- Rigid chassis
- WhichTractor size: Compact
- Lab tested ×2
- 2008–2012
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
New Holland T-4020 specs: hp, weight, years
IVECO F5 AE 9484 AA (Tier-III) four-cylinder diesel or Iveco F5AE9484A. The manufacturer claimed 64.1 horsepower. The only laboratory test on record is of one version: OECD Test 2465 measured 58.7 hp at the PTO of the T4020 (4 WD); OECD Test 2466 measured 58.7 hp at the PTO of the T4020 (4 WD). Compared at the engine's rated speed, where the brochure figure is quoted, the shaft gave 58.7 hp — 8.4% below the claim.
Engine power, claimed · gross or net not stated
64.1 hp
47.8 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “New Holland T 4020”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 8,179 lb
- 3-point lift
- 6,393 lb
- Hyd. flow
- 13.9 gpm
- Top speed
- 18.6–24.9 mph
New Holland T-4020 specs: key facts
The New Holland T-4020 was built from 2008 to 2012.
Only one version of the New Holland T-4020 has a laboratory test on record: the T4020 (4 WD) produced 43.8 kW (58.7 hp) at the PTO, measured on OECD Test 2465; the T4020 (4 WD) produced 43.8 kW (58.7 hp) at the PTO, measured on OECD Test 2466.Source 1,Source 2
The New Holland T-4020 has a claimed engine power (gross or net not stated) of 47.8 kW (64.1 hp); it has no measured PTO figure.
The New Holland T-4020 is four-wheel drive (4WD).Source 1,Source 2
The New Holland T-4020 has a IVECO F5 AE 9484 AA (Tier-III) engine, a 4-cylinder 3.20 L diesel unit.
The New Holland T-4020 weighs 3,710 kg (8,179 lb) unladen.
The New Holland T-4020 has a rear PTO running at 540 rpm / 1000 rpm.
The three-point hitch of the New Holland T-4020 lifts 2,900 kg (6,393 lb) at the lower-link ends.
The hydraulic pump of the New Holland T-4020 delivers 52.5 L/min (13.9 gpm).
Source · Traktorenlexikon, “New Holland T 4020”
How does the T-4020 compare with its class?
- Strength:
A maximum engine torque of 276 N·m is high for its class — 19% above the median of 232 N·m across the 332 machines within 10% of its power that hold this figure.
- Worth knowing:
An unladen mass of 3,710 kg is high for its class — 33% above the median of 2,800 kg across the 395 machines within 10% of its power that hold this figure.
Derived by WhichTractor from 395 comparable records. How we work this out

How much horsepower does a T-4020 have?
The only laboratory test on record is of one version. OECD Test 2465 measured 58.7 hp at the PTO of the T4020 (4 WD); OECD Test 2466 measured 58.7 hp at the PTO of the T4020 (4 WD). For the T-4020 as a whole the figure is the 64.1 hp claimed for the engine, which is not power at the shaft.
Sources · Traktorenlexikon, “New Holland T 4020”; OECD test report 2465, 2009; OECD test report 2466, 2009
What engine is in a T-4020?
A T-4020 has an IVECO F5 AE 9484 AA (Tier-III), a 4-cylinder 3.20 L diesel engine. T4020 (4 WD) tractors have a Iveco F5AE9484A. T4020 (4 WD) tractors have a Iveco F5AE9484A.
| Make & model | IVECO F5 AE 9484 AA (Tier-III) |
|---|---|
| Cylinders | 4, liquid-cooled |
| Displacement | 195.4 ci · 3.20 L |
| Max torque | 204 lb·ft · 276 N·m @ 1,000 rpm |
| Injection | Direct injection |
| Electrical system | 12 V |
Source · Traktorenlexikon, “New Holland T 4020”
How much will a T-4020 lift, and what is its hydraulic flow?
