- Rigid chassis
- WhichTractor size: Compact
- Not independently tested
- 1982–1988
- 11,800 built
It was ranked on an engine power figure whose source does not say gross or net. WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Deutz-Fahr D 3607 Full specifications
KHD F2L 912 two-cylinder diesel. The manufacturer claimed 34 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
34 hp
25 kW as stated by the source
Not independently tested
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Deutz-Fahr D 3607”, claimed
- Weight
- 4,255 lb
- 3-point lift
- 4,189 lb
- Hyd. flow
- 9.2 gpm
- Top speed
- 15.5–18.6 mph
Deutz-Fahr D 3607 specs: key facts
The Deutz-Fahr D 3607 was built from 1982 to 1988.
The Deutz-Fahr D 3607 has a claimed engine power (gross or net not stated) of 25 kW (34 hp); it has no measured PTO figure.
The Deutz-Fahr D 3607 is two-wheel drive (2WD).
The Deutz-Fahr D 3607 has a KHD F2L 912 engine, a 2-cylinder 1.88 L diesel unit.Source 1
The Deutz-Fahr D 3607 weighs 1,930 kg (4,255 lb) unladen.
The Deutz-Fahr D 3607 has an independent rear PTO running at 600 rpm.
The three-point hitch of the Deutz-Fahr D 3607 lifts 1,900 kg (4,189 lb) at the lower-link ends.
The hydraulic pump of the Deutz-Fahr D 3607 delivers 35 L/min (9.2 gpm).
Source · Traktorenlexikon, “Deutz-Fahr D 3607”
How much horsepower does a D 3607 have?
The only figure for the D 3607 is 34 hp (25 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Deutz-Fahr D 3607”
What engine is in a D 3607?
A D 3607 has a KHD F2L 912, a 2-cylinder 1.88 L diesel engine.
| Make & model | KHD F2L 912Source 1 |
|---|---|
| Cylinders | 2, air-cooledSource 1 |
| Displacement | 115.0 ci · 1.88 LSource 1 |
| Max torque | 86 lb·ft · 117 N·m @ 1,600 rpm |
| Injection | direct injection |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Deutz-Fahr D 3607”
How much will a D 3607 lift, and what is its hydraulic flow?
A D 3607 lifts 4,189 lb (1,900 kg) at the lower-link ends.
| Pump flow | 9.2 gpm · 35 L/min |
|---|---|
| Lift at ends | 4,189 lb · 1,900 kg |
| Rear PTO | Independent, engine-driven, 600 rpm |
| PTO shaft | 29 x 34,9 x 8,7 mm (Form-A) |
Source · Traktorenlexikon, “Deutz-Fahr D 3607”
What transmission does a D 3607 have?
Transmission specifications for the D 3607 are below.
| Steering | mechanical ZF Gemmer steering |
|---|---|
| Top speed | 15.5–18.6 mph · 25–30 km/hthe article lists alternatives |
Source · Traktorenlexikon, “Deutz-Fahr D 3607”
How much does a D 3607 weigh?
A D 3607 weighs 4,255 lb (1,930 kg) unladen.
| Unladen weight | 4,255 lb · 1,930 kg |
|---|---|
| Maximum permissible mass | 7,055 lb · 3,200 kg |
| Maximum front axle load | 2,976 lb · 1,350 kg |
| Maximum rear axle load | 5,512 lb · 2,500 kg |
| Wheelbase | 73.4 in · 1,865 mm |
| Length | 131.1 in · 3,330 mm |
| Width | 63.0 in · 1,600 mm |
| Height | 92.5 in · 2,350 mm |
| Ground clearance | 18.1 in · 460 mm |
| Front track | 49.2–51.2 in · 1,250–1,300 mmthe article lists alternatives |
| Rear track | 49.2–68.9 in · 1,250–1,750 mm |
Source · Traktorenlexikon, “Deutz-Fahr D 3607”
Which tractors compare with a D 3607?
Within 10% of its 34 hp of claimed engine power, the same type, and first built within 15 years of it.
- SAME Delfino 35 (1981-1995)34 hp engine, claimed · 1981–1995Side by side with the D 3607 →
- UTB U-340 (DTC)34 hp engine, claimed · 1987–1991Side by side with the D 3607 →
- Lamborghini R-235 (DT)34 hp engine, claimed · 1972–1989Side by side with the D 3607 →
- SAME Delfino 35 (DT)34 hp engine, claimed · 1972–1981Side by side with the D 3607 →
- Fiat 400 V/E34 hp engine, claimed · 1968–1971Side by side with the D 3607 →
- SOMECA 400 (DT)34 hp engine, claimed · 1968–1971Side by side with the D 3607 →
Everything else people ask
Is a D 3607 two-wheel drive or four-wheel drive?
The Deutz-Fahr D 3607 is two-wheel drive (2WD).
What PTO does a D 3607 have?
A D 3607 has a independent 600 rpm rear PTO on a 29 x 34,9 x 8,7 mm (Form-A) shaft.
Where this page comes from
Compiled from Traktorenlexikon, “Deutz D 2506”; and Traktorenlexikon, “Deutz-Fahr D 3607”.
