Which tractors compare with a D 130?
Within 10% of its 17 hp at the PTO as the maker claimed it, with no laboratory test on file, the same type, and first built within 15 years of it.
- Fahr D 17 NA17 hp PTO, claimed · 1953–1955Side by side with the D 130 →
- Fahr D 17 NH17 hp PTO, claimed · 1953–1955Side by side with the D 130 →
- Fahr D 17 NHA17 hp PTO, claimed · 1953–1955Side by side with the D 130 →
- Fahr D 17N17 hp PTO, claimed · 1953–1955Side by side with the D 130 →
- Kramer KA 1717 hp PTO, claimed · 1956Side by side with the D 130 →
- BOLINDER-MUNKTELL 425 Terrier16.8 hp PTO, claimed · 1957–1962Side by side with the D 130 →
Common questions about the Fahr D 130
Is a D 130 two-wheel drive or four-wheel drive?
The Fahr D 130 is two-wheel drive (2WD).
What PTO does a D 130 have?
A D 130 has a 588 rpm rear PTO on a 29 x 34,9 x 8,7 mm shaft.
Sources and how this page was built
Compiled from Traktorenlexikon, “Fahr D 131 L”; and Traktorenlexikon, “Fahr D 130”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- Traktorenlexikon: Fahr D 130 — CC BY-SA 4.0, WIKIBOOKS-TL-46964 · revision 990493. Wikibooks contributors (Traktorenlexikon). Original document
- Traktorenlexikon: Fahr D 131 L — CC BY-SA 4.0, WIKIBOOKS-TL-43364 · revision 1043101. Wikibooks contributors (Traktorenlexikon). Original document
