- Rigid chassis
- WhichTractor size: Utility
- Lab tested ×1
- 1999–2003
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Hürlimann XN-708 specs: hp, weight, years
Hürlimann 1000.4 W-3 four-cylinder diesel or Same Deutz-Fahr Group 1000.4W3. The manufacturer claimed 79.0 horsepower. The only laboratory test on record is of one version: OECD Test 1812 measured 73.8 hp at the PTO of the XN 708 (4 WD). Compared at the engine's rated speed, where the brochure figure is quoted, the shaft gave 73.8 hp — 6.6% below the claim.
Engine power, claimed · gross or net not stated
79.0 hp
58.9 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Hürlimann XN 708”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 5,556 lb
- Hyd. flow
- 8.9 gpm
- Top speed
- 18.6 mph
Hürlimann XN-708 specs: key facts
The Hürlimann XN-708 was built from 1999 to 2003.
Only one version of the Hürlimann XN-708 has a laboratory test on record: the XN 708 (4 WD) produced 55.0 kW (73.8 hp) at the PTO, measured on OECD Test 1812.Source 1
The Hürlimann XN-708 has a claimed engine power (gross or net not stated) of 58.9 kW (79.0 hp); it has no measured PTO figure.
The Hürlimann XN-708 is four-wheel drive (4WD).Source 1
The Hürlimann XN-708 has a Hürlimann 1000.4 W-3 engine, a 4-cylinder 4.00 L diesel unit.
The Hürlimann XN-708 weighs 2,520 kg (5,556 lb) unladen.
The Hürlimann XN-708 has a rear PTO running at 540 rpm / 1000 rpm.
The hydraulic pump of the Hürlimann XN-708 delivers 33.7 L/min (8.9 gpm).
Source · Traktorenlexikon, “Hürlimann XN 708”
How does the XN-708 compare with its class?
- Strength:
45 forward gears is high for its class — 275% above the median of 12 across the 348 machines within 10% of its power that hold this figure.
- Limitation:
A 58 L fuel tank is low for its class — 41% below the median of 99.1 L across the 330 machines within 10% of its power that hold this figure.
- Worth knowing:
An unladen mass of 2,520 kg is low for its class — 24% below the median of 3,330 kg across the 355 machines within 10% of its power that hold this figure.
Derived by WhichTractor from 356 comparable records. How we work this out

How much horsepower does a XN-708 have?
The only laboratory test on record is of one version. OECD Test 1812 measured 73.8 hp at the PTO of the XN 708 (4 WD). For the XN-708 as a whole the figure is the 79.0 hp claimed for the engine, which is not power at the shaft.
Sources · Traktorenlexikon, “Hürlimann XN 708”; OECD test report 1812, 1999
What engine is in a XN-708?
A XN-708 has a Hürlimann 1000.4 W-3, a 4-cylinder 4.00 L diesel engine. XN 708 (4 WD) tractors have a Same Deutz-Fahr Group 1000.4W3.
| Make & model | Hürlimann 1000.4 W-3 |
|---|---|
| Cylinders | 4, liquid-cooled |
| Displacement | 244.1 ci · 4.00 L |
| Max torque | 184 lb·ft · 250 N·m @ 1,456 rpm |
| Injection | direct injection |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Hürlimann XN 708”
How much will a XN-708 lift, and what is its hydraulic flow?
Hydraulic and PTO specifications for the XN-708 are below.
| System | Load sensing |
|---|---|
| Pump flow | 8.9 gpm · 33.7 L/min |
| Hitch category | Category 2 |
| Rear PTO | 540 rpm / 1000 rpm @ 2,077 engine rpm |
| PTO shaft | 1 3/8"- 6 splines |
Source · Traktorenlexikon, “Hürlimann XN 708”
What transmission does a XN-708 have?
Transmission specifications for the XN-708 are below.
| Clutch | Pedal-operated dry SDF single disc clutch |
|---|---|
| Brakes | Hydraulically operated wet SLH disc brake acting on differential side shafts |
| Steering | Hydrostatic Danfoss steering |
| Top speed | 18.6 mph · 30 km/h |
Source · Traktorenlexikon, “Hürlimann XN 708”
How much does a XN-708 weigh?
