- Rigid chassis
- WhichTractor size: Utility
- No lab test on file
- 1976–1982
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Massey Ferguson 565 specs: hp, weight, years
Perkins A 4.236 four-cylinder diesel. The manufacturer claimed 59.3 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
59.3 hp
44.2 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Massey Ferguson MF 565”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 6,107 lb
- 3-point lift
- 3,960 lb
- Hyd. flow
- 16.5 gpm
- Top speed
- 15.5 mph
Massey Ferguson 565 specs: key facts
The Massey Ferguson 565 was built from 1976 to 1982.
The Massey Ferguson 565 has a claimed engine power (gross or net not stated) of 44.2 kW (59.3 hp); it has no measured PTO figure.
The Massey Ferguson 565 is two-wheel drive (2WD).
The Massey Ferguson 565 has a Perkins A 4.236 engine, a 4-cylinder 3.87 L diesel unit.Source 1
The Massey Ferguson 565 weighs 2,770 kg (6,107 lb) unladen.
The Massey Ferguson 565 has a rear PTO running at 540 rpm / 1000 rpm.
The three-point hitch of the Massey Ferguson 565 lifts 1,796 kg (3,960 lb) at the lower-link ends.
The hydraulic pump of the Massey Ferguson 565 delivers 62.5 L/min (16.5 gpm).
Source · Traktorenlexikon, “Massey Ferguson MF 565”
How does the 565 compare with its class?
- Strength:
A hydraulic pump flow of 62.5 L/min is high for its class — 85% above the median of 33.8 L/min across the 302 machines within 10% of its power that hold this figure.
Derived by WhichTractor from 359 comparable records. How we work this out

How much horsepower does a 565 have?
The only figure for the 565 is 59.3 hp (44.2 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Massey Ferguson MF 565”
What engine is in a 565?
A 565 has a Perkins A 4.236, a 4-cylinder 3.87 L diesel engine.
| Make & model | Perkins A 4.236 |
|---|---|
| Cylinders | 4, liquid-cooledSource 2 |
| Displacement | 236.0 ci · 3.87 L |
| Max torque | 178 lb·ft · 241.9 N·m @ 1,370 rpmSource 2 |
| Electrical system | 12 VSource 2 |
Source · Traktorenlexikon, “Massey Ferguson MF 168 & MF 168A”
How much will a 565 lift, and what is its hydraulic flow?
A 565 lifts 3,960 lb (1,796 kg) at the lower-link ends.
| Pump flow | 16.5 gpm · 62.5 L/min |
|---|---|
| Lift at ends | 3,960 lb · 1,796 kg |
| Rear PTO | 540 rpm / 1000 rpm @ 1,684 engine rpm |
Source · Traktorenlexikon, “Massey Ferguson MF 565”
What transmission does a 565 have?
Transmission specifications for the 565 are below.
| Clutch | Pedal-operated, dry and air-cooled single-disc clutch |
|---|---|
| Brakes | Hydraulically operated, wet Girling multi-disc brake acting on differential side shafts |
| Top speed | 15.5 mph · 25 km/h |
Source · Traktorenlexikon, “Massey Ferguson MF 565”
How much does a 565 weigh?
A 565 weighs 6,107 lb (2,770 kg) unladen.
| Unladen weight | 6,107 lb · 2,770 kg |
|---|---|
| Wheelbase | 87.5 in · 2,223 mm |
| Length | 148.4 in · 3,770 mm |
| Width | 72.8 in · 1,850 mm |
| Height | 94.9 in · 2,410 mm |
| Ground clearance | 13.0 in · 330 mm |
| Front track | 48.0–72.0 in · 1,218–1,830 mm |
| Rear track | 55.9–84.1 in · 1,421–2,135 mm |
| Turning radius, braked | 11.2 ft · 3.41 m |
Source · Traktorenlexikon, “Massey Ferguson MF 565”
What oil does a 565 take, and how much?
A 565 engine takes 7.5 qt (7.1 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 7.5 qt · 7.1 LSource: Traktorenlexikon, “Massey Ferguson MF 565” · single source, not independently verified |
| Transmission | 26.4 qt · 25.0 LSource: Traktorenlexikon, “Massey Ferguson MF 565” · single source, not independently verified |
| Cooling system | 15.0 qt · 14.2 LSource: Traktorenlexikon, “Massey Ferguson MF 565” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a 565?
Within 10% of its 52.0 hp at the PTO as the maker claimed it, with no laboratory test on file, the same type, and first built within 15 years of it.
- IMT 577 (DV)52.1 hp PTO, claimed · 1981–1993Side by side with the 565 →
- David Brown 99551.9 hp PTO, claimed · 1971–1976Side by side with the 565 →
- David Brown 996 (A)51.9 hp PTO, claimed · 1971–1976Side by side with the 565 →
- Deutz D 600552.2 hp PTO, claimed · 1966–1967Side by side with the 565 →
- Leyland 26252.3 hp PTO, claimed · 1975–1980Side by side with the 565 →
- Massey Ferguson 16552.3 hp PTO, claimed · 1964–1971Side by side with the 565 →
Common questions about the Massey Ferguson 565
Is a 565 two-wheel drive or four-wheel drive?
The Massey Ferguson 565 is two-wheel drive (2WD).
What PTO does a 565 have?
A 565 has a 540 rpm / 1000 rpm rear PTO.
Sources and how this page was built
Compiled from Traktorenlexikon, “Massey Ferguson MF 168 & MF 168A”; and Traktorenlexikon, “Massey Ferguson MF 565”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- Traktorenlexikon: Massey Ferguson MF 168 & MF 168A — CC BY-SA 4.0, WIKIBOOKS-TL-69277 · revision 1065377. Wikibooks contributors (Traktorenlexikon). Original document
- Traktorenlexikon: Massey Ferguson MF 565 — CC BY-SA 4.0, WIKIBOOKS-TL-86946 · revision 957152. Wikibooks contributors (Traktorenlexikon). Original document
