- WhichTractor size: Standard-size
- Not independently tested
- 1975–1978
- 9 built
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Bührer 6135 Full specifications
MERCEDES-BENZ OM-352 A diesel. The manufacturer claimed 133 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
133 hp
Not independently tested
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Bührer 6135”, claimed
- Weight
- 8,488 lb
- Top speed
- 15.5 mph
Bührer 6135 specs: key facts
The Bührer 6135 was built from 1975 to 1978.
The Bührer 6135 has a claimed engine power (gross or net not stated) of 99.3 kW (133 hp); it has no measured PTO figure.
The Bührer 6135 was built in two-wheel drive (2WD) and four-wheel drive (4WD) versions, depending on configuration.Source 2
The Bührer 6135 weighs 3,850 kg (8,488 lb) unladen.
The Bührer 6135 has an independent rear PTO running at 540/800 rpm.Source 2
The three-point hitch of the Bührer 6135 lifts 2,375 kg (5,236 lb) at the lower-link ends.Source 2
The hydraulic pump of the Bührer 6135 delivers 39.0 L/min (10.3 gpm).Source 2
Source · Traktorenlexikon, “Bührer 6135”
How much horsepower does a 6135 have?
The only figure for the 6135 is 133 hp (99.3 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Bührer 6135”
How much will a 6135 lift?
Hydraulic and PTO specifications for the 6135 are below.
| Pump flow | 10.3 gpm · 39.0 L/minOn record for 1 of 3 configurations |
|---|---|
| Pressure | 2,845 psi · 196 barOn record for 1 of 3 configurations |
| Hitch category | Category 2On record for 1 of 3 configurations |
| Lift at ends | 5,236 lb · 2,375 kgOn record for 1 of 3 configurations |
Source · Traktorenlexikon, “Bührer 6135 (A)”
What transmission does a 6135 have?
Transmission specifications for the 6135 are below.
| Clutch | Pedal operated dry Buerhrer twin disc clutch as driving clutchOn record for 1 of 3 configurations |
|---|---|
| Steering | ZF spindle hydraulic steering with separate oil circuitOn record for 1 of 3 configurations |
| Top speed | 15.5 mph · 25 km/hSource 134 |
Source · Traktorenlexikon, “Bührer 6135 (A)”
How much does a 6135 weigh?
A 6135 weighs 8,488 lb (3,850 kg) unladen.
| Unladen weight | 8,488 lb · 3,850 kgSource 14150 |
|---|---|
| Maximum permissible mass | 14,330 lb · 6,500 kgOn record for 1 of 3 configurations |
| Wheelbase | 103.5–107.5 in · 2,630–2,730 mmVaries by configuration: 2,630 mm or 2,730 mmOn record for 2 of 3 configurationstwo-wheel-drive versionfour-wheel-drive version |
| Length | 166.5 in · 4,230 mmOn record for 1 of 3 configurations |
| Width | 81.9 in · 2,080 mmOn record for 1 of 3 configurations |
| Height | 97.6 in · 2,480 mmOn record for 1 of 3 configurations |
| Ground clearance | 15.0–15.7 in · 380–400 mmVaries by configuration: 380 mm or 400 mmOn record for 2 of 3 configurationstwo-wheel-drive versionfour-wheel-drive version |
| Front track | 59.1–68.9 in · 1,500–1,750 mmVaries by configuration: 1,500–1,750 mm or 1,644–1,670 mmOn record for 2 of 3 configurationstwo-wheel-drive versionfour-wheel-drive version |
| Rear track | 64.7–74.8 in · 1,644–1,900 mmOn record for 1 of 3 configurationsthe article lists alternatives |
Source · Traktorenlexikon, “Bührer 6135 (A)”
Which tractors compare with a 6135?
Within 10% of its 133 hp of claimed engine power, the same type, and first built within 15 years of it.
- SOMECA 1380 (TD)133.2 hp engine, claimed · 1979–1983Side by side with the 6135 →
- Lamborghini R-1356 DT133.2 hp engine, claimed · 1980–1984Side by side with the 6135 →
- Hürlimann D-550 Hydrostat133.0 hp engine, claimed · 1974Side by side with the 6135 →
- Renault 145-54 TX133.3 hp engine, claimed · 1989–1990Side by side with the 6135 →
- Fendt Favorit 614 SA132.6 hp engine, claimed · 1974–1976Side by side with the 6135 →
- Fendt Favorit 612 LS132.5 hp engine, claimed · 1983–1987Side by side with the 6135 →
Everything else people ask
Is a 6135 two-wheel drive or four-wheel drive?
The Bührer 6135 was built in two-wheel drive (2WD) and four-wheel drive (4WD) versions, depending on configuration.
Where this page comes from
Compiled from Traktorenlexikon, “Bührer 6135 (A)”; and Traktorenlexikon, “Bührer 6135”.
