- Rigid chassis
- WhichTractor size: Standard-size
- No lab test on file
- 1995–2004
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Hürlimann 910.6 XT specs: hp, weight, years
Hürlimann H-1000.6 W1 six-cylinder diesel. The manufacturer claimed 103.5 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
103.5 hp
77.2 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Hürlimann XT 910.6”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 10,031 lb
- Hyd. flow
- 10.8 gpm
- Top speed
- 18.6–24.9 mph
Hürlimann 910.6 XT specs: key facts
The Hürlimann 910.6 XT was built from 1995 to 2004.
The Hürlimann 910.6 XT has a claimed engine power (gross or net not stated) of 77.2 kW (103.5 hp); it has no measured PTO figure.
The Hürlimann 910.6 XT is four-wheel drive (4WD).
The Hürlimann 910.6 XT has a Hürlimann H-1000.6 W1 engine, a 6-cylinder 6.00 L diesel unit.
The Hürlimann 910.6 XT weighs 4,550 kg (10,031 lb) unladen.
The Hürlimann 910.6 XT has a rear PTO running at 540/1000/540E/1000E rpm.
The hydraulic pump of the Hürlimann 910.6 XT delivers 41.0 L/min (10.8 gpm).
Source · Traktorenlexikon, “Hürlimann XT 910.6”
How much horsepower does a 910.6 XT have?
The only figure for the 910.6 XT is 103.5 hp (77.2 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Hürlimann XT 910.6”
What engine is in a 910.6 XT?
A 910.6 XT has a Hürlimann H-1000.6 W1, a 6-cylinder 6.00 L diesel engine.
| Make & model | Hürlimann H-1000.6 W1 |
|---|---|
| Cylinders | 6, liquid-cooled |
| Displacement | 366.2 ci · 6.00 L |
| Max torque | 253 lb·ft · 343 N·m @ 1,409 rpm |
| Injection | Naturally aspirated six-cylinder diesel with direct injection |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Hürlimann XT 910.6”
How much will a 910.6 XT lift, and what is its hydraulic flow?
Hydraulic and PTO specifications for the 910.6 XT are below.
| System | Load sensing |
|---|---|
| Pump flow | 10.8 gpm · 41.0 L/min |
| Pressure | 3,046 psi · 210 bar |
| Hitch category | Category 2 |
| Rear PTO | 540/1000/540E/1000E rpm @ 2,229 engine rpm |
| PTO shaft | 1 3/8"- 6 splines or 1 3/8"- 21 splines |
Source · Traktorenlexikon, “Hürlimann XT 910.6”
What transmission does a 910.6 XT have?
Transmission specifications for the 910.6 XT are below.
| Clutch | Pedal-operated dry SLH single-plate clutch |
|---|---|
| Brakes | Hydraulically operated wet SLH disc brakes acting on differential side shafts |
| Steering | Hydrostatic Danfoss steering |
| Top speed | 18.6–24.9 mph · 30–40 km/hthe article lists alternatives |
Source · Traktorenlexikon, “Hürlimann XT 910.6”
How much does a 910.6 XT weigh?
A 910.6 XT weighs 10,031 lb (4,550 kg) unladen.
| Unladen weight | 10,031 lb · 4,550 kg |
|---|---|
| Wheelbase | 103.7 in · 2,635 mm |
| Length | 175.2 in · 4,450 mm |
| Width | 81.9–98.4 in · 2,080–2,500 mm |
| Height | 106.9 in · 2,715 mm |
| Ground clearance | 17.9 in · 455 mm |
| Front track | 59.8–83.5 in · 1,520–2,120 mm |
| Rear track | 62.6–82.3 in · 1,590–2,090 mm |
| Turning radius, braked | 15.3 ft · 4.67 m |
Source · Traktorenlexikon, “Hürlimann XT 910.6”
What oil does a 910.6 XT take, and how much?
A 910.6 XT engine takes 15.9 qt (15.0 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 15.9 qt · 15.0 LSource: Traktorenlexikon, “Hürlimann XT 910.6” · single source, not independently verified |
| Transmission & hydraulic | 75.0 qt · 71.0 LSource: Traktorenlexikon, “Hürlimann XT 910.6” · single source, not independently verified |
| Front axle | 16.4 qt · 15.5 LSource: Traktorenlexikon, “Hürlimann XT 910.6” · single source, not independently verified |
| Cooling system | 18.0 qt · 17.0 LSource: Traktorenlexikon, “Hürlimann XT 910.6” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a 910.6 XT?
Within 10% of its 103.5 hp of claimed engine power, the same type, and first built within 15 years of it.
- Lamborghini 1060 DT103.5 hp engine, claimed · 1995–2004Side by side with the 910.6 XT →
- UTB U-1033 (DT)103.5 hp engine, claimed · 1994–2004Side by side with the 910.6 XT →
- New Holland TM 115103.5 hp engine, claimed · 1999–2002Side by side with the 910.6 XT →
- VALMET 6600-4 (6600E)103.5 hp engine, claimed · 1991–2000Side by side with the 910.6 XT →
- ZETOR 10641103.5 hp engine, claimed · 1999–2002Side by side with the 910.6 XT →
- VALMET 905-4103.5 hp engine, claimed · 1984–1989Side by side with the 910.6 XT →
Common questions about the Hürlimann 910.6 XT
Is a 910.6 XT two-wheel drive or four-wheel drive?
The Hürlimann 910.6 XT is four-wheel drive (4WD).
What PTO does a 910.6 XT have?
A 910.6 XT has a 540/1000/540E/1000E rpm rear PTO on a 1 3/8"- 6 splines or 1 3/8"- 21 splines shaft.
Sources and how this page was built
Compiled from Traktorenlexikon, “Hürlimann XT 910.6”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- Traktorenlexikon: Hürlimann XT 910.6 — CC BY-SA 4.0, WIKIBOOKS-TL-105056 · revision 896223. Wikibooks contributors (Traktorenlexikon). Original document