A XN-708 weighs 5,556 lb (2,520 kg) unladen.
| Unladen weight | 5,556 lb · 2,520 kg |
|---|---|
| Wheelbase | 80.9 in · 2,056 mm |
| Length | 140.2 in · 3,561 mm |
| Width | 50.8–64.6 in · 1,290–1,640 mm |
| Height | 83.1 in · 2,110 mm |
| Ground clearance | 9.1 in · 230 mm |
| Front track | 40.2–49.8 in · 1,020–1,265 mm |
| Rear track | 35.0–50.8 in · 890–1,290 mm |
| Turning radius, braked | 13.7 ft · 4.17 m |
Source · Traktorenlexikon, “Hürlimann XN 708”
What oil does a XN-708 take, and how much?
A XN-708 engine takes 11.6 qt (11.0 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 11.6 qt · 11.0 LSource: Traktorenlexikon, “Hürlimann XN 708” · single source, not independently verified |
| Transmission & hydraulic | 43.3 qt · 41.0 LSource: Traktorenlexikon, “Hürlimann XN 708” · single source, not independently verified |
| Front axle | 6.3 qt · 6.0 LSource: Traktorenlexikon, “Hürlimann XN 708” · single source, not independently verified |
| Final drives | 3.2 qt · 3.0 LSource: Traktorenlexikon, “Hürlimann XN 708” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
How much fuel does a XN-708 burn per hour?
Measured on OECD Test 1812 (tested as the XN 708 (4 WD)), at each condition the laboratory recorded.
Cost per hour = fuel used per hour × your fuel price (per litre, or per US gallon for the gal/h figure).
| Test condition | Fuel per hour |
|---|---|
| Maximum PTO powerPTO 55.0 kW (73.8 hp) at 1,022 rpm | 17.65 L/h 4.66 gal/h |
| Rated engine speedPTO 55.0 kW (73.8 hp) at 1,022 rpm | 17.65 L/h 4.66 gal/h |
| Standard PTO speedPTO 54.2 kW (72.7 hp) at 1,000 rpm | 17.29 L/h 4.57 gal/h |
| 75% load, 50% load | Not on record for this test |
Source · OECD Test 1812
Which tractors compare with a XN-708?
Within 10% of its 79.0 hp of claimed engine power, the same type, and first built within 15 years of it.
- Deutz-Fahr Agrocompact 80 V/F79.0 hp engine, claimed · 1998–2004Side by side with the XN-708 →
- Fiat TS 9079.0 hp engine, claimed · 1997–2003Side by side with the XN-708 →
- New Holland TS 90 (A)79.0 hp engine, claimed · 1997–2003Side by side with the XN-708 →
- John Deere 612079.0 hp engine, claimed · 2003–2006Side by side with the XN-708 →
- Massey Ferguson 6120 (A)79.0 hp engine, claimed · 1995–1999Side by side with the XN-708 →
- Fiat 80-66S/80-66 DTS79.0 hp engine, claimed · 1992–1996Side by side with the XN-708 →
Common questions about the Hürlimann XN-708
Is a XN-708 two-wheel drive or four-wheel drive?
The Hürlimann XN-708 is four-wheel drive (4WD).
What PTO does a XN-708 have?
A XN-708 has a 540 rpm / 1000 rpm rear PTO on a 1 3/8"- 6 splines shaft.
Sources and how this page was built
Compiled from OECD tractor test report 1812; and Traktorenlexikon, “Hürlimann XN 708”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- OECD Code 2 test report 1/1 812: Hürlimann XN 708 — Licence not stated by the publisher; facts cited, OECD-1812 · published 1999-03-12 · retrieved 2026-09-14. OECD; testing station ISMA, Treviglio, Italy. Original document
- Traktorenlexikon: Hürlimann XN 708 — CC BY-SA 4.0, WIKIBOOKS-TL-105311 · revision 864829. Wikibooks contributors (Traktorenlexikon). Original document
