- Rigid chassis
- WhichTractor size: Utility
- No lab test on file
- 1953–1955
- 2,226 built
WhichTractor size, not the maker’s category
The source says so, in a sentence about this machine. How we decide what a machine is
Fahr D 17N specs: hp, weight, years
Güldner 2 DN two-cylinder diesel. The manufacturer claimed 16.8 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
16.8 hp
12.5 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Fahr D 17 N”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 2,712 lb
- Top speed
- 11.3 mph
Fahr D 17N specs: key facts
The Fahr D 17N was built from 1953 to 1955.
The Fahr D 17N has a claimed engine power (gross or net not stated) of 12.5 kW (16.8 hp); it has no measured PTO figure.
The Fahr D 17N is two-wheel drive (2WD).
The Fahr D 17N has a Güldner 2 DN engine, a 2-cylinder 1.30 L diesel unit.Source 2
The Fahr D 17N weighs 1,230 kg (2,712 lb) unladen.
The Fahr D 17N has a rear PTO running at 540 rpm.
Source · Traktorenlexikon, “Fahr D 17 N”
How much horsepower does a D 17N have?
The only figure for the D 17N is 16.8 hp (12.5 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Fahr D 17 N”
What engine is in a D 17N?
A D 17N has a Güldner 2 DN, a 2-cylinder 1.30 L diesel engine.
| Make & model | Güldner 2 DNSource 2 |
|---|---|
| Cylinders | 2, liquid-cooledSource 2 |
| Displacement | 79.6 ci · 1.30 LSource 2 |
| Max torque | 51 lb·ft · 69 N·m @ 1,610 rpm |
| Injection | Bosch injection pump |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Fahr D 17 N”
How much will a D 17N lift?
Hydraulic and PTO specifications for the D 17N are below.
| Pressure | 3,129 psi · 216 bar |
|---|---|
| Rear PTO | 540 rpm |
Source · Traktorenlexikon, “Fahr D 17 N”
What transmission does a D 17N have?
Transmission specifications for the D 17N are below.
| Clutch | Pedal operated dry Fichtel & Sachs single disc clutch |
|---|---|
| Steering | ZF steering with independent wheel steering |
| Top speed | 11.3 mph · 18.2 km/h |
Source · Traktorenlexikon, “Fahr D 17 N”
How much does a D 17N weigh?
A D 17N weighs 2,712 lb (1,230 kg) unladen.
| Unladen weight | 2,712 lb · 1,230 kg |
|---|---|
| Maximum permissible mass | 4,189 lb · 1,900 kg |
| Maximum front axle load | 1,653 lb · 750 kg |
| Maximum rear axle load | 2,535 lb · 1,150 kg |
| Wheelbase | 64.6 in · 1,640 mm |
| Length | 101.6 in · 2,580 mm |
| Width | 61.5 in · 1,562 mm |
| Height | 58.1 in · 1,475 mm |
| Ground clearance | 16.1 in · 410 mm |
| Front track | 49.2–59.1 in · 1,250–1,500 mmWikibooks gives one track for both axles |
| Rear track | 49.2–59.1 in · 1,250–1,500 mmWikibooks gives one track for both axles |
| Turning radius, braked | 8.0 ft · 2.45 m |
Source · Traktorenlexikon, “Fahr D 17 N”
What oil does a D 17N take, and how much?
A D 17N engine takes 5.3 qt (5 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 5.3 qt · 5 LSource: Traktorenlexikon, “Fahr D 17 N” · single source, not independently verified |
| Transmission | 0.3 qt · 0 LSource: Traktorenlexikon, “Fahr D 17 N” · single source, not independently verified |
| Hydraulic | 8.5 qt · 8 LSource: Traktorenlexikon, “Fahr D 17 N” · single source, not independently verified |
| Cooling system | 9.5 qt · 9 LSource: Traktorenlexikon, “Fahr D 17 N” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a D 17N?
Within 10% of its 17 hp at the PTO as the maker claimed it, with no laboratory test on file, the same type, and first built within 15 years of it.
- Fahr D 17 NA17 hp PTO, claimed · 1953–1955Side by side with the D 17N →
- Fahr D 17 NH17 hp PTO, claimed · 1953–1955Side by side with the D 17N →
- Fahr D 17 NHA17 hp PTO, claimed · 1953–1955Side by side with the D 17N →
- Fahr D 13017 hp PTO, claimed · 1954–1957Side by side with the D 17N →
- Fahr D 130H17 hp PTO, claimed · 1954–1957Side by side with the D 17N →
- Kramer KA 1717 hp PTO, claimed · 1956Side by side with the D 17N →
Common questions about the Fahr D 17N
Is a D 17N two-wheel drive or four-wheel drive?
The Fahr D 17N is two-wheel drive (2WD).
What PTO does a D 17N have?
A D 17N has a 540 rpm rear PTO.
Sources and how this page was built
Compiled from Traktorenlexikon, “MAN AS 718 A”; and Traktorenlexikon, “Fahr D 17 N”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- Traktorenlexikon: Fahr D 17 N — CC BY-SA 4.0, WIKIBOOKS-TL-49060 · revision 1044886. Wikibooks contributors (Traktorenlexikon). Original document
- Traktorenlexikon: MAN AS 718 A — CC BY-SA 4.0, WIKIBOOKS-TL-46600 · revision 1004306. Wikibooks contributors (Traktorenlexikon). Original document
