- WhichTractor size: Utility
- No lab test on file
- 1972–1976
It was ranked on an engine power figure whose source does not say gross or net. WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Massey Ferguson 152 specs: hp, weight, years
Perkins AD 3.152 three-cylinder diesel. The manufacturer claimed 46.4 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
46.4 hp
34.6 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Massey Ferguson MF 152”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 3,933 lb
- 3-point lift
- 3,968 lb
- Hyd. flow
- 4.9 gpm
- Top speed
- 15.5 mph
Massey Ferguson 152 specs: key facts
The Massey Ferguson 152 was built from 1972 to 1976.
The Massey Ferguson 152 has a claimed engine power (gross or net not stated) of 34.6 kW (46.4 hp); it has no measured PTO figure.
The Massey Ferguson 152 is two-wheel drive (2WD).Source 3
The Massey Ferguson 152 has a Perkins AD 3.152 engine, a 3-cylinder 2.50 L diesel unit.Source 1
The Massey Ferguson 152 weighs 1,784 kg (3,933 lb) unladen.
The Massey Ferguson 152 has an independent rear PTO running at 540 rpm.
The three-point hitch of the Massey Ferguson 152 lifts 1,800 kg (3,968 lb) at the lower-link ends.
The hydraulic pump of the Massey Ferguson 152 delivers 18.4 L/min (4.9 gpm).
Source · Traktorenlexikon, “Massey Ferguson MF 152”
.jpg){kind=link}
How much horsepower does a 152 have?
The only figure for the 152 is 46.4 hp (34.6 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Massey Ferguson MF 152”
What engine is in a 152?
A 152 has a Perkins AD 3.152, a 3-cylinder 2.50 L diesel engine.
| Make & model | Perkins AD 3.152 |
|---|---|
| Cylinders | 3, liquid-cooledSource 2 |
| Displacement | 152.6 ci · 2.50 L |
| Max torque | 129 lb·ft · 175 N·m @ 1,380 rpmSource 2,Source 3 |
| Electrical system | 12 VSource 2 |
Source · Traktorenlexikon, “Massey Ferguson MF 148”
How much will a 152 lift, and what is its hydraulic flow?
A 152 lifts 3,968 lb (1,800 kg) at the lower-link ends.
| Pump flow | 4.9 gpm · 18.4 L/min |
|---|---|
| Pressure | 2,347 psi · 162 barSource 3Sources disagree2,589 psi · 178 bar (Traktorenlexikon, “Massey Ferguson MF 152”) |
| Hitch category | Category 1Source 3On record for 1 of 2 configurations |
| Lift at ends | 3,968 lb · 1,800 kg |
| Rear PTO | Independent, engine-driven, 540 rpm @ 1,685 engine rpmEngages under load |
| PTO shaft | 29 x 34,9 x 9,7 mm (Form-1) |
Source · Traktorenlexikon, “Massey Ferguson MF 152”
What transmission does a 152 have?
Transmission specifications for the 152 are below.
| Clutch | Pedal operated dry and air-cooled MF double clutch |
|---|---|
| Steering | Mechanical recirculating ball steering |
| Top speed | 15.5 mph · 25 km/h |
Source · Traktorenlexikon, “Massey Ferguson MF 152”
How much does a 152 weigh?
A 152 weighs 3,933 lb (1,784 kg) unladen.
| Unladen weight | 3,933 lb · 1,784 kg |
|---|---|
| Wheelbase | 81.1 in · 2,060 mm |
| Length | 126.0 in · 3,200 mm |
| Width | 72.8 in · 1,850 mm |
| Height | 92.5 in · 2,350 mm |
| Ground clearance | 13.8 in · 350 mm |
| Front track | 48.0–79.9 in · 1,220–2,030 mm |
| Rear track | 53.1–80.7 in · 1,350–2,050 mm |
Source · Traktorenlexikon, “Massey Ferguson MF 152”
What oil does a 152 take, and how much?
A 152 engine takes 7.0 qt (6.6 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 7.0 qt · 6.6 LSource: Traktorenlexikon, “Massey Ferguson MF 152” · single source, not independently verified |
| Transmission | 26.4 qt · 25.0 LSource: Traktorenlexikon, “Massey Ferguson MF 152” · single source, not independently verified |
| Cooling system | 10.8 qt · 10.2 LSource: Traktorenlexikon, “Massey Ferguson MF 152” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a 152?
Within 10% of its 46.4 hp of claimed engine power, the same type, and first built within 15 years of it.
- Massey Ferguson 14846.4 hp engine, claimed · 1972–1978Side by side with the 152 →
- Massey Ferguson 25546.4 hp engine, claimed · 1975–1981Side by side with the 152 →
- AGRIFULL 345-C (S)46.4 hp engine, claimed · 1976–1977Side by side with the 152 →
- Steyr 548 (a)46.4 hp engine, claimed · 1977–1981Side by side with the 152 →
- Ford 3600 (A)46.4 hp engine, claimed · 1981–1993Side by side with the 152 →
- Ford 361046.4 hp engine, claimed · 1981–1983Side by side with the 152 →
Common questions about the Massey Ferguson 152
Is a 152 two-wheel drive or four-wheel drive?
The Massey Ferguson 152 is two-wheel drive (2WD).
What PTO does a 152 have?
A 152 has a independent 540 rpm rear PTO on a 29 x 34,9 x 9,7 mm (Form-1) shaft.
Sources and how this page was built
Compiled from Traktorenlexikon, “Massey Ferguson MF 152 S”; Traktorenlexikon, “Massey Ferguson MF 148”; and Traktorenlexikon, “Massey Ferguson MF 152”.
