- Crawler
- WhichTractor size: Compact
- No lab test on file
- 1964–1965
WhichTractor size, not the maker’s category
Derived by WhichTractor from a sourced three-point linkage. How we decide what a machine is
Fiat 311C specs: hp, weight, years
FIAT 605 D.000 four-cylinder diesel. The manufacturer claimed 29.6 horsepower. No laboratory has tested one, so there is no measured figure at the shaft.
Engine power, claimed · gross or net not stated
29.6 hp
22.1 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Fiat 311-C”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 4,079 lb
- Hyd. flow
- 4.4 gpm
- Top speed
- 6.8 mph
Fiat 311C specs: key facts
The Fiat 311C was built from 1964 to 1965.
The Fiat 311C has a claimed engine power (gross or net not stated) of 22.1 kW (29.6 hp); it has no measured PTO figure.
The Fiat 311C is a tracked machine.
The Fiat 311C has a FIAT 605 D.000 engine, a 4-cylinder 1.90 L diesel unit.
The Fiat 311C weighs 1,850 kg (4,079 lb) unladen.
The Fiat 311C has a rear PTO running at 540 rpm.
The hydraulic pump of the Fiat 311C delivers 16.5 L/min (4.4 gpm).
Source · Traktorenlexikon, “Fiat 311-C”
How much horsepower does a 311C have?
The only figure for the 311C is 29.6 hp (22.1 kW) of claimed engine power, gross or net not stated, no test standard stated — not power at the shaft.
Source · Traktorenlexikon, “Fiat 311-C”
What engine is in a 311C?
A 311C has an FIAT 605 D.000, a 4-cylinder 1.90 L diesel engine.
| Make & model | FIAT 605 D.000 |
|---|---|
| Cylinders | 4, liquid-cooled |
| Displacement | 116.0 ci · 1.90 L |
| Max torque | 74 lb·ft · 101 N·m @ 1,600 rpm |
Source · Traktorenlexikon, “Fiat 311-C”
How much will a 311C lift, and what is its hydraulic flow?
Hydraulic and PTO specifications for the 311C are below.
| Pump flow | 4.4 gpm · 16.5 L/min |
|---|---|
| Pressure | 2,843 psi · 196 bar |
| Hitch category | Category 2 |
| Rear PTO | 540 rpm @ 1,845 engine rpm |
| PTO shaft | 1 3/8" with 6 splines |
Source · Traktorenlexikon, “Fiat 311-C”
What transmission does a 311C have?
Transmission specifications for the 311C are below.
| Clutch | Hand lever operated dry single plate clutch with dead center engagement |
|---|---|
| Top speed | 6.8 mph · 11.0 km/h |
Source · Traktorenlexikon, “Fiat 311-C”
How much does a 311C weigh?
A 311C weighs 4,079 lb (1,850 kg) unladen.
| Unladen weight | 4,079 lb · 1,850 kg |
|---|---|
| Wheelbase | 48.2 in · 1,225 mm |
| Length | 98.4 in · 2,500 mm |
| Width | 50.8 in · 1,290 mm |
| Height | 48.2 in · 1,225 mm |
| Ground clearance | 10.6 in · 270 mm |
| Front track | 39.8 in · 1,010 mmWikibooks gives one track for both axles |
| Rear track | 39.8 in · 1,010 mmWikibooks gives one track for both axles |
Source · Traktorenlexikon, “Fiat 311-C”
What oil does a 311C take, and how much?
A 311C engine takes 5.9 qt (5.6 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 5.9 qt · 5.6 LSource: Traktorenlexikon, “Fiat 311-C” · single source, not independently verified |
| Transmission | 8.3 qt · 7.9 LSource: Traktorenlexikon, “Fiat 311-C” · single source, not independently verified |
| Cooling system | 10.6 qt · 10.0 LSource: Traktorenlexikon, “Fiat 311-C” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Common questions about the Fiat 311C
Is a 311C two-wheel drive or four-wheel drive?
The Fiat 311C is a tracked machine.
What PTO does a 311C have?
A 311C has a 540 rpm rear PTO on a 1 3/8" with 6 splines shaft.
Sources and how this page was built
Compiled from Traktorenlexikon, “Fiat 311-C”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- Traktorenlexikon: Fiat 311-C — CC BY-SA 4.0, WIKIBOOKS-TL-121922 · revision 1076465. Wikibooks contributors (Traktorenlexikon). Original document
