- Rigid chassis
- WhichTractor size: Utility
- No lab test on file
- 1972–1977
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
ZETOR 6711 specs: hp, weight, years
ZETOR Z-6701 four-cylinder diesel. The manufacturer claimed 64.1 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
64.1 hp
47.8 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Zetor 6711”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 5,776 lb
- Hyd. flow
- 5.3 gpm
- Top speed
- 15.5 mph
ZETOR 6711 specs: key facts
The ZETOR 6711 was built from 1972 to 1977.
The ZETOR 6711 has a claimed engine power (gross or net not stated) of 47.8 kW (64.1 hp); it has no measured PTO figure.
The ZETOR 6711 was offered in two-wheel-drive and four-wheel-drive versions.
The ZETOR 6711 has a ZETOR Z-6701 engine, a 4-cylinder 3.46 L diesel unit.
The ZETOR 6711 weighs 2,620 kg (5,776 lb) unladen.
The ZETOR 6711 has a rear PTO running at 540 rpm.
The hydraulic pump of the ZETOR 6711 delivers 20.0 L/min (5.3 gpm).
Source · Traktorenlexikon, “Zetor 6711”
How does the 6711 compare with its class?
- Limitation:
A hydraulic pump flow of 20 L/min is low for its class — 46% below the median of 37 L/min across the 327 machines within 10% of its power that hold this figure.
Derived by WhichTractor from 395 comparable records. How we work this out
.jpg){kind=link}
How much horsepower does a 6711 have?
The only figure for the 6711 is 64.1 hp (47.8 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Zetor 6711”
What engine is in a 6711?
A 6711 has a ZETOR Z-6701, a 4-cylinder 3.46 L diesel engine.
| Make & model | ZETOR Z-6701 |
|---|---|
| Cylinders | 4, liquid-cooled |
| Displacement | 210.9 ci · 3.46 L |
| Max torque | 148 lb·ft · 201 N·m @ 1,506 rpm |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Zetor 6711”
How much will a 6711 lift, and what is its hydraulic flow?
Hydraulic and PTO specifications for the 6711 are below.
| Pump flow | 5.3 gpm · 20.0 L/min |
|---|---|
| Rear PTO | 540 rpm @ 1,993 engine rpm |
Source · Traktorenlexikon, “Zetor 6711”
What transmission does a 6711 have?
Transmission specifications for the 6711 are below.
| Clutch | Pedal-actuated, dry two-stage ZETOR double clutch with mechanical clutch booster |
|---|---|
| Top speed | 15.5 mph · 25 km/h |
Source · Traktorenlexikon, “Zetor 6711”
How much does a 6711 weigh?
A 6711 weighs 5,776 lb (2,620 kg) unladen.
| Unladen weight | 5,776 lb · 2,620 kgtwo-wheel-drive version |
|---|---|
| Wheelbase | 88.5 in · 2,247 mmtwo-wheel-drive version |
| Length | 144.5 in · 3,670 mm |
| Width | 70.5 in · 1,790 mmtwo-wheel-drive version |
| Height | 64.4 in · 1,635 mmtwo-wheel-drive version |
| Ground clearance | 13.0 in · 330 mmtwo-wheel-drive version |
| Front track | 56.3–72.8 in · 1,430–1,850 mmtwo-wheel-drive version |
| Rear track | 56.1–70.9 in · 1,425–1,800 mm |
| Turning radius, braked | 11.7 ft · 3.56 mtwo-wheel-drive version |
Source · Traktorenlexikon, “Zetor 6711”
What oil does a 6711 take, and how much?
A 6711 engine takes 12.7 qt (12.0 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 12.7 qt · 12.0 LSource: Traktorenlexikon, “Zetor 6711” · single source, not independently verified |
| Transmission & hydraulic | 26.4 qt · 25.0 LSource: Traktorenlexikon, “Zetor 6711” · single source, not independently verified |
| Front axle | 7.4 qt · 7.0 LSource: Traktorenlexikon, “Zetor 6711” · single source, not independently verified |
| Cooling system | 13.7 qt · 13.0 LSource: Traktorenlexikon, “Zetor 6711” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a 6711?
Within 10% of its 64.1 hp of claimed engine power, the same type, and first built within 15 years of it.
- Renault 651 (S)64.1 hp engine, claimed · 1972–1986Side by side with the 6711 →
- Renault 651-4 (S)64.1 hp engine, claimed · 1972–1987Side by side with the 6711 →
- Fiat 650 (DT)64.1 hp engine, claimed · 1971–1976Side by side with the 6711 →
- Landini R-6500 (DT)64.1 hp engine, claimed · 1973–1983Side by side with the 6711 →
- SOMECA 650 (TD)64.1 hp engine, claimed · 1971–1976Side by side with the 6711 →
- UTB U-650/651M64.1 hp engine, claimed · 1973–1990Side by side with the 6711 →
Common questions about the ZETOR 6711
Is a 6711 two-wheel drive or four-wheel drive?
The ZETOR 6711 was offered in two-wheel-drive and four-wheel-drive versions.
What PTO does a 6711 have?
A 6711 has a 540 rpm rear PTO.
Sources and how this page was built
Compiled from Traktorenlexikon, “Zetor 6711”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- Traktorenlexikon: Zetor 6711 — CC BY-SA 4.0, WIKIBOOKS-TL-112193 · revision 1076744. Wikibooks contributors (Traktorenlexikon). Original document
