- Rigid chassis
- WhichTractor size: Utility
- No lab test on file
- 1956–1960
- 31,910 built
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Renault D-22 specs: hp, weight, years
MWM AKD 112 Z two-cylinder diesel. The manufacturer claimed 21.7 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
21.7 hp
16.2 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Renault D22 R7052”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 3,263 lb
- 3-point lift
- 2,866 lb
- Hyd. flow
- 4.0 gpm
- Top speed
- 15.5 mph
Renault D-22 specs: key facts
The Renault D-22 was built from 1956 to 1960.
The Renault D-22 has a claimed engine power (gross or net not stated) of 16.2 kW (21.7 hp); it has no measured PTO figure.
The Renault D-22 is two-wheel drive (2WD).
The Renault D-22 has a MWM AKD 112 Z engine, a 2-cylinder 1.81 L diesel unit.Source 1
The Renault D-22 weighs 1,480 kg (3,263 lb) unladen.
The Renault D-22 has a rear PTO running at 540 rpm.
The three-point hitch of the Renault D-22 lifts 1,300 kg (2,866 lb) at the lower-link ends.
The hydraulic pump of the Renault D-22 delivers 15.0 L/min (4.0 gpm).
Source · Traktorenlexikon, “Renault D22 R7052”
.jpg){kind=link}
How much horsepower does a D-22 have?
The only figure for the D-22 is 21.7 hp (16.2 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Renault D22 R7052”
What engine is in a D-22?
A D-22 has an MWM AKD 112 Z, a 2-cylinder 1.81 L diesel engine.
| Make & model | MWM AKD 112 Z |
|---|---|
| Cylinders | 2, air-cooledSource 2 |
| Displacement | 110.5 ci · 1.81 L |
| Electrical system | 12 VSource 2 |
Source · Traktorenlexikon, “Fendt Farmer 1 Z”
How much will a D-22 lift, and what is its hydraulic flow?
A D-22 lifts 2,866 lb (1,300 kg) at the lower-link ends of its Category 1 three-point hitch.
| Pump flow | 4.0 gpm · 15.0 L/min |
|---|---|
| Hitch category | Category 1 |
| Lift at ends | 2,866 lb · 1,300 kg |
| Rear PTO | 540 rpm @ 1,582 engine rpm |
| PTO shaft | 34 x 28 x 6 mm |
Source · Traktorenlexikon, “Renault D22 R7052”
What transmission does a D-22 have?
Transmission specifications for the D-22 are below.
| Clutch | Pedal-operated dry FERODO single-disc clutch |
|---|---|
| Steering | Mechanical GEMMER steering |
| Top speed | 15.5 mph · 25 km/h |
Source · Traktorenlexikon, “Renault D22 R7052”
How much does a D-22 weigh?
A D-22 weighs 3,263 lb (1,480 kg) unladen.
| Unladen weight | 3,263 lb · 1,480 kg |
|---|---|
| Wheelbase | 67.7 in · 1,720 mm |
| Length | 118.1 in · 3,000 mm |
| Width | 61.8–83.1 in · 1,570–2,110 mm |
| Height | 60.6 in · 1,540 mm |
| Ground clearance | 15.0 in · 380 mm |
| Front track | 47.2–74.8 in · 1,200–1,900 mm |
| Rear track | 47.2–70.9 in · 1,200–1,800 mm |
| Turning radius, braked | 9.6 ft · 2.92 m |
Source · Traktorenlexikon, “Renault D22 R7052”
What oil does a D-22 take, and how much?
A D-22 engine takes 5.3 qt (5.0 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 5.3 qt · 5.0 LSource: Traktorenlexikon, “Renault D22 R7052” · single source, not independently verified |
| Transmission | 21.1 qt · 20.0 LSource: Traktorenlexikon, “Renault D22 R7052” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with a D-22?
Within 10% of its 20.6 hp at the PTO as the maker claimed it, with no laboratory test on file, the same type, and first built within 15 years of it.
- Renault N 7220.6 hp PTO, claimed · 1960–1964Side by side with the D-22 →
- Güldner ALB21 hp PTO, claimed · 1955–1958Side by side with the D-22 →
- Fahr D 16021 hp PTO, claimed · 1954Side by side with the D-22 →
- Fahr D 160H21 hp PTO, claimed · 1954–1956Side by side with the D-22 →
- Fahr D 22 PH21 hp PTO, claimed · 1951–1953Side by side with the D-22 →
- Porsche-Diesel 20820.3 hp PTO, claimed · 1957Side by side with the D-22 →
Common questions about the Renault D-22
Is a D-22 two-wheel drive or four-wheel drive?
The Renault D-22 is two-wheel drive (2WD).
What PTO does a D-22 have?
A D-22 has a 540 rpm rear PTO on a 34 x 28 x 6 mm shaft.
Sources and how this page was built
Compiled from Traktorenlexikon, “Renault D22 R7052”; and Traktorenlexikon, “Fendt Farmer 1 Z”.
