- Vehicle type: unspecified
- Rigid chassis
- WhichTractor size: High-power
- Lab tested ×1
- from 2005
WhichTractor size, not the maker’s category
We looked and the record does not say what this machine is. How we decide what a machine is
Fendt 936 Vario specs: hp, weight, years
Deutz TCD 2013L06 4V. The manufacturer claimed 355 horsepower. The only laboratory test on record is of one version: OECD Test 2536 measured 342.6 hp at the PTO of the 936 Vario TMS, COM IIIa. Compared at the engine's rated speed, where the brochure figure is quoted, the shaft gave 314.5 hp — 11.5% below the claim.
Engine power, claimed · gross or net not stated
355 hp
265 kW as stated by the source
No lab test on file
Claimed · standard not stated by the source
Source · Traktorenlexikon, “Fendt 936 Vario”, claimed
This is the maker’s own figure, measured at the engine. Power at the PTO is lower — by how much, for this machine, nobody has measured.
- Weight
- 22,840 lb
- Top speed
- 37.3 mph
Fendt 936 Vario specs: key facts
The Fendt 936 Vario was first built in 2005.
Only one version of the Fendt 936 Vario has a laboratory test on record: the 936 Vario TMS, COM IIIa produced 255.5 kW (342.6 hp) at the PTO, measured on OECD Test 2536.Source 1
The Fendt 936 Vario has a claimed engine power (gross or net not stated) of 265 kW (355 hp); it has no measured PTO figure.
The Fendt 936 Vario is four-wheel drive (4WD).Source 1
The Fendt 936 Vario weighs 10,360 kg (22,840 lb) unladen.
The Fendt 936 Vario has a rear PTO running at 540E/1000 rpm.
Source · Traktorenlexikon, “Fendt 936 Vario”
How does the 936 Vario compare with its class?
We will not rate this machine against its class. Only 27 published tractors sit within 10% of its 265 kW — too few to say what is normal.
Derived by WhichTractor. How we work this out
How much horsepower does a 936 Vario have?
The only laboratory test on record is of one version. OECD Test 2536 measured 342.6 hp at the PTO of the 936 Vario TMS, COM IIIa. For the 936 Vario as a whole the figure is the 355 hp claimed for the engine, which is not power at the shaft.
Sources · Traktorenlexikon, “Fendt 936 Vario”; OECD test report 2536, 2010
How much will a 936 Vario lift?
Hydraulic and PTO specifications for the 936 Vario are below.
| System | Load sensing |
|---|---|
| Rear PTO | 540E/1000 rpm |
| PTO shaft | 44.45 mm, 6 splinesSource 1On record for 1 of 2 configurations |
Source · Traktorenlexikon, “Fendt 936 Vario”
What transmission does a 936 Vario have?
Transmission specifications for the 936 Vario are below.
| Steering | Hydrostatic steering with reaction steering system |
|---|---|
| Top speed | 37.3 mph · 60 km/h |
Source · Traktorenlexikon, “Fendt 936 Vario”
How much does a 936 Vario weigh?
A 936 Vario weighs 22,840 lb (10,360 kg) unladen.
| Unladen weight | 22,840 lb · 10,360 kg |
|---|---|
| Maximum permissible mass | 35,274–39,683 lb · 16,000–18,000 kg |
| Wheelbase | 120.1 in · 3,050 mm |
| Length | 222.6 in · 5,655 mm |
| Width | 108.3 in · 2,750 mm |
| Height | 132.8 in · 3,372 mm |
| Ground clearance | 22.4 in · 570 mm |
| Front track | 82.7 in · 2,100 mm |
| Rear track | 78.7 in · 2,000 mm |
| Turning radius, braked | 19.4 ft · 5.90 m |
Source · Traktorenlexikon, “Fendt 936 Vario”
What oil does a 936 Vario take, and how much?
A 936 Vario engine takes 40.2 qt (38 L). Single source, not independently verified — always confirm against the operator’s manual for your machine.
| System | Capacity |
|---|---|
| Engine oil | 40.2 qt · 38 LSource: Traktorenlexikon, “Fendt 936 Vario” · single source, not independently verified |
| Transmission | 70.8 qt · 67 LSource: Traktorenlexikon, “Fendt 936 Vario” · single source, not independently verified |
| Hydraulic | 115.2 qt · 109 LSource: Traktorenlexikon, “Fendt 936 Vario” · single source, not independently verified |
| Cooling system | 31.7 qt · 30 LSource: Traktorenlexikon, “Fendt 936 Vario” · single source, not independently verified |
Always confirm against the operator’s manual for your machine before service.
Common questions about the Fendt 936 Vario
Is a 936 Vario two-wheel drive or four-wheel drive?
The Fendt 936 Vario is four-wheel drive (4WD).
What PTO does a 936 Vario have?
A 936 Vario has a 540E/1000 rpm rear PTO.
Sources and how this page was built
Compiled from OECD tractor test report 2536; and Traktorenlexikon, “Fendt 936 Vario”.
Sources
Facts taken from these documents, units converted. Numbers beside a figure refer to this list. Licences and attribution
- OECD Code 2 test report 2/2 536: Fendt 936 Vario TMS, COM IIIa — Licence not stated by the publisher; facts cited, OECD-2536 · published 2010-01-28 · retrieved 2026-09-14. OECD; testing station DLG e.V., Gross-Umstadt, Germany. Original document
- Traktorenlexikon: Fendt 936 Vario — CC BY-SA 4.0, WIKIBOOKS-TL-40482 · revision 912350. Wikibooks contributors (Traktorenlexikon). Original document
