- Rigid chassis
- WhichTractor size: Utility
- No lab test on file
- 1954–1959
- 8,021 built
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Fahr D 180H specs: hp, weight, years
MWM AKD-12 Z or AKD-112 Z two-cylinder diesel. The manufacturer claimed 23.7 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
23.7 hp
17.7 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Fahr D 180 H”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 3,142 lb
- Top speed
- 12.4 mph
Fahr D 180H specs: key facts
The Fahr D 180H was built from 1954 to 1959.
The Fahr D 180H has a claimed engine power (gross or net not stated) of 17.7 kW (23.7 hp); it has no measured PTO figure.
The Fahr D 180H is two-wheel drive (2WD).
The Fahr D 180H has a MWM AKD-12 Z or AKD-112 Z engine, a 2-cylinder 1.81 L diesel unit.
The Fahr D 180H weighs 1,425 kg (3,142 lb) unladen.
The Fahr D 180H has a dependent rear PTO running at 600 rpm.
Source · Traktorenlexikon, “Fahr D 180 H”
How much horsepower does a D 180H have?
The only figure for the D 180H is 23.7 hp (17.7 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Fahr D 180 H”
What engine is in a D 180H?
A D 180H has an MWM AKD-12 Z or AKD-112 Z, a 2-cylinder 1.81 L diesel engine.
| Make & model | MWM AKD-12 Z or AKD-112 Z |
|---|---|
| Cylinders | 2, air-cooled |
| Displacement | 110.5 ci · 1.81 L |
| Max torque | 66 lb·ft · 89 N·m @ 1,500 rpm |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Fahr D 180 H”
How much will a D 180H lift?
Hydraulic and PTO specifications for the D 180H are below.
| Pressure | 3,129 psi · 216 bar |
|---|---|
| Rear PTO | Dependent, transmission-driven, 600 rpm |
Source · Traktorenlexikon, “Fahr D 180 H”
What transmission does a D 180H have?
Transmission specifications for the D 180H are below.
| Steering | ZF steering |
|---|---|
| Top speed | 12.4 mph · 20 km/h |
Source · Traktorenlexikon, “Fahr D 180 H”
How much does a D 180H weigh?
A D 180H weighs 3,142 lb (1,425 kg) unladen.
| Unladen weight | 3,142 lb · 1,425 kg |
|---|---|
| Maximum permissible mass | 4,409 lb · 2,000 kg |
| Wheelbase | 71.6 in · 1,818 mm |
| Length | 110.6 in · 2,810 mm |
| Width | 61.5 in · 1,562 mm |
| Height | 62.2 in · 1,580 mm |
| Ground clearance | 15.4 in · 390 mm |
| Front track | 49.2–59.1 in · 1,250–1,500 mmWikibooks gives one track for both axles; the article lists alternatives |
| Rear track | 49.2–59.1 in · 1,250–1,500 mmWikibooks gives one track for both axles; the article lists alternatives |
| Turning radius, braked | 8.4 ft · 2.55 m |
Source · Traktorenlexikon, “Fahr D 180 H”
What oil does a D 180H take, and how much?
A D 180H engine takes 5.3 qt (5 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 5.3 qt · 5 LSource: Traktorenlexikon, “Fahr D 180 H” · single source, not independently verified |
| Transmission | 0.3 qt · 0 LSource: Traktorenlexikon, “Fahr D 180 H” · single source, not independently verified |
| Hydraulic | 9.5 qt · 9 LSource: Traktorenlexikon, “Fahr D 180 H” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a D 180H?
Within 10% of its 23 hp at the PTO as the maker claimed it, with no laboratory test on file, the same type, and first built within 15 years of it.
- Fahr D 185H23 hp PTO, claimed · 1956Side by side with the D 180H →
- Güldner AB23 hp PTO, claimed · 1958–1959Side by side with the D 180H →
- Fahr D 133N23 hp PTO, claimed · 1959–1961Side by side with the D 180H →
- Fahr D 133T23 hp PTO, claimed · 1959–1961Side by side with the D 180H →
- Güldner A 2 BL23 hp PTO, claimed · 1959–1960Side by side with the D 180H →
- Fahr D 28 UW23 hp PTO, claimed · 1948–1951Side by side with the D 180H →
Common questions about the Fahr D 180H
Is a D 180H two-wheel drive or four-wheel drive?
The Fahr D 180H is two-wheel drive (2WD).
What PTO does a D 180H have?
A D 180H has a dependent 600 rpm rear PTO.
Sources and how this page was built
Compiled from Traktorenlexikon, “Fahr D 180 H”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- Traktorenlexikon: Fahr D 180 H — CC BY-SA 4.0, WIKIBOOKS-TL-37239 · revision 956434. Wikibooks contributors (Traktorenlexikon). Original document
