- Rigid chassis
- WhichTractor size: Utility
- Lab tested ×2
- 2003–2006
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
John Deere 6120 specs: hp, weight, years
John Deere PowrTech 4.045 TL-070 four-cylinder diesel or John Deere 4045TL054 or John Deere 4045TL070. The manufacturer claimed 79.0 horsepower. The only laboratory test on record is of one version: OECD Test 1821 measured 78.6 hp at the PTO of the 6120 (4 WD); OECD Test 2028 measured 72.3 hp at the PTO of the 6120 (4 WD). Compared at the engine's rated speed, where the brochure figure is quoted, the shaft gave 74.7 hp — 5.4% below the claim.
Engine power, claimed · gross or net not stated
79.0 hp
58.9 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “John Deere 6120”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 9,513 lb
- 3-point lift
- 10,251 lb
- Top speed
- 24.9 mph
John Deere 6120 specs: key facts
The John Deere 6120 was built from 2003 to 2006.
Only one version of the John Deere 6120 has a laboratory test on record: the 6120 (4 WD) produced 58.6 kW (78.6 hp) at the PTO, measured on OECD Test 1821; the 6120 (4 WD) produced 53.9 kW (72.3 hp) at the PTO, measured on OECD Test 2028.Source 1,Source 2
The John Deere 6120 has a claimed engine power (gross or net not stated) of 58.9 kW (79.0 hp); it has no measured PTO figure.
The John Deere 6120 is four-wheel drive (4WD).Source 1,Source 2
The John Deere 6120 has a John Deere PowrTech 4.045 TL-070 engine, a 4-cylinder 4.53 L diesel unit.
The John Deere 6120 weighs 4,315 kg (9,513 lb) unladen.
The John Deere 6120 has a rear PTO running at 540/1000 rpm.Source 1
The three-point hitch of the John Deere 6120 lifts 4,650 kg (10,251 lb) at the lower-link ends.
Source · Traktorenlexikon, “John Deere 6120”
How does the 6120 compare with its class?
- Strength:
A three-point lift at the lower links of 4,650 kg is high for its class — 48% above the median of 3,136 kg across the 270 machines within 10% of its power that hold this figure.
- Strength:
A 165 L fuel tank is high for its class — 68% above the median of 98.1 L across the 330 machines within 10% of its power that hold this figure.
- Worth knowing:
An unladen mass of 4,315 kg is high for its class — 30% above the median of 3,325 kg across the 355 machines within 10% of its power that hold this figure.
Derived by WhichTractor from 356 comparable records. How we work this out
How much horsepower does a 6120 have?
The only laboratory test on record is of one version. OECD Test 1821 measured 78.6 hp at the PTO of the 6120 (4 WD); OECD Test 2028 measured 72.3 hp at the PTO of the 6120 (4 WD). For the 6120 as a whole the figure is the 79.0 hp claimed for the engine, which is not power at the shaft.
Sources · Traktorenlexikon, “John Deere 6120”; OECD test report 1821, 1999; OECD test report 2028, 2002
What engine is in a 6120?
A 6120 has a John Deere PowrTech 4.045 TL-070, a 4-cylinder 4.53 L diesel engine. 6120 (4 WD) tractors have a John Deere 4045TL054. 6120 (4 WD) tractors have a John Deere 4045TL070.
| Make & model | John Deere PowrTech 4.045 TL-070 |
|---|---|
| Cylinders | 4, liquid-cooled |
| Displacement | 276.1 ci · 4.53 L |
| Max torque | 232 lb·ft · 314 N·m @ 1,399 rpmSource 1 |
| Electrical system | 12 V |
Source · Traktorenlexikon, “John Deere 6120”
How much will a 6120 lift?
