- Rigid chassis
- WhichTractor size: Utility
- No lab test on file
- 1974–1980
- 8,000 built
It sits on the utility/standard-size boundary, so either size is a fair description. WhichTractor size, not the maker’s category
The source says so, in a sentence about this machine. How we decide what a machine is
Deutz D 6206 specs: hp, weight, years
KHD F4L 912 four-cylinder diesel.
- Weight
- 4,905 lb
- Hyd. flow
- 7.2 gpm
- Top speed
- 12.4–18.6 mph
Deutz D 6206 specs: key facts
The Deutz D 6206 was built from 1974 to 1980.
The Deutz D 6206 was offered in two-wheel-drive and four-wheel-drive versions.
The Deutz D 6206 has a KHD F4L 912 engine, a 4-cylinder 3.77 L diesel unit.Source 1
The Deutz D 6206 weighs 2,225 kg (4,905 lb) unladen.
The Deutz D 6206 has an independent rear PTO running at 540 rpm.
The hydraulic pump of the Deutz D 6206 delivers 27.4 L/min (7.2 gpm).
Source · Traktorenlexikon, “Deutz D 6206”
How much horsepower does a Deutz D 6206 have?
No sourced power figure for the Deutz D 6206 is on record yet.
What engine is in a Deutz D 6206?
A Deutz D 6206 has a KHD F4L 912, a 4-cylinder 3.77 L diesel engine.
| Make & model | KHD F4L 912Source 1 |
|---|---|
| Cylinders | 4, air-cooledSource 1 |
| Displacement | 229.9 ci · 3.77 LSource 1 |
| Max torque | 159 lb·ft · 216 N·m @ 1,600 rpm |
| Injection | Direct injection method |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Deutz D 6206”
How much will a Deutz D 6206 lift, and what is its hydraulic flow?
Hydraulic and PTO specifications for the Deutz D 6206 are below.
| Pump flow | 7.2 gpm · 27.4 L/min |
|---|---|
| Pressure | 2,901 psi · 200 bar |
| Rear PTO | Independent, 540 rpm @ 2,070 engine rpmEngages under load |
| PTO shaft | 29 x 34,9 x 8,7 mm |
Source · Traktorenlexikon, “Deutz D 6206”
What transmission does a Deutz D 6206 have?
Transmission specifications for the Deutz D 6206 are below.
| Clutch | Independent two-plate dry clutch |
|---|---|
| Brakes | Pedal operated Girling full disc brake acting on the differential side shafts |
| Steering | Mechanical ZF Gemmer steering |
| Top speed | 12.4–18.6 mph · 20–30 km/hthe article lists alternatives |
Source · Traktorenlexikon, “Deutz D 6206”
How much does a Deutz D 6206 weigh?
A Deutz D 6206 weighs 4,905 lb (2,225 kg) unladen.
| Unladen weight | 4,905 lb · 2,225 kgtwo-wheel-drive version |
|---|---|
| Maximum permissible mass | 8,818 lb · 4,000 kg |
| Maximum front axle load | 3,417 lb · 1,550 kg |
| Maximum rear axle load | 6,614 lb · 3,000 kg |
| Wheelbase | 83.7 in · 2,125 mmtwo-wheel-drive version |
| Length | 144.9 in · 3,680 mm |
| Width | 72.2 in · 1,835 mm |
| Height | 66.5 in · 1,690 mm |
| Ground clearance | 18.1 in · 460 mmtwo-wheel-drive version |
| Front track | 58.7–74.4 in · 1,490–1,890 mmtwo-wheel-drive version |
| Rear track | 55.6–75.9 in · 1,413–1,928 mm |
| Turning radius, braked | 11.8 ft · 3.61 m |
Source · Traktorenlexikon, “Deutz D 6206”
What oil does a Deutz D 6206 take, and how much?
A Deutz D 6206 engine takes 8.5 qt (8 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 8.5 qt · 8 LSource: Traktorenlexikon, “Deutz D 6206” · single source, not independently verified |
| Transmission | 19.0 qt · 18 LSource: Traktorenlexikon, “Deutz D 6206” · single source, not independently verified |
| Hydraulic | 12.7 qt · 12 LSource: Traktorenlexikon, “Deutz D 6206” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a Deutz D 6206?
Within 10% of its 55.1 hp at the PTO as the maker claimed it, with no laboratory test on file, the same type, and first built within 15 years of it.
- David Brown 1494 (A)55.1 hp PTO, claimed · 1984–1988Side by side with the Deutz D 6206 →
- J.I. Case 1494 (DT)55.1 hp PTO, claimed · 1984–1985Side by side with the Deutz D 6206 →
- Fiat 650-S (DT)55.2 hp PTO, claimed · 1971–1974Side by side with the Deutz D 6206 →
- International Harvester 624 (A)55.2 hp PTO, claimed · 1965–1972Side by side with the Deutz D 6206 →
- David Brown 1294 (A)55.2 hp PTO, claimed · 1984–1985Side by side with the Deutz D 6206 →
- J.I. Case 1294 (DT)55.2 hp PTO, claimed · 1984–1985Side by side with the Deutz D 6206 →
Common questions about the Deutz D 6206
Is a Deutz D 6206 two-wheel drive or four-wheel drive?
The Deutz D 6206 was offered in two-wheel-drive and four-wheel-drive versions.
What PTO does a Deutz D 6206 have?
A Deutz D 6206 has a independent 540 rpm rear PTO on a 29 x 34,9 x 8,7 mm shaft.
Sources and how this page was built
Compiled from Traktorenlexikon, “Deutz D 6006”; and Traktorenlexikon, “Deutz D 6206”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- Traktorenlexikon: Deutz D 6006 — CC BY-SA 4.0, WIKIBOOKS-TL-51755 · revision 1024090. Wikibooks contributors (Traktorenlexikon). Original document
- Traktorenlexikon: Deutz D 6206 — CC BY-SA 4.0, WIKIBOOKS-TL-60365 · revision 1082880. Wikibooks contributors (Traktorenlexikon). Original document
