- Articulated
- WhichTractor size: High-power
- No lab test on file
- 1990–1995
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Case-IH 9250 specs: hp, weight, years
CUMMINS LTA-10 six-cylinder diesel. The manufacturer claimed 296.0 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
296.0 hp
220.7 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Case-IH 9250”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 30,060 lb
- 3-point lift
- 14,074 lb
- Hyd. flow
- 27.8 gpm
- Top speed
- 18.6 mph
Case-IH 9250 specs: key facts
The Case-IH 9250 was built from 1990 to 1995.
The Case-IH 9250 has a claimed engine power (gross or net not stated) of 220.7 kW (296.0 hp); it has no measured PTO figure.
The Case-IH 9250 is four-wheel drive (4WD).
The Case-IH 9250 has a CUMMINS LTA-10 engine, a 6-cylinder 10.01 L diesel unit.
The Case-IH 9250 weighs 13,635 kg (30,060 lb) unladen.
The Case-IH 9250 has a rear PTO running at 1000 rpm.
The three-point hitch of the Case-IH 9250 lifts 6,384 kg (14,074 lb) at the lower-link ends.
The hydraulic pump of the Case-IH 9250 delivers 105.2 L/min (27.8 gpm).
Source · Traktorenlexikon, “Case-IH 9250”
How does the 9250 compare with its class?
- Limitation:
Twelve forward gears is low for its class — 25% below the median of 16 across the 37 machines within 10% of its power that hold this figure.
- Limitation:
The power figure is a manufacturer claim, not a measurement. No laboratory test report exists for this machine. Of the 44 tractors within 10% of its power, 32% carry one.
Derived by WhichTractor from 44 comparable records. How we work this out
How much horsepower does a 9250 have?
The only figure for the 9250 is 296.0 hp (220.7 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Case-IH 9250”
What engine is in a 9250?
A 9250 has a CUMMINS LTA-10, a 6-cylinder 10.01 L diesel engine.
| Make & model | CUMMINS LTA-10 |
|---|---|
| Cylinders | 6, liquid-cooled |
| Displacement | 611.1 ci · 10.01 L |
| Max torque | 977 lb·ft · 1,324 N·m @ 1,290 rpm |
| Injection | Direct injection |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Case-IH 9250”
How much will a 9250 lift, and what is its hydraulic flow?
A 9250 lifts 14,074 lb (6,384 kg) at the lower-link ends of its Category 3 three-point hitch.
| Pump flow | 27.8 gpm · 105.2 L/min |
|---|---|
| Pressure | 2,306 psi · 159 bar |
| Hitch category | Category 3 |
| Lift at ends | 14,074 lb · 6,384 kg |
| Rear PTO | 1000 rpm |
| PTO shaft | 1 3/4"- 20 splined |
Source · Traktorenlexikon, “Case-IH 9250”
What transmission does a 9250 have?
Transmission specifications for the 9250 are below.
| Clutch | Oil-immersed multi-plate clutch |
|---|---|
| Brakes | Pedal-operated, hydraulic dry disc brake acting on front axle differential |
| Steering | Hydrostatic Eaton steering |
| Top speed | 18.6 mph · 30 km/h |
Source · Traktorenlexikon, “Case-IH 9250”
How much does a 9250 weigh?
A 9250 weighs 30,060 lb (13,635 kg) unladen.
| Unladen weight | 30,060 lb · 13,635 kg |
|---|---|
| Wheelbase | 130.0 in · 3,302 mm |
| Length | 264.0 in · 6,706 mm |
| Width | 119.5–148.3 in · 3,035–3,767 mm |
| Height | 139.1 in · 3,532 mm |
| Ground clearance | 14.8 in · 377 mm |
| Front track | 60.0–130.0 in · 1,524–3,302 mmWikibooks gives one track for both axles |
| Rear track | 60.0–130.0 in · 1,524–3,302 mmWikibooks gives one track for both axles |
Source · Traktorenlexikon, “Case-IH 9250”
What oil does a 9250 take, and how much?
A 9250 engine takes 35.9 qt (34.0 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 35.9 qt · 34.0 LSource: Traktorenlexikon, “Case-IH 9250” · single source, not independently verified |
| Transmission | 35.9 qt · 34.0 LSource: Traktorenlexikon, “Case-IH 9250” · single source, not independently verified |
| Hydraulic | 72.0 qt · 68.1 LSource: Traktorenlexikon, “Case-IH 9250” · single source, not independently verified |
| Cooling system | 54.0 qt · 51.1 LSource: Traktorenlexikon, “Case-IH 9250” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a 9250?
Within 10% of its 296.0 hp of claimed engine power, the same type, and first built within 15 years of it.
- John Deere 8760296.1 hp engine, claimed · 1989–1993Side by side with the 9250 →
- Ford FW-40295 hp engine, claimed · 1977–1982Side by side with the 9250 →
- Case-IH 9350306 hp engine, claimed · 1995–2000Side by side with the 9250 →
- New Holland 9482306 hp engine, claimed · 1995–1999Side by side with the 9250 →
- Ford 876280.1 hp engine, claimed · 1988–1993Side by side with the 9250 →
- Case-IH 9150276.1 hp engine, claimed · 1987–1990Side by side with the 9250 →
Common questions about the Case-IH 9250
Is a 9250 two-wheel drive or four-wheel drive?
The Case-IH 9250 is four-wheel drive (4WD).
What PTO does a 9250 have?
A 9250 has a 1000 rpm rear PTO on a 1 3/4"- 20 splined shaft.
