- Rigid chassis
- WhichTractor size: Standard-size
- No lab test on file
- 1983–1990
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Deutz-Fahr DX 6.30 specs: hp, weight, years
The manufacturer claimed 113.7 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
113.7 hp
84.8 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Deutz-Fahr DX 6.30”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 10,670 lb
- 3-point lift
- 11,464 lb
- Hyd. flow
- 16.0 gpm
- Top speed
- 18.6–24.9 mph
Deutz-Fahr DX 6.30 specs: key facts
The Deutz-Fahr DX 6.30 was built from 1983 to 1990.
The Deutz-Fahr DX 6.30 has a claimed engine power (gross or net not stated) of 84.8 kW (113.7 hp); it has no measured PTO figure.
The Deutz-Fahr DX 6.30 was offered in two-wheel-drive and four-wheel-drive versions.
The Deutz-Fahr DX 6.30 weighs 4,840 kg (10,670 lb) unladen.
The Deutz-Fahr DX 6.30 has an independent rear PTO running at 540/1000 rpm.
The three-point hitch of the Deutz-Fahr DX 6.30 lifts 5,200 kg (11,464 lb) at the lower-link ends.
The hydraulic pump of the Deutz-Fahr DX 6.30 delivers 60.4 L/min (16.0 gpm).
Source · Traktorenlexikon, “Deutz-Fahr DX 6.30”
How does the DX 6.30 compare with its class?
- Limitation:
A 120 L fuel tank is low for its class — 33% below the median of 180 L across the 269 machines within 10% of its power that hold this figure.
- Limitation:
The power figure is a manufacturer claim, not a measurement. No laboratory test report exists for this machine. Of the 287 tractors within 10% of its power, 10% carry one.
Derived by WhichTractor from 287 comparable records. How we work this out
How much horsepower does a DX 6.30 have?
The only figure for the DX 6.30 is 113.7 hp (84.8 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Deutz-Fahr DX 6.30”
How much will a DX 6.30 lift, and what is its hydraulic flow?
A DX 6.30 lifts 11,464 lb (5,200 kg) at the lower-link ends.
| System | Open centre |
|---|---|
| Pump flow | 16.0 gpm · 60.4 L/min |
| Pressure | 3,481 psi · 240 bar |
| Lift at ends | 11,464 lb · 5,200 kg |
| Rear PTO | Independent, 540/1000 rpm @ 2,192 engine rpmEngages under load |
Source · Traktorenlexikon, “Deutz-Fahr DX 6.30”
What transmission does a DX 6.30 have?
Transmission specifications for the DX 6.30 are below.
| Top speed | 18.6–24.9 mph · 30–40 km/hthe article lists alternatives |
|---|
Source · Traktorenlexikon, “Deutz-Fahr DX 6.30”
How much does a DX 6.30 weigh?
A DX 6.30 weighs 10,670 lb (4,840 kg) unladen.
| Unladen weight | 10,670 lb · 4,840 kg |
|---|---|
| Maximum permissible mass | 14,991 lb · 6,800 kg |
| Maximum front axle load | 5,952 lb · 2,700 kg |
| Maximum rear axle load | 10,141 lb · 4,600 kg |
| Wheelbase | 106.4 in · 2,703 mm |
| Length | 179.1 in · 4,550 mm |
| Width | 90.7 in · 2,304 mm |
| Height | 104.3 in · 2,650 mm |
| Ground clearance | 21.3 in · 540 mm |
| Rear track | 70.9–78.7 in · 1,800–2,000 mm |
| Turning radius, braked | 16.2 ft · 4.94 m |
Source · Traktorenlexikon, “Deutz-Fahr DX 6.30”
What oil does a DX 6.30 take, and how much?
A DX 6.30 engine takes 18.0 qt (17 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 18.0 qt · 17 LSource: Traktorenlexikon, “Deutz-Fahr DX 6.30” · single source, not independently verified |
| Transmission | 50.7 qt · 48 LSource: Traktorenlexikon, “Deutz-Fahr DX 6.30” · single source, not independently verified |
| Front axle | 7.9 qt · 7.5 LSource: Traktorenlexikon, “Deutz-Fahr DX 6.30” · single source, not independently verified |
| Cooling system | 1,585.0 qt · 1,500 LSource: Traktorenlexikon, “Deutz-Fahr DX 6.30” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a DX 6.30?
Within 10% of its 113.7 hp of claimed engine power, the same type, and first built within 15 years of it.
- Fiat 115-90 (DT)113.5 hp engine, claimed · 1984–1990Side by side with the DX 6.30 →
- ZETOR 12111/12145113.5 hp engine, claimed · 1984–1990Side by side with the DX 6.30 →
- Massey Ferguson 1250113.5 hp engine, claimed · 1980–1982Side by side with the DX 6.30 →
- Fiat 1180 (DT)113.5 hp engine, claimed · 1979–1984Side by side with the DX 6.30 →
- Lamborghini R-1156 (DT)113.5 hp engine, claimed · 1979–1984Side by side with the DX 6.30 →
- SOMECA 1180 (TD)113.5 hp engine, claimed · 1979–1983Side by side with the DX 6.30 →
Common questions about the Deutz-Fahr DX 6.30
Is a DX 6.30 two-wheel drive or four-wheel drive?
The Deutz-Fahr DX 6.30 was offered in two-wheel-drive and four-wheel-drive versions.
What PTO does a DX 6.30 have?
A DX 6.30 has a independent 540/1000 rpm rear PTO.
Sources and how this page was built
Compiled from Traktorenlexikon, “Deutz-Fahr DX 6.30”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- Traktorenlexikon: Deutz-Fahr DX 6.30 — CC BY-SA 4.0, WIKIBOOKS-TL-87875 · revision 982181. Wikibooks contributors (Traktorenlexikon). Original document
