- Rigid chassis
- WhichTractor size: Standard-size
- No lab test on file
- 1974–1981
- 6,200 built
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Deutz D 7206 specs: hp, weight, years
KHD F4L 912 four-cylinder diesel. The manufacturer claimed 70.7 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
70.7 hp
52.7 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Deutz D 7206”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 5,732 lb
- Hyd. flow
- 7.2 gpm
- Top speed
- 17.1 mph
Deutz D 7206 specs: key facts
The Deutz D 7206 was built from 1974 to 1981.
The Deutz D 7206 has a claimed engine power (gross or net not stated) of 52.7 kW (70.7 hp); it has no measured PTO figure.
The Deutz D 7206 was offered in two-wheel-drive and four-wheel-drive versions.
The Deutz D 7206 has a KHD F4L 912 engine, a 4-cylinder 3.77 L diesel unit.Source 1
The Deutz D 7206 weighs 2,600 kg (5,732 lb) unladen.
The Deutz D 7206 has an independent rear PTO running at 540/1000 rpm.
The hydraulic pump of the Deutz D 7206 delivers 27.2 L/min (7.2 gpm).
Source · Traktorenlexikon, “Deutz D 7206”
How much horsepower does a Deutz D 7206 have?
The only figure for the Deutz D 7206 is 70.7 hp (52.7 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Deutz D 7206”
What engine is in a Deutz D 7206?
A Deutz D 7206 has a KHD F4L 912, a 4-cylinder 3.77 L diesel engine.
| Make & model | KHD F4L 912Source 1 |
|---|---|
| Cylinders | 4, air-cooledSource 1 |
| Displacement | 229.9 ci · 3.77 LSource 1 |
| Max torque | 178 lb·ft · 242 N·m @ 1,600 rpm |
| Injection | direct injection |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Deutz D 7206”
How much will a Deutz D 7206 lift, and what is its hydraulic flow?
Hydraulic and PTO specifications for the Deutz D 7206 are below.
| Pump flow | 7.2 gpm · 27.2 L/min |
|---|---|
| Pressure | 2,901 psi · 200 bar |
| Rear PTO | Independent, 540/1000 rpmEngages under load |
Source · Traktorenlexikon, “Deutz D 7206”
What transmission does a Deutz D 7206 have?
Transmission specifications for the Deutz D 7206 are below.
| Clutch | Independent dry double clutch from Fichtel & Sachs |
|---|---|
| Steering | Mechanical ZF Gemmer steering |
| Top speed | 17.1 mph · 27.6 km/h |
Source · Traktorenlexikon, “Deutz D 7206”
How much does a Deutz D 7206 weigh?
A Deutz D 7206 weighs 5,732 lb (2,600 kg) unladen.
| Unladen weight | 5,732 lb · 2,600 kgtwo-wheel-drive version |
|---|---|
| Maximum permissible mass | 11,023 lb · 5,000 kg |
| Maximum front axle load | 3,902 lb · 1,770 kg |
| Maximum rear axle load | 8,818 lb · 4,000 kg |
| Wheelbase | 94.9 in · 2,410 mm |
| Length | 155.9 in · 3,960 mm |
| Width | 76.4 in · 1,940 mm |
| Height | 71.3 in · 1,810 mm |
| Ground clearance | 19.9 in · 505 mmtwo-wheel-drive version |
| Front track | 56.1–75.8 in · 1,425–1,925 mmtwo-wheel-drive version |
| Rear track | 59.8–71.8 in · 1,520–1,823 mm |
| Turning radius, braked | 13.0 ft · 3.96 m |
Source · Traktorenlexikon, “Deutz D 7206”
What oil does a Deutz D 7206 take, and how much?
A Deutz D 7206 engine takes 10.0 qt (9.5 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 10.0 qt · 9.5 LSource: Traktorenlexikon, “Deutz D 7206” · single source, not independently verified |
| Transmission | 38.6 qt · 36.5 LSource: Traktorenlexikon, “Deutz D 7206” · single source, not independently verified |
| Hydraulic | 15.3 qt · 14.5 LSource: Traktorenlexikon, “Deutz D 7206” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a Deutz D 7206?
Within 10% of its 66 hp at the PTO as the maker claimed it, with no laboratory test on file, the same type, and first built within 15 years of it.
- SAME Jaguar 95 (DT)66.0 hp PTO, claimed · 1979–1982Side by side with the Deutz D 7206 →
- Steyr 870 (a)66.1 hp PTO, claimed · 1971–1975Side by side with the Deutz D 7206 →
- Steyr Plus 7066.1 hp PTO, claimed · 1968–1975Side by side with the Deutz D 7206 →
- Lamborghini R-475 (DT)66.2 hp PTO, claimed · 1971–1973Side by side with the Deutz D 7206 →
- Hürlimann H-480 (A)65.2 hp PTO, claimed · 1979–1982Side by side with the Deutz D 7206 →
- International Harvester 66666.3 hp PTO, claimed · 1972–1976Side by side with the Deutz D 7206 →
Common questions about the Deutz D 7206
Is a Deutz D 7206 two-wheel drive or four-wheel drive?
The Deutz D 7206 was offered in two-wheel-drive and four-wheel-drive versions.
What PTO does a Deutz D 7206 have?
A Deutz D 7206 has a independent 540/1000 rpm rear PTO.
