- Rigid chassis
- WhichTractor size: Compact
- No lab test on file
- 1988–2009
It was ranked on an engine power figure whose source does not say gross or net. WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
URSUS 2812 specs: hp, weight, years
URSUS 3250 three-cylinder diesel. The manufacturer claimed 37.4 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
37.4 hp
27.9 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Ursus 2812”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 4,453 lb
- 3-point lift
- 3,012 lb
- Hyd. flow
- 5.0 gpm
- Top speed
- 15.5 mph
URSUS 2812 specs: key facts
The URSUS 2812 was built from 1988 to 2009.
The URSUS 2812 has a claimed engine power (gross or net not stated) of 27.9 kW (37.4 hp); it has no measured PTO figure.
The URSUS 2812 is two-wheel drive (2WD).
The URSUS 2812 has a URSUS 3250 engine, a 3-cylinder 2.50 L diesel unit.
The URSUS 2812 weighs 2,020 kg (4,453 lb) unladen.
The URSUS 2812 has a rear PTO running at 540 rpm.
The three-point hitch of the URSUS 2812 lifts 1,366 kg (3,012 lb) at the lower-link ends.
The hydraulic pump of the URSUS 2812 delivers 18.8 L/min (5.0 gpm).
Source · Traktorenlexikon, “Ursus 2812”
How much horsepower does a 2812 have?
The only figure for the 2812 is 37.4 hp (27.9 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Ursus 2812”
What engine is in a 2812?
A 2812 has a URSUS 3250, a 3-cylinder 2.50 L diesel engine.
| Make & model | URSUS 3250 |
|---|---|
| Cylinders | 3, liquid-cooled |
| Displacement | 152.7 ci · 2.50 L |
| Max torque | 114 lb·ft · 155 N·m @ 1,215 rpm |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Ursus 2812”
How much will a 2812 lift, and what is its hydraulic flow?
A 2812 lifts 3,012 lb (1,366 kg) at the lower-link ends of its Category 2 three-point hitch.
| Pump flow | 5.0 gpm · 18.8 L/min |
|---|---|
| Pressure | 3,002 psi · 207 bar |
| Hitch category | Category 2 |
| Lift at ends | 3,012 lb · 1,366 kg |
| Rear PTO | 540 rpm @ 1,788 engine rpm |
Source · Traktorenlexikon, “Ursus 2812”
What transmission does a 2812 have?
Transmission specifications for the 2812 are below.
| Steering | Mechanical recirculating ball steering |
|---|---|
| Top speed | 15.5 mph · 25 km/h |
Source · Traktorenlexikon, “Ursus 2812”
How much does a 2812 weigh?
A 2812 weighs 4,453 lb (2,020 kg) unladen.
| Unladen weight | 4,453 lb · 2,020 kg |
|---|---|
| Wheelbase | 76.0 in · 1,930 mm |
| Length | 126.0 in · 3,200 mm |
| Width | 66.5–90.2 in · 1,690–2,290 mm |
| Height | 88.2 in · 2,240 mm |
| Ground clearance | 11.2 in · 285 mm |
| Front track | 53.1–70.9 in · 1,350–1,800 mm |
| Rear track | 53.1–76.8 in · 1,350–1,950 mm |
| Turning radius, braked | 10.8 ft · 3.30 m |
Source · Traktorenlexikon, “Ursus 2812”
What oil does a 2812 take, and how much?
A 2812 engine takes 7.2 qt (6.8 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 7.2 qt · 6.8 LSource: Traktorenlexikon, “Ursus 2812” · single source, not independently verified |
| Hydraulic | 33.8 qt · 32.0 LSource: Traktorenlexikon, “Ursus 2812” · single source, not independently verified |
| Cooling system | 10.8 qt · 10.2 LSource: Traktorenlexikon, “Ursus 2812” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a 2812?
Within 10% of its 37.4 hp of claimed engine power, the same type, and first built within 15 years of it.
- Ford 2110 (A)37.4 hp engine, claimed · 1983–1987Side by side with the 2812 →
- Ford 260037.4 hp engine, claimed · 1975–1981Side by side with the 2812 →
- Massey Ferguson 23338 hp engine, claimed · 1983–1987Side by side with the 2812 →
- Ford 3230 (A)36.5 hp engine, claimed · 1990–1994Side by side with the 2812 →
- IMT 53938.5 hp engine, claimed · 1980–1990Side by side with the 2812 →
- New Holland 323538.5 hp engine, claimed · 1996–1999Side by side with the 2812 →
Common questions about the URSUS 2812
Is a 2812 two-wheel drive or four-wheel drive?
The URSUS 2812 is two-wheel drive (2WD).
What PTO does a 2812 have?
A 2812 has a 540 rpm rear PTO.
Sources and how this page was built
Compiled from Traktorenlexikon, “Ursus 2812”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- Traktorenlexikon: Ursus 2812 — CC BY-SA 4.0, WIKIBOOKS-TL-103457 · revision 1053002. Wikibooks contributors (Traktorenlexikon). Original document
