- Vehicle type: unspecified
- Rigid chassis
- WhichTractor size: Compact
- No lab test on file
- 2004–2008
WhichTractor size, not the maker’s category
We looked and the record does not say what this machine is. How we decide what a machine is
Steyr 360 Kompakt specs: hp, weight, years
IVECO 8035.05 C three-cylinder diesel. The manufacturer claimed 58.2 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
58.2 hp
43.4 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Steyr 360 Kompakt”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 6,283 lb
- Hyd. flow
- 13.8 gpm
- Top speed
- 18.6–24.9 mph
Steyr 360 Kompakt specs: key facts
The Steyr 360 Kompakt was built from 2004 to 2008.
The Steyr 360 Kompakt has a claimed engine power (gross or net not stated) of 43.4 kW (58.2 hp); it has no measured PTO figure.
The Steyr 360 Kompakt is four-wheel drive (4WD).
The Steyr 360 Kompakt has a IVECO 8035.05 C engine, a 3-cylinder 2.93 L diesel unit.
The Steyr 360 Kompakt weighs 2,850 kg (6,283 lb) unladen.
The Steyr 360 Kompakt has a rear PTO running at 430/540/540E rpm.
The hydraulic pump of the Steyr 360 Kompakt delivers 52.1 L/min (13.8 gpm).
Source · Traktorenlexikon, “Steyr 360 Kompakt”
How does the 360 Kompakt compare with its class?
- Strength:
A hydraulic pump flow of 52.1 L/min is high for its class — 59% above the median of 32.8 L/min across the 260 machines within 10% of its power that hold this figure.
Derived by WhichTractor from 316 comparable records. How we work this out
How much horsepower does a 360 Kompakt have?
The only figure for the 360 Kompakt is 58.2 hp (43.4 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Steyr 360 Kompakt”
What engine is in a 360 Kompakt?
A 360 Kompakt has an IVECO 8035.05 C, a 3-cylinder 2.93 L diesel engine.
| Make & model | IVECO 8035.05 C |
|---|---|
| Cylinders | 3, liquid-cooled |
| Displacement | 178.9 ci · 2.93 L |
| Max torque | 159 lb·ft · 216 N·m @ 1,400 rpm |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Steyr 360 Kompakt”
How much will a 360 Kompakt lift, and what is its hydraulic flow?
Hydraulic and PTO specifications for the 360 Kompakt are below.
| Pump flow | 13.8 gpm · 52.1 L/min |
|---|---|
| Rear PTO | 430/540/540E rpm |
| PTO shaft | 1 3/8"- 6 splines and 1 3/8"- 21 spline |
Source · Traktorenlexikon, “Steyr 360 Kompakt”
What transmission does a 360 Kompakt have?
Transmission specifications for the 360 Kompakt are below.
| Steering | Hydrostatic Danfoss steering |
|---|---|
| Top speed | 18.6–24.9 mph · 30–40 km/hthe article lists alternatives |
Source · Traktorenlexikon, “Steyr 360 Kompakt”
How much does a 360 Kompakt weigh?
A 360 Kompakt weighs 6,283 lb (2,850 kg) unladen.
| Unladen weight | 6,283 lb · 2,850 kg |
|---|---|
| Maximum permissible mass | 10,582 lb · 4,800 kg |
| Wheelbase | 81.3 in · 2,065 mm |
| Length | 135.4 in · 3,440 mm |
| Width | 90.6 in · 2,300 mm |
| Height | 94.9 in · 2,410 mm |
| Ground clearance | 13.8 in · 350 mm |
| Front track | 54.4–75.6 in · 1,382–1,920 mm |
| Rear track | 58.1–75.6 in · 1,475–1,920 mm |
Source · Traktorenlexikon, “Steyr 360 Kompakt”
What oil does a 360 Kompakt take, and how much?
A 360 Kompakt engine takes 7.9 qt (7.5 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 7.9 qt · 7.5 LSource: Traktorenlexikon, “Steyr 360 Kompakt” · single source, not independently verified |
| Hydraulic | 44.4 qt · 42.0 LSource: Traktorenlexikon, “Steyr 360 Kompakt” · single source, not independently verified |
| Cooling system | 12.7 qt · 12.0 LSource: Traktorenlexikon, “Steyr 360 Kompakt” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a 360 Kompakt?
Within 10% of its 58.2 hp of claimed engine power, the same type, and first built within 15 years of it.
- Case-IH JX 60 (A)58.2 hp engine, claimed · 2004–2008Side by side with the 360 Kompakt →
- New Holland TN 60 DA/SA58.2 hp engine, claimed · 2003–2008Side by side with the 360 Kompakt →
- New Holland TD 60 D (A)58.2 hp engine, claimed · 2002–2008Side by side with the 360 Kompakt →
- Fendt 206S58.9 hp engine, claimed · from 2003Side by side with the 360 Kompakt →
- Deutz-Fahr AgroXtra 3.5758.9 hp engine, claimed · 1991–1996Side by side with the 360 Kompakt →
- Fendt 206 F/FA59 hp engine, claimed · 2002–2009Side by side with the 360 Kompakt →
Common questions about the Steyr 360 Kompakt
Is a 360 Kompakt two-wheel drive or four-wheel drive?
The Steyr 360 Kompakt is four-wheel drive (4WD).
What PTO does a 360 Kompakt have?
A 360 Kompakt has a 430/540/540E rpm rear PTO on a 1 3/8"- 6 splines and 1 3/8"- 21 spline shaft.
