- Rigid chassis
- WhichTractor size: Utility
- No lab test on file
- 1972–1978
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
SAME Minitauro 60 specs: hp, weight, years
SAME DA 038-1053 L three-cylinder diesel. The manufacturer claimed 55.3 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
55.3 hp
41.2 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “SAME Minitauro 60”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 4,211 lb
- 3-point lift
- 4,321 lb
- Hyd. flow
- 5.5 gpm
- Top speed
- 15.5 mph
SAME Minitauro 60 specs: key facts
The SAME Minitauro 60 was built from 1972 to 1978.
The SAME Minitauro 60 has a claimed engine power (gross or net not stated) of 41.2 kW (55.3 hp); it has no measured PTO figure.
The SAME Minitauro 60 was offered in two-wheel-drive and four-wheel-drive versions.
The SAME Minitauro 60 has a SAME DA 038-1053 L engine, a 3-cylinder 3.12 L diesel unit.
The SAME Minitauro 60 weighs 1,910 kg (4,211 lb) unladen.
The SAME Minitauro 60 has a rear PTO running at 540 rpm.
The three-point hitch of the SAME Minitauro 60 lifts 1,960 kg (4,321 lb) at the lower-link ends.
The hydraulic pump of the SAME Minitauro 60 delivers 21.0 L/min (5.5 gpm).
Source · Traktorenlexikon, “SAME Minitauro 60”
How does the Minitauro 60 compare with its class?
- Limitation:
A hydraulic pump flow of 21 L/min is low for its class — 36% below the median of 32.8 L/min across the 261 machines within 10% of its power that hold this figure.
- Worth knowing:
An unladen mass of 1,910 kg is low for its class — 24% below the median of 2,520 kg across the 323 machines within 10% of its power that hold this figure.
Derived by WhichTractor from 323 comparable records. How we work this out
How much horsepower does a Minitauro 60 have?
The only figure for the Minitauro 60 is 55.3 hp (41.2 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “SAME Minitauro 60”
What engine is in a Minitauro 60?
A Minitauro 60 has an SAME DA 038-1053 L, a 3-cylinder 3.12 L diesel engine.
| Make & model | SAME DA 038-1053 L |
|---|---|
| Cylinders | 3, air-cooled |
| Displacement | 190.2 ci · 3.12 L |
| Max torque | 145 lb·ft · 197 N·m @ 1,478 rpm |
| Injection | Direct injection |
Source · Traktorenlexikon, “SAME Minitauro 60”
How much will a Minitauro 60 lift, and what is its hydraulic flow?
A Minitauro 60 lifts 4,321 lb (1,960 kg) at the lower-link ends of its Category 1 three-point hitch.
| Pump flow | 5.5 gpm · 21.0 L/min |
|---|---|
| Hitch category | Category 1 |
| Lift at ends | 4,321 lb · 1,960 kg |
| Rear PTO | 540 rpm @ 1,980 engine rpm |
| PTO shaft | 1 3/8"- 6 splines (Form-1) |
Source · Traktorenlexikon, “SAME Minitauro 60”
What transmission does a Minitauro 60 have?
Transmission specifications for the Minitauro 60 are below.
| Clutch | Pedal operated dry two stage double clutch with coil springs |
|---|---|
| Steering | Mechanical CAM GEARS steering |
| Top speed | 15.5 mph · 25 km/h |
Source · Traktorenlexikon, “SAME Minitauro 60”
How much does a Minitauro 60 weigh?
A Minitauro 60 weighs 4,211 lb (1,910 kg) unladen.
| Unladen weight | 4,211 lb · 1,910 kgDT: 2,055 |
|---|---|
| Wheelbase | 77.6 in · 1,970 mmDT: 1,960 |
| Length | 133.9 in · 3,400 mm |
| Width | 66.3–90.0 in · 1,685–2,285 mm |
| Height | 92.9 in · 2,360 mm |
| Ground clearance | 13.4 in · 340 mmDT: 350 |
| Front track | 47.2–74.8 in · 1,200–1,900 mmDT: 1,340 |
| Rear track | 47.2–74.8 in · 1,200–1,900 mm |
| Turning radius, braked | 9.8 ft · 2.99 mDT: 3,200 |
Source · Traktorenlexikon, “SAME Minitauro 60”
What oil does a Minitauro 60 take, and how much?
A Minitauro 60 engine takes 9.0 qt (8.5 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 9.0 qt · 8.5 LSource: Traktorenlexikon, “SAME Minitauro 60” · single source, not independently verified |
| Transmission | 40.2 qt · 38.0 LSource: Traktorenlexikon, “SAME Minitauro 60” · single source, not independently verified |
| Hydraulic | 11.1 qt · 10.5 LSource: Traktorenlexikon, “SAME Minitauro 60” · single source, not independently verified |
| Front axle | 4.6 qt · 4.4 LSource: Traktorenlexikon, “SAME Minitauro 60” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a Minitauro 60?
Within 10% of its 52.39 hp at the PTO as the maker claimed it, with no laboratory test on file, the same type, and first built within 15 years of it.
- Fiat 640 (DT)52.4 hp PTO, claimed · 1973–1982Side by side with the Minitauro 60 →
- David Brown 121252.5 hp PTO, claimed · 1971–1976Side by side with the Minitauro 60 →
- Hürlimann D-150S52.5 hp PTO, claimed · 1966–1971Side by side with the Minitauro 60 →
- Leyland 26252.3 hp PTO, claimed · 1975–1980Side by side with the Minitauro 60 →
- Massey Ferguson 16552.3 hp PTO, claimed · 1964–1971Side by side with the Minitauro 60 →
- Renault Master 252.6 hp PTO, claimed · 1964–1969Side by side with the Minitauro 60 →
Common questions about the SAME Minitauro 60
Is a Minitauro 60 two-wheel drive or four-wheel drive?
The SAME Minitauro 60 was offered in two-wheel-drive and four-wheel-drive versions.
What PTO does a Minitauro 60 have?
A Minitauro 60 has a 540 rpm rear PTO on a 1 3/8"- 6 splines (Form-1) shaft.
Sources and how this page was built
Compiled from Traktorenlexikon, “SAME Minitauro 60”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- Traktorenlexikon: SAME Minitauro 60 — CC BY-SA 4.0, WIKIBOOKS-TL-103821 · revision 1024246. Wikibooks contributors (Traktorenlexikon). Original document
