- WhichTractor size: Utility
- Not independently tested
- 2002–2009
- 568 built
It was ranked on an engine power figure whose source does not say gross or net. WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Fendt 209 VA/VA-breit Full specifications
The manufacturer claimed 89 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
89 hp
66 kW as stated by the source
Not independently tested
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Fendt Farmer 209 VA”, claimed
- Weight
- 5,611 lb
- Hyd. flow
- 19.5 gpm
- Top speed
- 21.7 mph
Fendt 209 VA/VA-breit specs: key facts
The Fendt 209 VA/VA-breit was built from 2002 to 2009.
The Fendt 209 VA/VA-breit has a claimed engine power (gross or net not stated) of 66 kW (89 hp); it has no measured PTO figure.
The Fendt 209 VA/VA-breit is four-wheel drive (4WD).
The Fendt 209 VA/VA-breit weighs 2,545 kg (5,611 lb) unladen.
The Fendt 209 VA/VA-breit has a rear PTO running at 540/750/1000 rpm.
The hydraulic pump of the Fendt 209 VA/VA-breit delivers 74.0 L/min (19.5 gpm).
Source · Traktorenlexikon, “Fendt Farmer 209 VA”
How much horsepower does a 209 VA/VA-breit have?
The only figure for the 209 VA/VA-breit is 89 hp (66 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Fendt Farmer 209 VA”
How much will a 209 VA/VA-breit lift, and what is its hydraulic flow?
Hydraulic and PTO specifications for the 209 VA/VA-breit are below.
| System | Load sensing |
|---|---|
| Pump flow | 19.5 gpm · 74.0 L/min |
| Pressure | 2,901 psi · 200 bar |
| Rear PTO | 540/750/1000 rpm |
Source · Traktorenlexikon, “Fendt Farmer 209 VA”
What transmission does a 209 VA/VA-breit have?
Transmission specifications for the 209 VA/VA-breit are below.
| Clutch | dry multi-plate clutch |
|---|---|
| Brakes | wet internal multi-disc full disc brake acting on the rear wheels |
| Steering | hydrostatic steering type Sauer-Danfos OSPF 60 LSR |
| Top speed | 21.7 mph · 35 km/h |
Source · Traktorenlexikon, “Fendt Farmer 209 VA”
How much does a 209 VA/VA-breit weigh?
A 209 VA/VA-breit weighs 5,611 lb (2,545 kg) unladen.
| Unladen weight | 5,611 lb · 2,545 kg |
|---|---|
| Maximum permissible mass | 8,818 lb · 4,000 kg |
| Wheelbase | 83.8 in · 2,128 mm |
| Length | 139.8 in · 3,550 mm |
| Width | 45.5–47.0 in · 1,155–1,193 mmthe article lists alternatives |
| Height | 92.8 in · 2,357 mm |
| Ground clearance | 8.7 in · 220 mm |
| Front track | 33.2 in · 844 mmbreit = 952 |
| Rear track | 32.7 in · 831 mmbreit = 897 |
Source · Traktorenlexikon, “Fendt Farmer 209 VA”
Which tractors compare with a 209 VA/VA-breit?
Within 10% of its 89 hp of claimed engine power, the same type, and first built within 15 years of it.
- Fendt 209 FA89 hp engine, claimed · 2002–2009Side by side with the 209 VA/VA-breit →
- Fendt 209 PA89 hp engine, claimed · 2002–2009Side by side with the 209 VA/VA-breit →
- Deutz-Fahr Agroplus S 10089 hp engine, claimed · 2005–2007Side by side with the 209 VA/VA-breit →
- New Holland TN 95 DA89 hp engine, claimed · 2006–2007Side by side with the 209 VA/VA-breit →
- URSUS 104489 hp engine, claimed · 1997–1999Side by side with the 209 VA/VA-breit →
- Deutz-Fahr Agrocompact 100 V/F88.8 hp engine, claimed · 2004–2006Side by side with the 209 VA/VA-breit →
Everything else people ask
Is a 209 VA/VA-breit two-wheel drive or four-wheel drive?
The Fendt 209 VA/VA-breit is four-wheel drive (4WD).
What PTO does a 209 VA/VA-breit have?
A 209 VA/VA-breit has a 540/750/1000 rpm rear PTO.
Where this page comes from
Compiled from Traktorenlexikon, “Fendt Farmer 209 VA”.
