- Rigid chassis
- WhichTractor size: Utility
- No lab test on file
- 2000–2003
It sits on the utility/standard-size boundary, so either size is a fair description. It was ranked on an engine power figure whose source does not say gross or net. WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Hürlimann XT 913 specs: hp, weight, years
SAME-DEUTZ-FAHR 1000.6 WT six-cylinder diesel. The manufacturer claimed 130.2 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
130.2 hp
97.1 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Hürlimann XT 913”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 11,971 lb
- 3-point lift
- 13,669 lb
- Top speed
- 24.9 mph
Hürlimann XT 913 specs: key facts
The Hürlimann XT 913 was built from 2000 to 2003.
The Hürlimann XT 913 has a claimed engine power (gross or net not stated) of 97.1 kW (130.2 hp); it has no measured PTO figure.
The Hürlimann XT 913 is four-wheel drive (4WD).
The Hürlimann XT 913 has a SAME-DEUTZ-FAHR 1000.6 WT engine, a 6-cylinder 6.00 L diesel unit.Source 1
The Hürlimann XT 913 weighs 5,430 kg (11,971 lb) unladen.
The Hürlimann XT 913 has an independent rear PTO running at 540/1000/540E/1000E rpm.
The three-point hitch of the Hürlimann XT 913 lifts 6,200 kg (13,669 lb) at the lower-link ends.
Source · Traktorenlexikon, “Hürlimann XT 913”
How does the XT 913 compare with its class?
- Limitation:
The power figure is a manufacturer claim, not a measurement. No laboratory test report exists for this machine. Of the 273 tractors within 10% of its power, 11% carry one.
Derived by WhichTractor from 273 comparable records. How we work this out
How much horsepower does an XT 913 have?
The only figure for the XT 913 is 130.2 hp (97.1 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Hürlimann XT 913”
What engine is in an XT 913?
An XT 913 has a SAME-DEUTZ-FAHR 1000.6 WT, a 6-cylinder 6.00 L diesel engine.
| Make & model | SAME-DEUTZ-FAHR 1000.6 WTSource 1 |
|---|---|
| Cylinders | 6, liquid-cooledSource 1 |
| Displacement | 366.1 ci · 6.00 LSource 1 |
| Max torque | 367 lb·ft · 497 N·m @ 1,300 rpm |
| Injection | Direct injection |
| Electrical system | 12 V |
Source · Traktorenlexikon, “Hürlimann XT 913”
How much will an XT 913 lift?
An XT 913 lifts 13,669 lb (6,200 kg) at the lower-link ends.
| System | Load sensing |
|---|---|
| Pressure | 3,046 psi · 210 bar |
| Lift at ends | 13,669 lb · 6,200 kg |
| Rear PTO | Independent, engine-driven, 540/1000/540E/1000E rpm @ 2,229 engine rpmEngages under load |
Source · Traktorenlexikon, “Hürlimann XT 913”
What transmission does an XT 913 have?
Transmission specifications for the XT 913 are below.
| Clutch | Pedal operated hydraulic dry single-disc clutch |
|---|---|
| Brakes | Hydraulically operated wet four-wheel disc brake |
| Steering | Hydrostatic DANFOSS steering |
| Top speed | 24.9 mph · 40 km/h |
Source · Traktorenlexikon, “Hürlimann XT 913”
How much does an XT 913 weigh?
An XT 913 weighs 11,971 lb (5,430 kg) unladen.
| Unladen weight | 11,971 lb · 5,430 kg |
|---|---|
| Wheelbase | 108.3 in · 2,750 mm |
| Length | 172.4 in · 4,380 mm |
| Width | 87.8–107.7 in · 2,230–2,735 mm |
| Height | 110.4 in · 2,805 mm |
| Ground clearance | 17.7 in · 450 mm |
| Front track | 71.9–93.1 in · 1,825–2,365 mm |
| Rear track | 68.9–88.6 in · 1,750–2,250 mm |
| Turning radius, braked | 12.0 ft · 3.65 m |
Source · Traktorenlexikon, “Hürlimann XT 913”
What oil does an XT 913 take, and how much?
An XT 913 engine takes 11.6 qt (11.0 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 11.6 qt · 11.0 LSource: Traktorenlexikon, “Hürlimann XT 913” · single source, not independently verified |
| Transmission & hydraulic | 79.3 qt · 75.0 LSource: Traktorenlexikon, “Hürlimann XT 913” · single source, not independently verified |
| Cooling system | 18.0 qt · 17.0 LSource: Traktorenlexikon, “Hürlimann XT 913” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with an XT 913?
Within 10% of its 130.2 hp of claimed engine power, the same type, and first built within 15 years of it.
- Lamborghini 1300 DT130.2 hp engine, claimed · 2000–2003Side by side with the XT 913 →
- SAME Silver 130 DT130.2 hp engine, claimed · 2000–2004Side by side with the XT 913 →
- Lamborghini 135 DT B Formula130.2 hp engine, claimed · from 1996Side by side with the XT 913 →
- SAME Antares II 130130.2 hp engine, claimed · from 1996Side by side with the XT 913 →
- New Holland T 6060 Elite130.2 hp engine, claimed · 2007–2012Side by side with the XT 913 →
- Lamborghini 135 DT Formula130.2 hp engine, claimed · 1991–1996Side by side with the XT 913 →
Common questions about the Hürlimann XT 913
Is an XT 913 two-wheel drive or four-wheel drive?
The Hürlimann XT 913 is four-wheel drive (4WD).
What PTO does an XT 913 have?
An XT 913 has a independent 540/1000/540E/1000E rpm rear PTO.
