- Rigid chassis
- WhichTractor size: Utility
- Not independently tested
- 1986–1989
- 307 built
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Renault 80-14 SP Full specifications
PERKINS 4.248 four-cylinder diesel. The manufacturer claimed 74.0 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
74.0 hp
55.2 kW as stated by the source
Not independently tested
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Renault 80-14 SP R3152”, claimed
- Weight
- 7,408 lb
- 3-point lift
- 10,075 lb
- Hyd. flow
- 8.4 gpm
- Top speed
- 18.6 mph
Renault 80-14 SP specs: key facts
The Renault 80-14 SP was built from 1986 to 1989.
The Renault 80-14 SP has a claimed engine power (gross or net not stated) of 55.2 kW (74.0 hp); it has no measured PTO figure.
The Renault 80-14 SP is four-wheel drive (4WD).
The Renault 80-14 SP has a PERKINS 4.248 engine, a 4-cylinder 4.07 L diesel unit.
The Renault 80-14 SP weighs 3,360 kg (7,408 lb) unladen.
The Renault 80-14 SP has an independent rear PTO running at 540/1000 rpm.
The three-point hitch of the Renault 80-14 SP lifts 4,570 kg (10,075 lb) at the lower-link ends.
The hydraulic pump of the Renault 80-14 SP delivers 31.9 L/min (8.4 gpm).
Source · Traktorenlexikon, “Renault 80-14 SP R3152”
How much horsepower does an 80-14 SP have?
The only figure for the 80-14 SP is 74.0 hp (55.2 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Renault 80-14 SP R3152”
What engine is in an 80-14 SP?
An 80-14 SP has a PERKINS 4.248, a 4-cylinder 4.07 L diesel engine.
| Make & model | PERKINS 4.248 |
|---|---|
| Cylinders | 4, liquid-cooled |
| Displacement | 248.4 ci · 4.07 L |
| Max torque | 200 lb·ft · 271 N·m @ 1,273 rpm |
| Injection | direct injection |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Renault 80-14 SP R3152”
How much will an 80-14 SP lift, and what is its hydraulic flow?
An 80-14 SP lifts 10,075 lb (4,570 kg) at the lower-link ends of its Category 2 three-point hitch.
| Pump flow | 8.4 gpm · 31.9 L/min |
|---|---|
| Hitch category | Category 2 |
| Lift at ends | 10,075 lb · 4,570 kg |
| Rear PTO | Independent, engine-driven, 540/1000 rpm @ 2,014 engine rpm |
Source · Traktorenlexikon, “Renault 80-14 SP R3152”
What transmission does an 80-14 SP have?
Transmission specifications for the 80-14 SP are below.
| Clutch | Dry LuK double clutch type DT 310/310 |
|---|---|
| Brakes | Pedal operated hydraulic Girling disc brake |
| Top speed | 18.6 mph · 30 km/h |
Source · Traktorenlexikon, “Renault 80-14 SP R3152”
How much does an 80-14 SP weigh?
An 80-14 SP weighs 7,408 lb (3,360 kg) unladen.
| Unladen weight | 7,408 lb · 3,360 kg |
|---|---|
| Wheelbase | 94.3 in · 2,394 mm |
| Length | 159.8 in · 4,058 mm |
| Width | 75.9 in · 1,929 mm |
| Height | 97.8 in · 2,485 mm |
| Ground clearance | 14.8 in · 377 mm |
| Front track | 59.1–74.8 in · 1,500–1,900 mm |
| Rear track | 59.1–70.9 in · 1,500–1,800 mm |
| Turning radius, braked | 16.1 ft · 4.90 m |
Source · Traktorenlexikon, “Renault 80-14 SP R3152”
Which tractors compare with an 80-14 SP?
Within 10% of its 68.3 hp at the PTO (claimed), the same type, and first built within 15 years of it.
- Renault 80-12 SP68.3 hp PTO, claimed · 1986–1989Side by side with the 80-14 SP →
- Renault 80-32 PX68.3 hp PTO, claimed · 1989–1993Side by side with the 80-14 SP →
- Renault 80-34 PX68.3 hp PTO, claimed · 1989–1993Side by side with the 80-14 SP →
- Ford 671068.3 hp PTO, claimed · 1981–1989Side by side with the 80-14 SP →
- VALMET 802/802-468.3 hp PTO, claimed · 1980–1983Side by side with the 80-14 SP →
- Renault 95-12 TX68.1 hp PTO, claimed · 1982–1986Side by side with the 80-14 SP →
Everything else people ask
Is an 80-14 SP two-wheel drive or four-wheel drive?
The Renault 80-14 SP is four-wheel drive (4WD).
What PTO does an 80-14 SP have?
An 80-14 SP has a independent 540/1000 rpm rear PTO.
Where this page comes from
Compiled from Traktorenlexikon, “Renault 80-14 SP R3152”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- Traktorenlexikon: Renault 80-14 SP R3152 — CC BY-SA 4.0, WIKIBOOKS-TL-109408 · revision 993400. Wikibooks contributors (Traktorenlexikon). Original document
