- Rigid chassis
- WhichTractor size: Standard-size
- Lab tested ×1
- 2006–2009
WhichTractor size, not the maker’s category
The source says so, in a sentence about this machine. How we decide what a machine is
John Deere 8130 Full specifications
John Deere 6090HRW01 six-cylinder or John Deere PowerTech-Plus 6.090 HRW-01 diesel. OECD put one on a dynamometer and measured 208.3 hp at the power take-off — the number to size an implement from.
Measured at the PTO shaft
208.3 hp
Source · OECD Test 2376, measured
- Drawbar hp
- 184.5
John Deere 8130 specs: key facts
The John Deere 8130 was built from 2006 to 2009 and produced 155.3 kW (208.3 hp) at the PTO, measured on OECD Test 2376.Source 1
The claimed engine power (gross or net not stated) of the John Deere 8130 is 158.2–158.2 kW (212.1–212.1 hp), depending on configuration.
The John Deere 8130 is four-wheel drive (4WD).Source 1
The John Deere 8130 has a John Deere 6090HRW01 engine, a 6-cylinder 8.98 L unit.Source 1
The John Deere 8130 weighs 9,670–10,572 kg (21,319–23,307 lb) unladen, depending on configuration.
The John Deere 8130 has an independent rear PTO running at 540/1000 rpm.Source 1
Source · Traktorenlexikon, “John Deere 8130”
How much horsepower does an 8130 have at the PTO?
At the PTO shaft an 8130 has 208.3 hp (155.3 kW), measured on OECD Test 2376.
Sources · OECD test report 2376, 2007; Traktorenlexikon, “John Deere 8130”
What engine is in an 8130?
An 8130 has a John Deere 6090HRW01, a 6-cylinder 8.98 L engine. Diesel tractors have a John Deere PowerTech-Plus 6.090 HRW-01. Diesel tractors have a John Deere PowerTech-Plus 6.090 HRW-01.
| Make & model | John Deere 6090HRW01 |
|---|---|
| Cylinders | 6, liquid-cooled |
| Displacement | 548.2 ci · 8.98 L |
| Aspiration | supercharged |
| Max torque | 674 lb·ft · 914.0 N·m @ 1,600 rpm |
Source · OECD test report 2376, 2007
How much will an 8130 lift?
Hydraulic and PTO specifications for the 8130 are below.
| System | Closed centre |
|---|---|
| Pressure | 3,336 psi · 230 barSource 2On record for 1 of 3 configurations |
| Rear PTO | 540/1000 rpm |
| PTO shaft | 45 mm, 20 splines |
Source · OECD test report 2376, 2007
What transmission does an 8130 have?
Transmission specifications for the 8130 are below.
| Clutch | Pedal-operated hydraulic wet John Deere multi-disc clutchOn record for 1 of 3 configurations |
|---|---|
| Top speed | 24.9–31.1 mph · 40–50 km/hOn record for 1 of 3 configurationsthe article lists alternatives |
Source · Traktorenlexikon, “John Deere 8130”
How much does an 8130 weigh?
Dimensions for the 8130 are below; no sourced weight is on record yet.
| Unladen weight | 21,319–23,307 lb · 9,670–10,572 kgVaries by configuration: 9,670 kg or 10,572 kgOn record for 2 of 3 configurationstwo-wheel-drive versionfour-wheel-drive version |
|---|---|
| Maximum permissible mass | 30,865 lb · 14,000 kgOn record for 1 of 3 configurations |
| Wheelbase | 120.1–126.8 in · 3,050–3,220 mmVaries by configuration: 3,050 mm or 3,220 mmOn record for 2 of 3 configurationstwo-wheel-drive versionfour-wheel-drive version |
| Length | 233.8 in · 5,938 mmOn record for 1 of 3 configurations |
| Width | 118.6 in · 3,012 mmOn record for 1 of 3 configurations |
| Height | 124.2 in · 3,155 mmOn record for 1 of 3 configurations |
| Ground clearance | 13.2–17.3 in · 336–440 mmVaries by configuration: 336 mm or 440 mmOn record for 2 of 3 configurationstwo-wheel-drive versionfour-wheel-drive version |
| Front track | 64.0–88.0 in · 1,625–2,235 mmOn record for 1 of 3 configurations |
| Rear track | 60.0–106.7 in · 1,524–2,710 mmOn record for 1 of 3 configurations |
Source · Traktorenlexikon, “John Deere 8130”
What did OECD measure on Test 2376?
OECD Test 2376 recorded 208.3 hp at the PTO and 184.5 hp at the drawbar. Configuration as printed: “4 WD · Power Shift Transmission (PST) - MFWD - 40 km/h”.
| PTO power, maximum | 208.3 hp at 847 PTO rpm · 155.3 kW @ 1,700 engine rpm |
|---|---|
| PTO power, rated engine speed | 182.2 hp at 1,047 PTO rpm · 135.9 kW @ 2,099 engine rpm |
| PTO power, standard PTO speed | 197.7 hp at 1,000 PTO rpm · 147.4 kW @ 2,006 engine rpm |
| Drawbar power, unballasted | 184.5 hp · 137.6 kW |
Source · OECD test report 2376, 2007
How much fuel does an 8130 burn per hour?
Measured on OECD Test 2376 (tested as the 8130 (4 WD)), at each condition the laboratory recorded.
Cost per hour = fuel used per hour × your fuel price (per litre, or per US gallon for the gal/h figure).
| Test condition | Fuel per hour |
|---|---|
| Maximum PTO powerPTO 155.3 kW (208.3 hp) at 847 rpm | 42.73 L/h 11.29 gal/h |
| Rated engine speedPTO 135.9 kW (182.2 hp) at 1,047 rpm | 39.15 L/h 10.34 gal/h |
| Standard PTO speedPTO 147.4 kW (197.7 hp) at 1,000 rpm | 40.91 L/h 10.81 gal/h |
| 75% load, 50% load | Not on record for this test |
Source · OECD Test 2376
Which tractors compare with an 8130?
Within 10% of its 208.3 hp at the PTO (measured), the same type, and first built within 15 years of it.
- Case-IH MX 220209.2 hp PTO, measured · 1999–2002Side by side with the 8130 →
- Case-IH 7240 PRO/8940206.8 hp PTO, claimed · 1997–1999Side by side with the 8130 →
- Steyr-Case 9250 a206.8 hp PTO, claimed · 1997–1999Side by side with the 8130 →
- Massey Ferguson MF 8450209.9 hp PTO, claimed · 2004–2008Side by side with the 8130 →
- New Holland TG 230213.6 hp PTO, claimed · 2002–2005Side by side with the 8130 →
- Massey Ferguson MF 8270 A214.6 hp PTO, claimed · 1999–2002Side by side with the 8130 →
Everything else people ask
Is an 8130 two-wheel drive or four-wheel drive?
The John Deere 8130 is four-wheel drive (4WD).
What PTO does an 8130 have?
An 8130 has a 540/1000 rpm rear PTO on a 45 mm, 20 splines shaft.
What implements will an 8130 run?
Size PTO implements from the measured 208.3 hp at the shaft.
Where this page comes from
Compiled from OECD tractor test report 2376; and Traktorenlexikon, “John Deere 8130”.
