- Rigid chassis
- WhichTractor size: Utility
- No lab test on file
- 1968–1977
- 2,973 built
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Renault 80 specs: hp, weight, years
MWM D 325-3 three-cylinder diesel. The manufacturer claimed 54.3 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
54.3 hp
40.5 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Renault 80 R7282”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 3,627 lb
- 3-point lift
- 4,079 lb
- Hyd. flow
- 6.1 gpm
- Top speed
- 15.5 mph
Renault 80 specs: key facts
The Renault 80 was built from 1968 to 1977.
The Renault 80 has a claimed engine power (gross or net not stated) of 40.5 kW (54.3 hp); it has no measured PTO figure.
The Renault 80 is two-wheel drive (2WD).
The Renault 80 has a MWM D 325-3 engine, a 3-cylinder 2.55 L diesel unit.Source 1
The Renault 80 weighs 1,645 kg (3,627 lb) unladen.
The Renault 80 has an independent rear PTO running at 540 rpm.
The three-point hitch of the Renault 80 lifts 1,850 kg (4,079 lb) at the lower-link ends.
The hydraulic pump of the Renault 80 delivers 23.2 L/min (6.1 gpm).
Source · Traktorenlexikon, “Renault 80 R7282”
How does the 80 compare with its class?
- Limitation:
A maximum engine torque of 156 N·m is low for its class — 18% below the median of 190 N·m across the 283 machines within 10% of its power that hold this figure.
- Worth knowing:
An unladen mass of 1,645 kg is low for its class — 33% below the median of 2,453 kg across the 364 machines within 10% of its power that hold this figure.
Derived by WhichTractor from 364 comparable records. How we work this out
.jpg){kind=link}
How much horsepower does an 80 have?
The only figure for the 80 is 54.3 hp (40.5 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Renault 80 R7282”
What engine is in an 80?
An 80 has an MWM D 325-3, a 3-cylinder 2.55 L diesel engine.
| Make & model | MWM D 325-3Source 1 |
|---|---|
| Cylinders | 3, air-cooledSource 1 |
| Displacement | 155.7 ci · 2.55 LSource 1 |
| Max torque | 115 lb·ft · 156 N·m @ 1,460 rpm |
| Injection | Direct injection method |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Renault 80 R7282”
How much will an 80 lift, and what is its hydraulic flow?
An 80 lifts 4,079 lb (1,850 kg) at the lower-link ends.
| Pump flow | 6.1 gpm · 23.2 L/min |
|---|---|
| Lift at ends | 4,079 lb · 1,850 kg |
| Rear PTO | Independent, engine-driven, 540 rpm @ 2,215 engine rpm |
Source · Traktorenlexikon, “Renault 80 R7282”
What transmission does an 80 have?
Transmission specifications for the 80 are below.
| Clutch | Dry Ferodo double clutch |
|---|---|
| Top speed | 15.5 mph · 25 km/h |
Source · Traktorenlexikon, “Renault 80 R7282”
How much does an 80 weigh?
An 80 weighs 3,627 lb (1,645 kg) unladen.
| Unladen weight | 3,627 lb · 1,645 kg |
|---|---|
| Wheelbase | 73.6 in · 1,870 mm |
| Length | 126.0 in · 3,200 mm |
| Width | 51.2–74.8 in · 1,300–1,900 mm |
| Height | 52.0 in · 1,320 mm |
| Ground clearance | 14.2 in · 360 mm |
| Front track | 39.4–59.1 in · 1,000–1,500 mm |
| Rear track | 39.4–63.0 in · 1,000–1,600 mm |
| Turning radius, braked | 9.1 ft · 2.77 m |
Source · Traktorenlexikon, “Renault 80 R7282”
What oil does an 80 take, and how much?
An 80 engine takes 9.0 qt (8.5 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 9.0 qt · 8.5 LSource: Traktorenlexikon, “Renault 80 R7282” · single source, not independently verified |
| Transmission & hydraulic | 28.0 qt · 26.5 LSource: Traktorenlexikon, “Renault 80 R7282” · single source, not independently verified |
| Final drives | 8.0 qt · 7.6 LSource: Traktorenlexikon, “Renault 80 R7282” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with an 80?
Within 10% of its 54.3 hp of claimed engine power, the same type, and first built within 15 years of it.
- ALLIS-CHALMERS One-Seventy54.3 hp engine, claimed · 1967–1973Side by side with the 80 →
- SAME Centauro54.3 hp engine, claimed · 1965–1969Side by side with the 80 →
- Renault 551/551.454.3 hp engine, claimed · 1972–1986Side by side with the 80 →
- Renault Master 154.3 hp engine, claimed · 1964–1969Side by side with the 80 →
- SOMECA SOM-51154.3 hp engine, claimed · 1964–1965Side by side with the 80 →
- ZETOR 571154.3 hp engine, claimed · 1972–1977Side by side with the 80 →
Common questions about the Renault 80
Is an 80 two-wheel drive or four-wheel drive?
The Renault 80 is two-wheel drive (2WD).
What PTO does an 80 have?
An 80 has a independent 540 rpm rear PTO.
Sources and how this page was built
Compiled from Traktorenlexikon, “Renault 80 R7282”; and Traktorenlexikon, “Renault 60 R7253”.
