- Rigid chassis
- WhichTractor size: Utility
- No lab test on file
- 1962–1965
- 12,154 built
It sits on the compact/utility boundary, so either size is a fair description. WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Renault Super 5 specs: hp, weight, years
RENAULT-ALPHA 592/30 three-cylinder diesel. The manufacturer claimed 34.5 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
34.5 hp
25.7 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Renault Super 5 R7054”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 3,587 lb
- 3-point lift
- 3,254 lb
- Hyd. flow
- 4.8 gpm
- Top speed
- 15.5 mph
Renault Super 5 specs: key facts
The Renault Super 5 was built from 1962 to 1965.
The Renault Super 5 has a claimed engine power (gross or net not stated) of 25.7 kW (34.5 hp); it has no measured PTO figure.
The Renault Super 5 is two-wheel drive (2WD).
The Renault Super 5 has a RENAULT-ALPHA 592/30 engine, a 3-cylinder 2.26 L diesel unit.
The Renault Super 5 weighs 1,627 kg (3,587 lb) unladen.
The Renault Super 5 has an independent rear PTO running at 540 rpm.
The three-point hitch of the Renault Super 5 lifts 1,476 kg (3,254 lb) at the lower-link ends.
The hydraulic pump of the Renault Super 5 delivers 18.0 L/min (4.8 gpm).
Source · Traktorenlexikon, “Renault Super 5 R7054”
How much horsepower does a Super 5 have?
The only figure for the Super 5 is 34.5 hp (25.7 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Renault Super 5 R7054”
What engine is in a Super 5?
A Super 5 has a RENAULT-ALPHA 592/30, a 3-cylinder 2.26 L diesel engine.
| Make & model | RENAULT-ALPHA 592/30 |
|---|---|
| Cylinders | 3, liquid-cooled |
| Displacement | 138.1 ci · 2.26 L |
| Max torque | 100 lb·ft · 136 N·m @ 1,648 rpm |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Renault Super 5 R7054”
How much will a Super 5 lift, and what is its hydraulic flow?
A Super 5 lifts 3,254 lb (1,476 kg) at the lower-link ends of its Category 1 three-point hitch.
| Pump flow | 4.8 gpm · 18.0 L/min |
|---|---|
| Hitch category | Category 1 |
| Lift at ends | 3,254 lb · 1,476 kg |
| Rear PTO | Independent, engine-driven, 540 rpm @ 1,582 engine rpm |
Source · Traktorenlexikon, “Renault Super 5 R7054”
What transmission does a Super 5 have?
Transmission specifications for the Super 5 are below.
| Steering | Mechanical Gemmer steering type 65 |
|---|---|
| Top speed | 15.5 mph · 25 km/h |
Source · Traktorenlexikon, “Renault Super 5 R7054”
How much does a Super 5 weigh?
A Super 5 weighs 3,587 lb (1,627 kg) unladen.
| Unladen weight | 3,587 lb · 1,627 kg |
|---|---|
| Wheelbase | 73.6 in · 1,870 mm |
| Length | 129.1 in · 3,280 mm |
| Width | 61.8–83.1 in · 1,570–2,110 mm |
| Height | 60.6 in · 1,540 mm |
| Ground clearance | 15.7 in · 400 mm |
| Front track | 47.2–74.8 in · 1,200–1,900 mm |
| Rear track | 47.2–70.9 in · 1,200–1,800 mm |
| Turning radius, braked | 10.4 ft · 3.18 m |
Source · Traktorenlexikon, “Renault Super 5 R7054”
What oil does a Super 5 take, and how much?
A Super 5 engine takes 6.3 qt (6.0 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 6.3 qt · 6.0 LSource: Traktorenlexikon, “Renault Super 5 R7054” · single source, not independently verified |
| Transmission | 21.1 qt · 20.0 LSource: Traktorenlexikon, “Renault Super 5 R7054” · single source, not independently verified |
| Cooling system | 10.6 qt · 10.0 LSource: Traktorenlexikon, “Renault Super 5 R7054” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a Super 5?
Within 10% of its 28.2 hp at the PTO as the maker claimed it, with no laboratory test on file, the same type, and first built within 15 years of it.
- OLIVER 50028.2 hp PTO, claimed · 1961–1963Side by side with the Super 5 →
- David Brown 850 Implematic28.2 hp PTO, claimed · 1960–1965Side by side with the Super 5 →
- International Harvester D-43028.1 hp PTO, claimed · 1956–1962Side by side with the Super 5 →
- Deutz F2L 514/5428.1 hp PTO, claimed · 1954–1955Side by side with the Super 5 →
- Volvo T-2528.1 hp PTO, claimed · 1952–1959Side by side with the Super 5 →
- URSUS C-33028.6 hp PTO, claimed · 1967–1987Side by side with the Super 5 →
Common questions about the Renault Super 5
Is a Super 5 two-wheel drive or four-wheel drive?
The Renault Super 5 is two-wheel drive (2WD).
What PTO does a Super 5 have?
A Super 5 has a independent 540 rpm rear PTO.
Sources and how this page was built
Compiled from Traktorenlexikon, “Renault Super 5 R7054”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- Traktorenlexikon: Renault Super 5 R7054 — CC BY-SA 4.0, WIKIBOOKS-TL-42140 · revision 993319. Wikibooks contributors (Traktorenlexikon). Original document
