- Rigid chassis
- WhichTractor size: Compact
- No lab test on file
- from 2003
It was ranked on an engine power figure whose source does not say gross or net. WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Fendt 206S specs: hp, weight, years
Deutz BF 3 L 914 three-cylinder diesel. The manufacturer claimed 58.9 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
58.9 hp
43.9 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Fendt Farmer 206 S”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 6,900 lb
- 3-point lift
- 6,790 lb
- Top speed
- 24.9 mph
Fendt 206S specs: key facts
The Fendt 206S was first built in 2003.
The Fendt 206S has a claimed engine power (gross or net not stated) of 43.9 kW (58.9 hp); it has no measured PTO figure.
The Fendt 206S is four-wheel drive (4WD).
The Fendt 206S has a Deutz BF 3 L 914 engine, a 3-cylinder 3.24 L diesel unit.
The Fendt 206S weighs 3,130 kg (6,900 lb) unladen.
The Fendt 206S has an independent rear PTO running at 540/750/1000 rpm.
The three-point hitch of the Fendt 206S lifts 3,080 kg (6,790 lb) at the lower-link ends.
Source · Traktorenlexikon, “Fendt Farmer 206 S”
How does the 206S compare with its class?
- Strength:
A three-point lift at the lower links of 3,080 kg is high for its class — 36% above the median of 2,270 kg across the 266 machines within 10% of its power that hold this figure.
- Strength:
21 forward gears is high for its class — 110% above the median of 10 across the 367 machines within 10% of its power that hold this figure.
Derived by WhichTractor from 370 comparable records. How we work this out
How much horsepower does a 206S have?
The only figure for the 206S is 58.9 hp (43.9 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Fendt Farmer 206 S”
What engine is in a 206S?
A 206S has a Deutz BF 3 L 914, a 3-cylinder 3.24 L diesel engine.
| Make & model | Deutz BF 3 L 914 |
|---|---|
| Cylinders | 3, air-cooled |
| Displacement | 197.5 ci · 3.24 L |
| Max torque | 176 lb·ft · 239 N·m @ 1,500 rpm |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Fendt Farmer 206 S”
How much will a 206S lift?
A 206S lifts 6,790 lb (3,080 kg) at the lower-link ends.
| System | Load sensing |
|---|---|
| Pressure | 2,901 psi · 200 bar |
| Lift at ends | 6,790 lb · 3,080 kg |
| Rear PTO | Independent, 540/750/1000 rpmEngages under load |
Source · Traktorenlexikon, “Fendt Farmer 206 S”
What transmission does a 206S have?
Transmission specifications for the 206S are below.
| Clutch | Dry multi-plate clutch |
|---|---|
| Steering | Hydrostatic steering from Sauer-Danfos |
| Top speed | 24.9 mph · 40 km/h |
Source · Traktorenlexikon, “Fendt Farmer 206 S”
How much does a 206S weigh?
A 206S weighs 6,900 lb (3,130 kg) unladen.
| Unladen weight | 6,900 lb · 3,130 kg |
|---|---|
| Maximum permissible mass | 11,684 lb · 5,300 kg |
| Wheelbase | 82.8 in · 2,102 mm |
| Length | 140.4 in · 3,565 mm |
| Width | 75.8 in · 1,925 mm |
| Height | 97.4 in · 2,475 mm |
| Ground clearance | 15.6 in · 395 mm |
| Front track | 58.8 in · 1,494 mm |
| Rear track | 59.1 in · 1,500 mm |
| Turning radius, braked | 10.8 ft · 3.30 m |
Source · Traktorenlexikon, “Fendt Farmer 206 S”
Which tractors compare with a 206S?
Within 10% of its 58.9 hp of claimed engine power, the same type, and first built within 15 years of it.
- Deutz-Fahr AgroXtra 3.5758.9 hp engine, claimed · 1991–1996Side by side with the 206S →
- Fendt Farmer 260 P/PA58.9 hp engine, claimed · 1988–1992Side by side with the 206S →
- Fendt 206 F/FA59 hp engine, claimed · 2002–2009Side by side with the 206S →
- Fendt Farmer 260 P/PA59 hp engine, claimed · 1988–1992Side by side with the 206S →
- SAME Golden 60 Compatto59.1 hp engine, claimed · 1998–2002Side by side with the 206S →
- VALMET 60059.1 hp engine, claimed · 1997–2002Side by side with the 206S →
Common questions about the Fendt 206S
Is a 206S two-wheel drive or four-wheel drive?
The Fendt 206S is four-wheel drive (4WD).
What PTO does a 206S have?
A 206S has a independent 540/750/1000 rpm rear PTO.
Sources and how this page was built
Compiled from Traktorenlexikon, “Fendt Farmer 206 S”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- Traktorenlexikon: Fendt Farmer 206 S — CC BY-SA 4.0, WIKIBOOKS-TL-98498 · revision 883120. Wikibooks contributors (Traktorenlexikon). Original document
