- Rigid chassis
- WhichTractor size: Compact
- No lab test on file
- 1968–1975
It was ranked on an engine power figure whose source does not say gross or net. WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
ZETOR 2511 specs: hp, weight, years
ZETOR Z-2001 two-cylinder diesel. The manufacturer claimed 22.7 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
22.7 hp
16.9 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Zetor 2511”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 2,954 lb
- 3-point lift
- 1,764 lb
- Hyd. flow
- 5.3 gpm
- Top speed
- 12.4 mph
ZETOR 2511 specs: key facts
The ZETOR 2511 was built from 1968 to 1975.
The ZETOR 2511 has a claimed engine power (gross or net not stated) of 16.9 kW (22.7 hp); it has no measured PTO figure.
The ZETOR 2511 is two-wheel drive (2WD).
The ZETOR 2511 has a ZETOR Z-2001 engine, a 2-cylinder 1.56 L diesel unit.
The ZETOR 2511 weighs 1,340 kg (2,954 lb) unladen.
The ZETOR 2511 has an independent rear PTO running at 540 rpm.
The three-point hitch of the ZETOR 2511 lifts 800 kg (1,764 lb) at the lower-link ends.
The hydraulic pump of the ZETOR 2511 delivers 20.0 L/min (5.3 gpm).
Source · Traktorenlexikon, “Zetor 2511”
How does the 2511 compare with its class?
- Strength:
Ten forward gears is high for its class — 100% above the median of 5 across the 113 machines within 10% of its power that hold this figure.
Derived by WhichTractor from 113 comparable records. How we work this out
How much horsepower does a 2511 have?
The only figure for the 2511 is 22.7 hp (16.9 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Zetor 2511”
What engine is in a 2511?
A 2511 has a ZETOR Z-2001, a 2-cylinder 1.56 L diesel engine.
| Make & model | ZETOR Z-2001 |
|---|---|
| Cylinders | 2, liquid-cooled |
| Displacement | 95.1 ci · 1.56 L |
| Max torque | 65 lb·ft · 88 N·m |
| Injection | direct injection |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Zetor 2511”
How much will a 2511 lift, and what is its hydraulic flow?
A 2511 lifts 1,764 lb (800 kg) at the lower-link ends.
| Pump flow | 5.3 gpm · 20.0 L/min |
|---|---|
| Pressure | 2,134 psi · 147 bar |
| Lift at ends | 1,764 lb · 800 kg |
| Rear PTO | Independent, engine-driven, 540 rpmGround-speed PTO available |
Source · Traktorenlexikon, “Zetor 2511”
What transmission does a 2511 have?
Transmission specifications for the 2511 are below.
| Clutch | Pedal-operated, dry two-stage double clutch |
|---|---|
| Steering | Mechanical worm steering with two steering drag links and one tie rod |
| Top speed | 12.4 mph · 20 km/h |
Source · Traktorenlexikon, “Zetor 2511”
How much does a 2511 weigh?
A 2511 weighs 2,954 lb (1,340 kg) unladen.
| Unladen weight | 2,954 lb · 1,340 kg |
|---|---|
| Maximum front axle load | 1,764 lb · 800 kg |
| Maximum rear axle load | 2,205 lb · 1,000 kg |
| Wheelbase | 68.7 in · 1,745 mm |
| Length | 119.7 in · 3,040 mm |
| Width | 63.8 in · 1,620 mm |
| Height | 57.3 in · 1,456 mm |
| Ground clearance | 14.2 in · 360 mm |
| Front track | 50.2–67.9 in · 1,275–1,725 mm |
| Rear track | 50.2–74.0 in · 1,275–1,880 mm |
| Turning radius, braked | 8.5 ft · 2.60 m |
Source · Traktorenlexikon, “Zetor 2511”
What oil does a 2511 take, and how much?
A 2511 engine takes 5.3 qt (5.0 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 5.3 qt · 5.0 LSource: Traktorenlexikon, “Zetor 2511” · single source, not independently verified |
| Transmission | 15.9 qt · 15.0 LSource: Traktorenlexikon, “Zetor 2511” · single source, not independently verified |
| Cooling system | 7.9 qt · 7.5 LSource: Traktorenlexikon, “Zetor 2511” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a 2511?
Within 10% of its 22.7 hp of claimed engine power, the same type, and first built within 15 years of it.
- Fiat 215 (DT)21.7 hp engine, claimed · 1965–1968Side by side with the 2511 →
- SOMECA 215 (F)21.7 hp engine, claimed · 1965–1968Side by side with the 2511 →
- ZETOR 201121.7 hp engine, claimed · 1963–1967Side by side with the 2511 →
- International Harvester D-32221.7 hp engine, claimed · 1962–1965Side by side with the 2511 →
- Ford 1510 (A)21.7 hp engine, claimed · 1983–1986Side by side with the 2511 →
- Hermann Lanz D 52723.6 hp engine, claimed · 1968–1973Side by side with the 2511 →
Common questions about the ZETOR 2511
Is a 2511 two-wheel drive or four-wheel drive?
The ZETOR 2511 is two-wheel drive (2WD).
What PTO does a 2511 have?
A 2511 has a independent 540 rpm rear PTO.
Sources and how this page was built
Compiled from Traktorenlexikon, “Zetor 2511”.
