- WhichTractor size: Utility
- No lab test on file
- 1956–1960
- 4,754 built
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Fahr D 88 specs: hp, weight, years
Güldner 2 LKN diesel. Claimed engine power varies by configuration. No laboratory has tested one, so there is no measured figure at the shaft.
- Weight
- 1,907 lb
- Top speed
- 15.5 mph
Fahr D 88 specs: key facts
The Fahr D 88 was built from 1956 to 1960.
The claimed engine power (gross or net not stated) of the Fahr D 88 is 11–11 kW (15–15 hp), depending on configuration.Source 2
The Fahr D 88 is two-wheel drive (2WD).Source 2
The Fahr D 88 weighs 865 kg (1,907 lb) unladen.
The Fahr D 88 has a dependent rear PTO running at 568 rpm.Source 2
Source · Traktorenlexikon, “Fahr D 88”
.jpg){kind=link}
How much horsepower does a D 88 have?
No independent test of the D 88 is on record. The only figures are claimed engine power of 15–15 hp (11–11 kW), varying by configuration, which is not power at the shaft.
Source · Traktorenlexikon, “Fahr D 88 E”
How much will a D 88 lift?
Hydraulic and PTO specifications for the D 88 are below.
| Pressure | 1,707 psi · 118 bar |
|---|---|
| Rear PTO | Dependent, transmission-driven |
| PTO shaft | 29 x 34,9 x 8,7 mmSource 2On record for 1 of 2 configurations |
Source · Traktorenlexikon, “Fahr D 88”
What transmission does a D 88 have?
Transmission specifications for the D 88 are below.
| Clutch | Pedal operated dry Fichtel & Sachs single-plate clutchOn record for 1 of 2 configurations |
|---|---|
| Brakes | Pedal operated combined hand and service brake as drum brakeOn record for 1 of 2 configurations |
| Steering | ZF Ross steeringOn record for 1 of 2 configurations |
| Top speed | 15.5 mph · 25 km/hSource 1 |
Source · Traktorenlexikon, “Fahr D 88 E”
How much does a D 88 weigh?
A D 88 weighs 1,907 lb (865 kg) unladen.
| Unladen weight | 1,907 lb · 865 kg |
|---|---|
| Maximum permissible mass | 2,976 lb · 1,350 kgSource 2On record for 1 of 2 configurations |
| Maximum front axle load | 1,102 lb · 500 kgSource 2On record for 1 of 2 configurations |
| Maximum rear axle load | 2,094 lb · 950 kgSource 2On record for 1 of 2 configurations |
| Wheelbase | 65.0 in · 1,650 mm |
| Length | 104.5 in · 2,655 mm |
| Width | 57.9 in · 1,470 mm |
| Height | 59.1 in · 1,500 mm |
| Ground clearance | 13.8 in · 350 mm |
| Front track | 49.2–59.1 in · 1,250–1,500 mmWikibooks gives one track for both axles; the article lists alternatives |
| Rear track | 49.2–59.1 in · 1,250–1,500 mmWikibooks gives one track for both axles; the article lists alternatives |
| Turning radius, braked | 8.6 ft · 2.63 m |
Source · Traktorenlexikon, “Fahr D 88”
What oil does a D 88 take, and how much?
A D 88 engine takes 4.0 qt (3.8 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 4.0 qt · 3.8 LSource: Traktorenlexikon, “Fahr D 88” · single source, not independently verified |
| Transmission | 7.9 qt · 7.5 LSource: Traktorenlexikon, “Fahr D 88” · single source, not independently verified |
| Hydraulic | 2.6 qt · 2.5 LSource: Traktorenlexikon, “Fahr D 88” · single source, not independently verified |
| Final drives | 1.4 qt · 1.3 LSource: Traktorenlexikon, “Fahr D 88” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a D 88?
Within 10% of its 15.0 hp at the PTO as the maker claimed it, with no laboratory test on file, the same type, and first built within 15 years of it.
- Güldner A 2 KS Spessart15.0 hp PTO, claimed · 1958–1965Side by side with the D 88 →
- Güldner G 1515.0 hp PTO, claimed · 1965Side by side with the D 88 →
- Güldner ADN15 hp PTO, claimed · 1953–1959Side by side with the D 88 →
- Steyr 8614.6 hp PTO, claimed · 1964–1968Side by side with the D 88 →
- Fahr D 1716 hp PTO, claimed · 1951–1953Side by side with the D 88 →
- Fahr D 17H16 hp PTO, claimed · 1951–1953Side by side with the D 88 →
Common questions about the Fahr D 88
Is a D 88 two-wheel drive or four-wheel drive?
The Fahr D 88 is two-wheel drive (2WD).
Sources and how this page was built
Compiled from Traktorenlexikon, “Güldner A 2 KS Spessart”; Traktorenlexikon, “Fahr D 88”; and Traktorenlexikon, “Fahr D 88 E”.
