- Rigid chassis
- WhichTractor size: Utility
- Lab tested ×1
- 1999–2003
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Hürlimann XN-709 specs: hp, weight, years
Hürlimann 1000.4 WT-1 four-cylinder diesel or Same Deutz-Fahr Group 1000.4 WT1. The manufacturer claimed 86.9 horsepower. The only laboratory test on record is of one version: OECD Test 1828 measured 81.4 hp at the PTO of the XN 709 (4 WD). Compared at the engine's rated speed, where the brochure figure is quoted, the shaft gave 81.4 hp — 6.3% below the claim.
Engine power, claimed · gross or net not stated
86.9 hp
64.8 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Hürlimann XN 709”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 6,041 lb
- Hyd. flow
- 9.2 gpm
- Top speed
- 24.9 mph
Hürlimann XN-709 specs: key facts
The Hürlimann XN-709 was built from 1999 to 2003.
Only one version of the Hürlimann XN-709 has a laboratory test on record: the XN 709 (4 WD) produced 60.7 kW (81.4 hp) at the PTO, measured on OECD Test 1828.Source 2
The Hürlimann XN-709 has a claimed engine power (gross or net not stated) of 64.8 kW (86.9 hp); it has no measured PTO figure.
The Hürlimann XN-709 is four-wheel drive (4WD).Source 1
The Hürlimann XN-709 has a Hürlimann 1000.4 WT-1 engine, a 4-cylinder 4.00 L diesel unit.Source 3
The Hürlimann XN-709 weighs 2,740 kg (6,041 lb) unladen.
The Hürlimann XN-709 has a rear PTO running at 540 rpm / 1000 rpm.
The hydraulic pump of the Hürlimann XN-709 delivers 34.9 L/min (9.2 gpm).
Source · Traktorenlexikon, “Hürlimann XN 709”
How does the XN-709 compare with its class?
- Strength:
45 forward gears is high for its class — 275% above the median of 12 across the 394 machines within 10% of its power that hold this figure.
- Limitation:
A 58 L fuel tank is low for its class — 50% below the median of 115 L across the 379 machines within 10% of its power that hold this figure.
- Worth knowing:
An unladen mass of 2,740 kg is low for its class — 24% below the median of 3,625 kg across the 402 machines within 10% of its power that hold this figure.
Derived by WhichTractor from 403 comparable records. How we work this out

How much horsepower does a XN-709 have?
The only laboratory test on record is of one version. OECD Test 1828 measured 81.4 hp at the PTO of the XN 709 (4 WD). For the XN-709 as a whole the figure is the 86.9 hp claimed for the engine, which is not power at the shaft.
Sources · Traktorenlexikon, “Hürlimann XN 709”; OECD test report 1828, 1999
What engine is in a XN-709?
A XN-709 has a Hürlimann 1000.4 WT-1, a 4-cylinder 4.00 L diesel engine. XN 709 (4 WD) tractors have a Same Deutz-Fahr Group 1000.4 WT1.
| Make & model | Hürlimann 1000.4 WT-1Source 3 |
|---|---|
| Cylinders | 4, liquid-cooledSource 3 |
| Displacement | 244.1 ci · 4.00 LSource 3 |
| Max torque | 235 lb·ft · 319 N·m @ 1,640 rpm |
| Injection | direct injection |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Hürlimann XN 709”
How much will a XN-709 lift, and what is its hydraulic flow?
Hydraulic and PTO specifications for the XN-709 are below.
| System | Load sensing |
|---|---|
| Pump flow | 9.2 gpm · 34.9 L/min |
| Pressure | 3,046 psi · 210 bar |
| Hitch category | Category 2 |
| Rear PTO | 540 rpm / 1000 rpm @ 2,077 engine rpm |
Source · Traktorenlexikon, “Hürlimann XN 709”
What transmission does a XN-709 have?
Transmission specifications for the XN-709 are below.
| Clutch | pedal-operated dry SDF single-plate clutch |
|---|---|
| Brakes | Hydraulically operated wet SLH disc brake acting on differential side shafts |
| Steering | Hydrostatic Danfoss steering |
| Top speed | 24.9 mph · 40 km/h |
Source · Traktorenlexikon, “Hürlimann XN 709”
How much does a XN-709 weigh?
A XN-709 weighs 6,041 lb (2,740 kg) unladen.
| Unladen weight | 6,041 lb · 2,740 kg |
|---|---|
| Wheelbase | 80.9 in · 2,056 mm |
| Length | 140.2 in · 3,561 mm |
| Width | 50.8–64.6 in · 1,290–1,640 mm |
| Height | 83.1 in · 2,110 mm |
| Ground clearance | 10.6 in · 270 mm |
| Front track | 42.5–47.2 in · 1,080–1,200 mm |
| Rear track | 42.5–49.2 in · 1,080–1,250 mm |
| Turning radius, braked | 13.9 ft · 4.23 m |
Source · Traktorenlexikon, “Hürlimann XN 709”
What oil does a XN-709 take, and how much?
A XN-709 engine takes 11.6 qt (11.0 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 11.6 qt · 11.0 LSource: Traktorenlexikon, “Hürlimann XN 709” · single source, not independently verified |
| Transmission & hydraulic | 43.3 qt · 41.0 LSource: Traktorenlexikon, “Hürlimann XN 709” · single source, not independently verified |
| Front axle | 6.3 qt · 6.0 LSource: Traktorenlexikon, “Hürlimann XN 709” · single source, not independently verified |
| Final drives | 3.2 qt · 3.0 LSource: Traktorenlexikon, “Hürlimann XN 709” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
How much fuel does a XN-709 burn per hour?
Measured on OECD Test 1828 (tested as the XN 709 (4 WD)), at each condition the laboratory recorded.
Cost per hour = fuel used per hour × your fuel price (per litre, or per US gallon for the gal/h figure).
| Test condition | Fuel per hour |
|---|---|
| Maximum PTO powerPTO 60.7 kW (81.4 hp) at 1,022 rpm | 17.48 L/h 4.62 gal/h |
| Rated engine speedPTO 60.7 kW (81.4 hp) at 1,022 rpm | 17.48 L/h 4.62 gal/h |
| Standard PTO speedPTO 60.4 kW (81.0 hp) at 1,000 rpm | 17.25 L/h 4.56 gal/h |
| 75% load, 50% load | Not on record for this test |
Source · OECD Test 1828
Which tractors compare with a XN-709?
Within 10% of its 86.9 hp of claimed engine power, the same type, and first built within 15 years of it.
- Deutz-Fahr Agrocompact 90 V/F86.9 hp engine, claimed · 1998–2004Side by side with the XN-709 →
- Deutz-Fahr Agrotron 9086.9 hp engine, claimed · 1997–2001Side by side with the XN-709 →
- Deutz-Fahr Agrotron 90 MK386.9 hp engine, claimed · 2001–2003Side by side with the XN-709 →
- Deutz-Fahr Agrotron 4.9086.9 hp engine, claimed · 1995–1997Side by side with the XN-709 →
- Deutz-Fahr Agrotron 10086.9 hp engine, claimed · 2004–2005Side by side with the XN-709 →
- Lamborghini Agile 990 S/DT86.8 hp engine, claimed · 1996–2003Side by side with the XN-709 →
Common questions about the Hürlimann XN-709
Is a XN-709 two-wheel drive or four-wheel drive?
The Hürlimann XN-709 is four-wheel drive (4WD).
What PTO does a XN-709 have?
A XN-709 has a 540 rpm / 1000 rpm rear PTO.