A T-4020 lifts 6,393 lb (2,900 kg) at the lower-link ends.
| Pump flow | 13.9 gpm · 52.5 L/min |
|---|---|
| Lift at ends | 6,393 lb · 2,900 kg |
| Rear PTO | 540 rpm / 1000 rpm @ 2,196 engine rpm |
Source · Traktorenlexikon, “New Holland T 4020”
What transmission does a T-4020 have?
Transmission specifications for the T-4020 are below.
| Clutch | Dry LuK double clutch |
|---|---|
| Steering | Hydrostatic Danfoss steering |
| Top speed | 18.6–24.9 mph · 30–40 km/hthe article lists alternatives |
Source · Traktorenlexikon, “New Holland T 4020”
How much does a T-4020 weigh?
A T-4020 weighs 8,179 lb (3,710 kg) unladen.
| Unladen weight | 8,179 lb · 3,710 kg |
|---|---|
| Maximum permissible mass | 11,574 lb · 5,250 kg |
| Wheelbase | 82.6 in · 2,098 mm |
| Length | 143.2 in · 3,637 mm |
| Width | 73.5–95.6 in · 1,867–2,428 mm |
| Height | 92.1 in · 2,340 mm |
| Ground clearance | 15.0 in · 380 mm |
| Front track | 48.7–76.6 in · 1,236–1,945 mm |
| Rear track | 48.5–76.7 in · 1,232–1,949 mm |
Source · Traktorenlexikon, “New Holland T 4020”
What oil does a T-4020 take, and how much?
A T-4020 engine takes 7.9 qt (7.5 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 7.9 qt · 7.5 LSource: Traktorenlexikon, “New Holland T 4020” · single source, not independently verified |
| Transmission & hydraulic | 44.4 qt · 42.0 LSource: Traktorenlexikon, “New Holland T 4020” · single source, not independently verified |
| Front axle | 1.3 qt · 1.25 LSource: Traktorenlexikon, “New Holland T 4020” · single source, not independently verified |
| Cooling system | 12.7 qt · 12.0 LSource: Traktorenlexikon, “New Holland T 4020” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
How much fuel does a T-4020 burn per hour?
Measured on OECD Test 2465 (tested as the T4020 (4 WD)), at each condition the laboratory recorded.
1 other test of this model is on record; figures differ between configurations.
Cost per hour = fuel used per hour × your fuel price (per litre, or per US gallon for the gal/h figure).
| Test condition | Fuel per hour |
|---|---|
| Maximum PTO powerPTO 43.8 kW (58.7 hp) at 564 rpm | 13.60 L/h 3.59 gal/h |
| Rated engine speedPTO 43.8 kW (58.7 hp) at 564 rpm | 13.60 L/h 3.59 gal/h |
| Standard PTO speedPTO 43.5 kW (58.3 hp) at 540 rpm | 13.53 L/h 3.57 gal/h |
| 75% load, 50% load | Not on record for this test |
Source · OECD Test 2465
Which tractors compare with a T-4020?
Within 10% of its 64.1 hp of claimed engine power, the same type, and first built within 15 years of it.
- Fiat TL 70 (DT)64.1 hp engine, claimed · from 1998Side by side with the T-4020 →
- New Holland TL 70 (A)64.1 hp engine, claimed · 1998–2004Side by side with the T-4020 →
- Massey Ferguson 4225 (A)64.1 hp engine, claimed · 1997–2001Side by side with the T-4020 →
- ZETOR 6321/6341 Super64.1 hp engine, claimed · 1997–2004Side by side with the T-4020 →
- Fiat L 65 (DT)64.1 hp engine, claimed · 1996–1998Side by side with the T-4020 →
- Ford 483564.1 hp engine, claimed · 1996–1998Side by side with the T-4020 →
Common questions about the New Holland T-4020
Is a T-4020 two-wheel drive or four-wheel drive?
The New Holland T-4020 is four-wheel drive (4WD).
What PTO does a T-4020 have?
A T-4020 has a 540 rpm / 1000 rpm rear PTO.
Sources and how this page was built
Compiled from OECD tractor test reports 2465 and 2466; and Traktorenlexikon, “New Holland T 4020”.
