- Vehicle type: unspecified
- Rigid chassis
- WhichTractor size: Utility
- No lab test on file
- 1937–1942
- 1,528 built
WhichTractor size, not the maker’s category
We looked and the record does not say what this machine is. How we decide what a machine is
Güldner A 20 specs: hp, weight, years
Güldner 1F one-cylinder diesel. The manufacturer claimed 19.7 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
19.7 hp
14.7 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Güldner A 20”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 3,527 lb
- Top speed
- 8.0–9.3 mph
Güldner A 20 specs: key facts
The Güldner A 20 was built from 1937 to 1942.
The Güldner A 20 has a claimed engine power (gross or net not stated) of 14.7 kW (19.7 hp); it has no measured PTO figure.
The Güldner A 20 is two-wheel drive (2WD).
The Güldner A 20 has a Güldner 1F engine, a 1-cylinder 1.56 L diesel unit.
The Güldner A 20 weighs 1,600 kg (3,527 lb) unladen.
The Güldner A 20 has a rear PTO running at 560 rpm.
Source · Traktorenlexikon, “Güldner A 20”
How much horsepower does an A 20 have?
The only figure for the A 20 is 19.7 hp (14.7 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Güldner A 20”
What engine is in an A 20?
An A 20 has a Güldner 1F, a 1-cylinder 1.56 L diesel engine.
| Make & model | Güldner 1F |
|---|---|
| Cylinders | 1, liquid-cooled |
| Displacement | 95.1 ci · 1.56 L |
| Max torque | 69 lb·ft · 94 N·m |
| Electrical system | 6 V |
Source · Traktorenlexikon, “Güldner A 20”
How much will an A 20 lift?
Hydraulic and PTO specifications for the A 20 are below.
| Rear PTO | 560 rpm |
|---|
Source · Traktorenlexikon, “Güldner A 20”
What transmission does an A 20 have?
Transmission specifications for the A 20 are below.
| Clutch | Single plate dry clutch by Fichtel & Sachs |
|---|---|
| Steering | Worm steering gear |
| Top speed | 8.0–9.3 mph · 12.8–15.0 km/hthe article lists alternatives |
Source · Traktorenlexikon, “Güldner A 20”
How much does an A 20 weigh?
An A 20 weighs 3,527 lb (1,600 kg) unladen.
| Unladen weight | 3,527 lb · 1,600 kg |
|---|---|
| Maximum permissible mass | 4,409 lb · 2,000 kg |
| Maximum front axle load | 1,764 lb · 800 kg |
| Maximum rear axle load | 2,646 lb · 1,200 kg |
| Wheelbase | 65.4 in · 1,660 mm |
| Length | 104.3 in · 2,650 mm |
| Width | 60.6 in · 1,540 mm |
| Height | 66.9 in · 1,700 mm |
| Ground clearance | 9.8 in · 250 mm |
| Front track | 50.0 in · 1,270 mmWikibooks gives one track for both axles |
| Rear track | 50.0 in · 1,270 mmWikibooks gives one track for both axles |
Source · Traktorenlexikon, “Güldner A 20”
What oil does an A 20 take, and how much?
Fluid capacities for the A 20 are below.
| System | Capacity |
|---|---|
| Transmission | 10.6 qt · 10 LSource: Traktorenlexikon, “Güldner A 20” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Which tractors compare with an A 20?
Within 10% of its 17 hp at the PTO as the maker claimed it, with no laboratory test on file, the same type, and first built within 15 years of it.
- Lanz D 350017 hp PTO, claimed · 1936–1942Side by side with the A 20 →
- Lanz D 350617 hp PTO, claimed · 1936–1952Side by side with the A 20 →
- International Harvester B/BN16.7 hp PTO, claimed · 1940–1948Side by side with the A 20 →
- International Harvester A/AV17.2 hp PTO, claimed · 1939–1948Side by side with the A 20 →
- International Harvester Farmall A/AV17.2 hp PTO, claimed · 1947–1954Side by side with the A 20 →
- International Harvester W-1416.1 hp PTO, claimed · 1938–1939Side by side with the A 20 →
Common questions about the Güldner A 20
Is an A 20 two-wheel drive or four-wheel drive?
The Güldner A 20 is two-wheel drive (2WD).
What PTO does an A 20 have?
An A 20 has a 560 rpm rear PTO.
Sources and how this page was built
Compiled from Traktorenlexikon, “Güldner A 20”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- Traktorenlexikon: Güldner A 20 — CC BY-SA 4.0, WIKIBOOKS-TL-63099 · revision 956571. Wikibooks contributors (Traktorenlexikon). Original document
