- Vehicle type: unspecified
- WhichTractor size: Standard-size
- No lab test on file
- 1968–1970
- 5,500 built
It was ranked on an engine power figure whose source does not say gross or net. WhichTractor size, not the maker’s category
We looked and the record does not say what this machine is. How we decide what a machine is
Deutz D 9006 specs: hp, weight, years
KHD F6L 912 six-cylinder diesel. The manufacturer claimed 90.3 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
90.3 hp
67.3 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Deutz D 9006”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 8,058 lb
- Hyd. flow
- 9.2 gpm
- Top speed
- 18.6 mph
Deutz D 9006 specs: key facts
The Deutz D 9006 was built from 1968 to 1970.
The Deutz D 9006 has a claimed engine power (gross or net not stated) of 67.3 kW (90.3 hp); it has no measured PTO figure.
The Deutz D 9006 was offered in two-wheel-drive and four-wheel-drive versions.
The Deutz D 9006 has a KHD F6L 912 engine, a 6-cylinder 5.65 L diesel unit.Source 2
The Deutz D 9006 weighs 3,655 kg (8,058 lb) unladen.
The Deutz D 9006 has an independent rear PTO running at 540/1000 rpm.
The hydraulic pump of the Deutz D 9006 delivers 34.7 L/min (9.2 gpm).
Source · Traktorenlexikon, “Deutz D 9006”
How does the Deutz D 9006 compare with its class?
- Limitation:
Eight forward gears is low for its class — 47% below the median of 15 across the 378 machines within 10% of its power that hold this figure.
Derived by WhichTractor from 389 comparable records. How we work this out
How much horsepower does a Deutz D 9006 have?
The only figure for the Deutz D 9006 is 90.3 hp (67.3 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Deutz D 9006”
What engine is in a Deutz D 9006?
A Deutz D 9006 has a KHD F6L 912, a 6-cylinder 5.65 L diesel engine.
| Make & model | KHD F6L 912Source 2 |
|---|---|
| Cylinders | 6, air-cooledSource 2 |
| Displacement | 344.9 ci · 5.65 LSource 2 |
| Max torque | 236 lb·ft · 320 N·m @ 1,200 rpm |
| Injection | Direct injection method with Bosch distributor injection pump |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Deutz D 9006”
How much will a Deutz D 9006 lift, and what is its hydraulic flow?
Hydraulic and PTO specifications for the Deutz D 9006 are below.
| Pump flow | 9.2 gpm · 34.7 L/min |
|---|---|
| Rear PTO | Independent, engine-driven, 540/1000 rpm |
| PTO shaft | 29 x 34,9 x 8,7 mm (Form-A) |
Source · Traktorenlexikon, “Deutz D 9006”
What transmission does a Deutz D 9006 have?
Transmission specifications for the Deutz D 9006 are below.
| Clutch | Dry Walterscheid double clutch operated by two-stage pedal |
|---|---|
| Brakes | Pedal operated servo internal shoe brake acting via planetary drive |
| Steering | Mechanical ZF Gemmer steering |
| Top speed | 18.6 mph · 30 km/h |
Source · Traktorenlexikon, “Deutz D 9006”
How much does a Deutz D 9006 weigh?
A Deutz D 9006 weighs 8,058 lb (3,655 kg) unladen.
| Unladen weight | 8,058 lb · 3,655 kgtwo-wheel-drive version |
|---|---|
| Wheelbase | 100.4 in · 2,550 mm |
| Length | 165.7 in · 4,210 mm |
| Width | 81.7 in · 2,075 mmtwo-wheel-drive version |
| Height | 94.5 in · 2,400 mm |
| Ground clearance | 22.2 in · 565 mmtwo-wheel-drive version |
| Front track | 55.9–79.5 in · 1,420–2,020 mm |
| Rear track | 64.6–74.8 in · 1,640–1,900 mm |
| Turning radius, braked | 13.1 ft · 4.00 m |
Source · Traktorenlexikon, “Deutz D 9006”
What oil does a Deutz D 9006 take, and how much?
A Deutz D 9006 engine takes 11.6 qt (11 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 11.6 qt · 11 LSource: Traktorenlexikon, “Deutz D 9006” · single source, not independently verified |
| Transmission | 38.0 qt · 36 LSource: Traktorenlexikon, “Deutz D 9006” · single source, not independently verified |
| Hydraulic | 13.2 qt · 12.5 LSource: Traktorenlexikon, “Deutz D 9006” · single source, not independently verified |
| Front axle | 7.9 qt · 7.5 LSource: Traktorenlexikon, “Deutz D 9006” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a Deutz D 9006?
Within 10% of its 90.3 hp of claimed engine power, the same type, and first built within 15 years of it.
- Hanomag Robust 901 (S)90 hp engine, claimed · 1969–1970Side by side with the Deutz D 9006 →
- Hürlimann T-9200 (A)90.7 hp engine, claimed · 1976–1979Side by side with the Deutz D 9006 →
- VALMET 702 S (A)89.7 hp engine, claimed · 1974–1979Side by side with the Deutz D 9006 →
- International Harvester 82690.8 hp engine, claimed · 1969–1971Side by side with the Deutz D 9006 →
- International Harvester Farmall 82690.8 hp engine, claimed · 1969–1971Side by side with the Deutz D 9006 →
- Ford 7600 (A)90.8 hp engine, claimed · 1975–1981Side by side with the Deutz D 9006 →
Common questions about the Deutz D 9006
Is a Deutz D 9006 two-wheel drive or four-wheel drive?
The Deutz D 9006 was offered in two-wheel-drive and four-wheel-drive versions.
What PTO does a Deutz D 9006 have?
A Deutz D 9006 has a independent 540/1000 rpm rear PTO on a 29 x 34,9 x 8,7 mm (Form-A) shaft.