A 6120 lifts 10,251 lb (4,650 kg) at the lower-link ends.
| System | Closed centre, load sensingSource 3 |
|---|---|
| Lift at ends | 10,251 lb · 4,650 kgSource 3 |
| Rear PTO | 540/1000 rpm |
| PTO shaft | 35 mm, 6 splines / 35 mm, 21 splines |
Source · OECD test report 1821, 1999
What transmission does a 6120 have?
Transmission specifications for the 6120 are below.
| Steering | Hydrostatic DANFOSS steering |
|---|---|
| Top speed | 24.9 mph · 40 km/h |
Source · Traktorenlexikon, “John Deere 6120”
How much does a 6120 weigh?
A 6120 weighs 9,513 lb (4,315 kg) unladen.
| Unladen weight | 9,513 lb · 4,315 kg |
|---|---|
| Maximum permissible mass | 15,432 lb · 7,000 kg |
| Wheelbase | 94.5 in · 2,400 mm |
| Length | 168.4 in · 4,278 mm |
| Width | 85.7 in · 2,178 mm |
| Height | 104.3 in · 2,648 mm |
| Ground clearance | 19.3 in · 490 mm |
| Front track | 59.8–79.1 in · 1,520–2,010 mm |
| Rear track | 63.6–75.3 in · 1,616–1,912 mm |
Source · Traktorenlexikon, “John Deere 6120”
What oil does a 6120 take, and how much?
A 6120 engine takes 16.9 qt (16.0 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 16.9 qt · 16.0 LSource: Traktorenlexikon, “John Deere 6120” · single source, not independently verified |
| Transmission | 56.0 qt · 53.0 LSource: Traktorenlexikon, “John Deere 6120” · single source, not independently verified |
| Front axle | 5.3 qt · 5.0 LSource: Traktorenlexikon, “John Deere 6120” · single source, not independently verified |
| Cooling system | 25.4 qt · 24.0 LSource: Traktorenlexikon, “John Deere 6120” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
How much fuel does a 6120 burn per hour?
Measured on OECD Test 1821 (tested as the 6120 (4 WD)), at each condition the laboratory recorded.
1 other test of this model is on record; figures differ between configurations.
Cost per hour = fuel used per hour × your fuel price (per litre, or per US gallon for the gal/h figure).
| Test condition | Fuel per hour |
|---|---|
| Maximum PTO powerPTO 58.6 kW (78.6 hp) at 861 rpm | 17.08 L/h 4.51 gal/h |
| Rated engine speedPTO 55.7 kW (74.7 hp) at 1,042 rpm | 18.19 L/h 4.81 gal/h |
| Standard PTO speedPTO 56.7 kW (76.0 hp) at 1,000 rpm | 17.98 L/h 4.75 gal/h |
| 75% load, 50% load | Not on record for this test |
Source · OECD Test 1821
Which tractors compare with a 6120?
Within 10% of its 79.0 hp of claimed engine power, the same type, and first built within 15 years of it.
- Hürlimann XN-70879.0 hp engine, claimed · 1999–2003Side by side with the 6120 →
- Deutz-Fahr Agrocompact 80 V/F79.0 hp engine, claimed · 1998–2004Side by side with the 6120 →
- Fiat TS 9079.0 hp engine, claimed · 1997–2003Side by side with the 6120 →
- New Holland TS 90 (A)79.0 hp engine, claimed · 1997–2003Side by side with the 6120 →
- Massey Ferguson 542079.0 hp engine, claimed · 2011–2013Side by side with the 6120 →
- Massey Ferguson 6120 (A)79.0 hp engine, claimed · 1995–1999Side by side with the 6120 →
Common questions about the John Deere 6120
Is a 6120 two-wheel drive or four-wheel drive?
The John Deere 6120 is four-wheel drive (4WD).
What PTO does a 6120 have?
A 6120 has a 540/1000 rpm rear PTO on a 35 mm, 6 splines / 35 mm, 21 splines shaft.
Sources and how this page was built
Compiled from OECD tractor test reports 1821 and 2028; and Traktorenlexikon, “John Deere 6120”.
