- Rigid chassis
- WhichTractor size: Compact
- Not independently tested
- 1963–1968
- 75,056 built
It was ranked on an engine power figure whose source does not say gross or net. WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
URSUS C-328 Full specifications
URSUS S-312 B two-cylinder diesel. The manufacturer claimed 27.6 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
27.6 hp
20.6 kW as stated by the source
Not independently tested
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Ursus C-328”, claimed
- Weight
- 3,646 lb
- 3-point lift
- 1,543 lb
- Hyd. flow
- 4.8 gpm
- Top speed
- 14.3 mph
URSUS C-328 specs: key facts
The URSUS C-328 was built from 1963 to 1968.
The URSUS C-328 has a claimed engine power (gross or net not stated) of 20.6 kW (27.6 hp); it has no measured PTO figure.
The URSUS C-328 is two-wheel drive (2WD).
The URSUS C-328 has a URSUS S-312 B engine, a 2-cylinder 1.96 L diesel unit.
The URSUS C-328 weighs 1,654 kg (3,646 lb) unladen.
The URSUS C-328 has an independent rear PTO running at 540 rpm.
The three-point hitch of the URSUS C-328 lifts 700 kg (1,543 lb) at the lower-link ends.
The hydraulic pump of the URSUS C-328 delivers 18.0 L/min (4.8 gpm).
Source · Traktorenlexikon, “Ursus C-328”
How much horsepower does a C-328 have?
The only figure for the C-328 is 27.6 hp (20.6 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Ursus C-328”
What engine is in a C-328?
A C-328 has a URSUS S-312 B, a 2-cylinder 1.96 L diesel engine.
| Make & model | URSUS S-312 B |
|---|---|
| Cylinders | 2, liquid-cooled |
| Displacement | 119.7 ci · 1.96 L |
| Max torque | 74 lb·ft · 100 N·m @ 1,600 rpm |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Ursus C-328”
How much will a C-328 lift, and what is its hydraulic flow?
A C-328 lifts 1,543 lb (700 kg) at the lower-link ends of its Category 2 three-point hitch.
| Pump flow | 4.8 gpm · 18.0 L/min |
|---|---|
| Hitch category | Category 2 |
| Lift at ends | 1,543 lb · 700 kg |
| Rear PTO | Independent, engine-driven, 540 rpm @ 2,159 engine rpmGround-speed PTO available |
| PTO shaft | 1 3/8"- 6 splines |
Source · Traktorenlexikon, “Ursus C-328”
What transmission does a C-328 have?
Transmission specifications for the C-328 are below.
| Top speed | 14.3 mph · 23 km/h |
|---|
Source · Traktorenlexikon, “Ursus C-328”
How much does a C-328 weigh?
A C-328 weighs 3,646 lb (1,654 kg) unladen.
| Unladen weight | 3,646 lb · 1,654 kg |
|---|---|
| Wheelbase | 72.8 in · 1,850 mmSource 2 |
| Length | 119.3 in · 3,030 mmSource 2 |
| Width | 66.1 in · 1,680 mmSource 2 |
| Height | 59.1 in · 1,500 mmSource 2 |
| Ground clearance | 15.7 in · 400 mm |
| Front track | 49.2–59.1 in · 1,250–1,500 mm |
| Rear track | 49.2–72.8 in · 1,250–1,850 mm |
| Turning radius, braked | 8.8 ft · 2.69 m |
Source · Traktorenlexikon, “Ursus C-328”
Which tractors compare with a C-328?
Within 10% of its 27.6 hp of claimed engine power, the same type, and first built within 15 years of it.
- Renault 5327.6 hp engine, claimed · 1967–1973Side by side with the C-328 →
- SOMECA 300 (TD)27.6 hp engine, claimed · 1972–1978Side by side with the C-328 →
- BOLINDER-MUNKTELL BM-24/BM-2527.6 hp engine, claimed · 1952–1959Side by side with the C-328 →
- Hürlimann D-5027.6 hp engine, claimed · 1948–1952Side by side with the C-328 →
- RÖHR R 2827.6 hp engine, claimed · 1948–1949Side by side with the C-328 →
- Fendt Farmer 2 D27.5 hp engine, claimed · 1961–1967Side by side with the C-328 →
Everything else people ask
Is a C-328 two-wheel drive or four-wheel drive?
The URSUS C-328 is two-wheel drive (2WD).
What PTO does a C-328 have?
A C-328 has a independent 540 rpm rear PTO on a 1 3/8"- 6 splines shaft.
